GP SERIES

Commercial/Residential

Portable Generators

GP15000E

Model 5734

UPC Number: 696471057348

Emissions Certification: 49-State

A/C Rated Output Watts 15,000

A/C Maximum Output Watts 22,500

customer connectionsfeatures

120V

30A

120V

30A

120V

20A

120V

GFCI

20A

RESET

TEST

30A

CONTROL

OFF

CIRCUIT BREAKERS - PUSH TO RESET

120V/240V

30A

12Vdc

10A

IDLE

30A

GFCI

20A

120V/240V

50A

GP15000E

Outlets

A(1) Duplex 5-20R GFCI

B(1) Duplex 5-20R 120V

C(2) L5-30R

D(1) L14-30R

E(1) 12VDC

F(1) 14-50R

Circuit Breakers

M(2) 20A

N(4) 30A

O(1) 50A

Other Features

HHour Meter

IIdle Control Switch

• GENERAC OHVI ENGINE, FULL PRESSURE

LUBRICATION

• HIGH PERFORMANCE ALTERNATOR

• LARGE CAPACITY FUEL TANK FOR EXTENDED

RUN TIME

• IDLE CONTROL

• CIRCUIT BREAKER PROTECTED OUTLETS

• LIFTING EYE

• FIXED HANDLES

• 12.3" PNEUMATIC WHEELS

• 1.25" HARDENED STEEL TUBE CRADLE

• LOW TONE MUFFLER

2 of 2

GP15000E

Generac Power Systems, Inc. • P.O. Box 8, Waukesha, WI 53187 • generac.com

GP15000E

specifications

Product Series GP15000E Start Switch Type 3-Position

Model 5734 Switch Location On Engine

Configuration/Emissions 49-State Single-Point Lifting Eye Yes

A/C Rated Output Watts: 15,000 Fuel Gauge Built-in Tank

A/C Maximum Output Watts: 22,500 Fuel Tank Capacity (Gal) 16

A/C Voltage 120/240VAC Fuel Tank Capacity (Ltrs) 60.56

A/C Frequency 60 Hz Run Time at 50% (Hours) 10

Rated 120/240 VAC Amperage 62.5 Cord Set N/A

Max 120/240 VAC Amperage 93.8 Handle Style Fixed

Neutrals Not bonded to ground (Floating) Wheel type 12.3" Pneumatic Wheels

Engine Displacement 992cc Maintenance Kit Included

Engine Type OHVI Warranty - Residential 2 Year

Engine RPM 3600 Warranty - Commercial 1 Year

Recommended Oil SAE 30

Lubrication Method Full Pressure

Choke Type Manual Lever

Fuel Shut Off Manual Lever

Idle Control Yes

Starting Method Electric

Battery Included

Battery Size 12VDC 365 CCA

Low Oil Shutdown Method Low Pressure

dimensions and weights

Length (L) 48.5

Width (W) 31

Height (H) 39.5

Carton Length 49.25

Carton Width 23.25

Carton Height 31

Unit Weight (lbs) 363

Shipping Weight (lbs) 425
