GE Profile PSW26LSRSS Manuale
R
Listed by
Underwriters
Laboratories
R
"94 SxS Refer
A
Front View
Top View
G
D
C
F
BE
H
PSW26LSR
GE Profile™ ENERGY STAR® 25.6 Cu. Ft. Stainless-Wrapped Side-By-Side Refrigerator
For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
ge.com or call GE Answer Center® service,
800.626.2000.
Dimensions and Installation Information (in inches)
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
210335
Specification Created 3/05
Overall
Dimensions
Height to top of hinge (in.) A 70-1/2*
Height to top of case (in.) B 70-1/2
Case depth without door (in.) C†28
Case depth less door handle (in.) D†32-1/4
Case depth with door handle (in.) E†34-7/8
Depth with fresh food door open 90° (in.) F†50-1/16
Width (in.) G
35-3/4**
Width with door open 90° with door handle (in.) H 42-3/8
Air
Clearances
Each side (in.) 1/8
Top (in.) 1
Back (in.) 1
*When cap is removed: 69-1/4"
**Width including top caps is 35-7/8".
† Water hook-up fits in back air clearance when calculating
installation depth.
If installed against a wall, allow clearance of 14-3/16" on freezer
side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 18-15/16".
Allow additional space for any necessary leveling adjustments.
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
R
Listed by
Underwriters
Laboratories
R
PSW26LSR
GE Profile™ ENERGY STAR® 25.6 Cu. Ft. Stainless-Wrapped Side-By-Side Refrigerator
For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
ge.com or call GE Answer Center® service,
800.626.2000.
To Remove Top Caps and Doors on PSW26LSR
Step 1: the refrigerator. Remove two screws, one on each side at the rear of the top
cap. Lift off and remove top cap.
Step 2: Open both doors. Remove one screw on each side of the toekick. Pull forward
to remove toekick.
Step 3: On the freezer door, disconnect water line coupler by pushing against the
collar on the left side. Disconnect wire harness.
Step 4: Use a Torx T-20 screwdriver to remove 2 screws holding the top hinge.
Carefully remove hinge while supporting door. Lift door up and off bottom hinge.
Remove fresh food door in the same manner. Note: Do not remove bottom hinges!
Door alignment will be difficult if bottom hinges are removed.
Step 5: Place refrigerator onto a hand truck, upright and against one side.
Move refrigerator to the installation location.
Step 6: Carefully lower doors onto bottom hinges. Be sure to route the tubing and
electrical connector through the bottom hinge. Reinstall top hinges.
Step 7: Place cap over the top of the refrigerator. Reinstall the original screws in the
top and back of the cap.
Step 8: Reconnect the wiring harness and waterline.
210335
Specification Created 3/05
Water Line Coupler
1.
366-15A
Hinge Screws
Wire Harness
Toekick Screw
4.
3.
2.
PSW26LSR
GE Profile™ ENERGY STAR® 25.6 Cu. Ft. Stainless-Wrapped Side-By-Side Refrigerator
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
210335
Specification Created 3/05
PSW26PSRSS
WATER
CRUSHED
CUBEDCLOCK SET
LIGHT
DOOR ALARM
RESET WATER FILTER
HOLD 3 SEC.
LOCK CONTROL
HOLD 3 SEC.
Arctica
Features and Benefits
• Stainless-Wrapped - Provides stainless steel doors, side panels and top for a truly dramatic look
• Upfront, Electronic Touch Temperature Controls - Extremely precise and easy to use
• Integrated IceTM System - Frees up valuable freezer space. It tilts down, providing easy access
to bulk ice
• Tall LightTouch! Dispenser - Delivers chilled water, cubed or crushed ice at the slightest touch
• Integrated Shelf Support System - Provides strong, yet flexible support
• FrostGuardTM Technology - Protects frozen items from freezer burn by monitoring door openings
and defrosting only when needed
• Adjustable Slide-Out, Spillproof Glass Shelves - Shelves slide out, spills stay put
• TurboCoolTM Setting - “Revs up” the refrigerator, cooling it quickly after frequent door openings
• GE SmartWaterTM Plus Filtration System - Delivers clean, great-tasting water and ice through the
LightTouch! Dispenser with indicator light
• ClearLookTM Adjustable Gallon Door Bin - Store gallon containers with ease
• Model PSW26LSRSS - Stainless-wrapped
