ZV42ISHSS – GE Monogram 42" Professional Taper-Sided Island Hood
Dimensions and Specifications (in inches)
For answers to your Monogram,®GE Profile™or
GE®appliance questions, visit our website at
GEAppliances.com or call GE Answer Center®
service, 800.626.2000.Specification Revised 2/08
130660
Listed by
Underwriters
Laboratories
Duct Cover Accessories
ZX42DC10–For ceiling heights of 8' 6" to 10' 4". Includes telescoping
support frame and decorative cover.
Order accessory at the same time as the vent hood and have on site
before installation begins.
Product Clearances
These vent hoods must be installed 30" min. to 36" max. above the
cooking surface. Exact installation height is determined by ceiling
height. The cooking surface should be at least 36" above the floor.
Important: Clearances may vary due to type of cooking product
and local codes. Check with local inspectors to be sure standard
is applicable.
When installing the Island Hood above a Monogram Professional
Range or Cooktop, installation clearance must be at least 30".
20"
14"
25-3/4"
31-3/4" 42"
9"*
*9" for ceiling heights of 7’11" to 8’5"
using the supplied support frame and duct cover
*
*9" for ceiling heights of 7' 11" to 8' 5" using the supplied support
frame and duct cover.
This vent hood is designed to be used in ceiling mounted installations.
ZV42ISHSS – GE Monogram 42" Professional Taper-Sided Island Hood
Specification Revised 2/08
130660
Features and Benefits
• Sophisticated styling
• Powerful ventilation–1200 CFM
• Efficient capture performance
• Halogen light–Provides bright light that illuminates the
cooking surface below hood
• Removable stainless steel filters
• Stainless steel utensil racks
ZV54ISHSS
