Generac Power Systems 1293-2 Manuale utente

2700PSI

This symbol points out important safety instructions, which, if not followed, could endanger

the personal safety and/or property of yourself and others. Read and follow all instructions in

the manual before attempting to operate this unit.

Model No. 12932 (2700 psi High Pressure Washer) Manual No. B4724 evision 0 (4/14/1999)

Pressure Washer Owner’s Manual

Problems?

Questions?

Before taking your unit

back to the store,

call the pressure washer

helpline at

-800-270- 408

M-F 8-5 CT

GENERAC

The Reliable Ones

Generac Portable Products 2700PSI High Pressure Washer

CAUTION! Always disconnect spark plug wire and place wire where it cannot contact spark plug to prevent

accidental starting when setting up, transporting, adjusting or making repairs to your high pressure washer.

 Engine exhaust gases contain DEADLY carbon

monoxide gas. This dangerous gas, if breathed in

sufficient concentrations, can cause

unconsciousness or even death. Operate this

equipment only in the open air where adequate

ventilation is available.

 Gasoline is highly FLAMMABLE and its vapors are

EXPLOSIVE. Do not permit smoking, open flames,

sparks or heat in the vicinity while handling

gasoline. Avoid spilling gasoline on a hot engine.

Allow unit to cool for 2 minutes before refueling.

Comply with all laws regulating storage and

handling of gasoline.

 Use this pressure washer in areas away from

combustible materials, combustible fumes or dust.

 The high pressure equipment is designed to be

used with Generac authorized parts only. If you use

this equipment with parts that do not comply with

minimum specifications, the user assumes all risks

and liabilities.

 Some chemicals or detergents may be harmful if

inhaled or ingested, causing severe nausea,

fainting or poisoning.

 Do not allow CHILD EN to operate the pressure

washer at any time.

 Operate engine only at governed speed. unning

the engine at excessive speeds increases the

hazard of personal injury. Do not tamper with parts

which may increase or decrease the governed

speed.

 Do not wear loose clothing, jewelry or anything that

may be caught in the starter or other rotating parts.

 Before starting the pressure washer in cold

weather, check all parts of the equipment and be

sure ice has not formed there.

 Units with broken or missing parts, or without

protective housing or covers should NEVE be

operated.

 The muffler and air cleaner must be installed and in

good condition before operating the pressure

washer. These components act as spark arrestors if

the engine backfires.

 Check the fuel system for leaks or signs of

deterioration such as chafed or spongy hose, loose

or missing clamps or damaged tank or cap. Correct

all defects before operating the pressure washer.

 Do not spray flammable liquids.

 Never aim the gun at people, animals or plants.

 The high pressure stream of water that this

equipment produces can pierce skin and its

underlying tissues, leading to serious injury.

 High pressure spray can cause paint chips or other

particles to become airborne and fly at high speeds.

The engine exhaust from this product

contains chemicals known to the State

of California to cause cancer, birth

defects, or other reproductive harm.

WWAARRNNIINNGG::

IMPORTANT!  SAFETY RULES  IMPORTANT!

Generac Portable Products 2700PSI High Pressure Washer

 Always wear eye protection when you use this

equipment or when you are in the vicinity where the

equipment is in use.

 Never move the machine by pulling on the high

pressure hose. Use the handle provided on the top

of the unit.

 Always be certain the spray gun, nozzles and

accessories are correctly attached.

 Never use a spray gun which does not have a

trigger lock or trigger guard in place and in working

order.

 Use a respirator or mask whenever there is a

chance that vapors may be inhaled. ead all

instructions with the mask so you are certain it will

provide the necessary protection against inhaling

harmful vapors.

 High pressure spray may damage fragile items

including glass. Do not point spray gun at glass

when in the high pressure spray mode.

 Keep the hose connected to machine and the spray

gun while the system is pressurized. Disconnecting

the hose while the unit is pressurized is dangerous.

 Hold the spray gun firmly in your hands before you

start the unit. Failure to do so could result in an

injury from a whipping spray gun. Do not leave the

spray gun unattended while the machine is running.

 The cleaning area should have adequate slopes

and drainage to reduce the possibility of a fall due

to slippery surfaces.

 Keep water spray away from electric wiring or fatal

electric shock may result.

 Do not secure trigger gun in the pull-back (open)

position.

 Do not by-pass any safety device on this machine.

 The muffler and engine heat up during operation

and remain hot immediately after shutting it down.

Avoid contact with a hot muffler or engine or you

could be severely burned.

 Operate and store this unit on a stable surface.

 Never allow any part of the body to come in contact

with the fluid stream. DO NOT come in contact with

a fluid stream created by a leak in the high pressure

hose.

 High pressure hose can develop leaks from wear,

kinking, abuse, etc. Water spraying from a leak is

capable of injecting material into skin. Inspect hose

each time before using it. Check all hoses for cuts,

leaks, abrasions or bulging of cover, or damage or

movement of couplings. If any of these conditions

exist, replace hose immediately. Never repair high

pressure hose. eplace it with another hose that

meets minimum pressure rating of your pressure

washer.

IMPORTANT!  SAFETY RULES  IMPORTANT!

Generac Portable Products 2700PSI High Pressure Washer

CONGRATULATIONS on your purchase of a

GENE AC high pressure washer. It has been

designed, engineered and manufactured to give you

the best possible dependability and performance.

Should you experience any problem you cannot

easily remedy, please contact your nearest

GENE AC Authorized Service facility, or call the 1-

800 number listed on the front of this manual. We

have competent, well-trained technicians and the

proper tools to service or repair this unit.

Please read and retain this manual. The instructions

will enable you to assemble and maintain your high

pressure washer properly.

CUSTOMER

RESPONSIBILITIES

 ead and observe the safety rules.

 Follow regular schedule in maintaining, caring for

and using your high pressure washer.

 Follow the instructions under Customer

esponsibilities and Storage sections of this

Owner's Manual.

PRODUCT

SPECIFICATIONS

Pressure Washer Specifications

Outlet Pressure . . . . 2700 psi

Flow Rate . . . . . . . . . 2.7 gallons per minute (gpm)

Detergent Mix . . . . . . Use undiluted detergent

approved for pressure

washers

Water Supply . . . . . . Not to exceed 140°F

Temperature

Automatic Cool . . . . Will cycle when water

Down System reaches 140°-145°F

Engine Specifications

Engine Model . . . . . . Generac Power Systems

Rated Horsepower . . 7.8

Displacement . . . . . . 220cc

Spark Plug

Type . . . . . . . . C-12YC

Set Gap To: . . 0.030 inch (0.76mm)

Gasoline Capacity . . 4.2 U.S. quarts

Oil . . . . . . . . . . . . . . . SAE 30

In the State of California a spark arrestor is required

by law (Section 4442 of the California Public

esources Code). Other states may have similar

laws. Federal laws apply on federal lands.

NOTE: The spark arrestor must be maintained in

effective working order by the owner/operator.

You can order a replacement spark arrestor through

your authorized Generac service facility. See Engine

Owners Manual for part number.

Model Number 2932

Serial Number

Date of Purchase

The model and serial numbers will be found on a

decal attached to the pressure washer. ecord both

serial number and date of purchase and keep in a

safe place for future reference.

KNOW YOUR PRESSURE WASHER

Read this owners manual and safety rules before operating your high pressure washer.

Compare the illustrations with your high pressure washer to familiarize yourself with the locations of various

controls and adjustments. Save this manual for future reference.

Generac Portable Products 2700PSI High Pressure Washer

Automatic Cool Down System  Cycles water

through pump when water reaches 140°-145°F. Warm

water will discharge from pump under base of unit. This

system prevents internal pump damage.

Chemical Valve Handle  The handle allows you to

select the high pressure spray or the chemical spray

(located on the wand).

Dual Element Air Cleaner  Uses a dry type filter

element and foam pre-cleaner to limit the amount of

dirt and dust that gets in the engine.

Dual Lance  Must be connected to the spray gun.

Gas Tank  Fill with regular unleaded gasoline.

Goggles  Always use the enclosed goggles or other

eye protection when running your pressure washer.

High Pressure Hose  Connect one end to water

pump and the other end to spray gun.

High Pressure Outlet  Connection for high pressure

hose.

Primer Bulb  Used for starting a cold engine.

Pump  Develops high pressure.

Spark Arrestor Muffler  Exhaust muffler lowers

engine noise and is equipped with a spark arrestor

screen, a USDA mandate for engine use in national

forests and parks.

Spray Gun  Controls the application of water and

chemical onto cleaning surface with trigger device.

Includes safety latch.

Water Inlet  Connection for garden hose.

Spray Gun

Chemical Valve Handle

High Pressure Hose

Goggles

Dual Element

Air Cleaner

Gas Tank

Water Inlet

Pump equipped with

Automatic Cool Down System

High Pressure Outlet

Spark Arrestor Muffler

Primer Bulb

Dual Lance

Generac Portable Products 2700PSI High Pressure Washer

ead entire owners manual before you attempt to

assemble or operate your new pressure washer. Your

new pressure washer has been assembled at the

factory with the exception of those parts left

unassembled for shipping purposes.

REMOVE PRESSURE

WASHER FROM CARTON

 emove parts box included with pressure washer.

 Slice two corners at guide handle end of carton

from top to bottom so the panel can be folded down

flat, then remove all packing material.

 oll pressure washer out of carton.

Carton Contents

Items in the carton include:

 Main Unit

 Manual Bag

 Owners Manual

 Engine Owners Manual

 Nozzle Cleaning Kit

 O ing Maintenance Kit

 StaBil® Brochure

 StaBil®

 Owner egistration Card

 Parts Box (which includes the following):

 Video

 Engine Oil

 Wireform

 Goggles

 Spray Gun

 Dual Lance

 High Pressure Hose

 Handle

 Handle Parts Bag (which includes the following):

 2 carriage bolts

 2 knobs

PREPARING PRESSURE

WASHER FOR USE

If you have any problems with the assembly of your

pressure washer or if parts are missing or damaged,

call the Pressure Washer Helpline at -800-270- 408.

To prepare your pressure washer for operation you

will need to perform these tasks:

 emove shipping cap from your pump and install oil

dipstick.

 Attach the handle and attach the wire form that

holds high pressure hose and spray gun.

 Connect high pressure hose to the spray gun and

the pump and connect water supply to the pump.

 Add oil to engine crankcase.

 Add fuel to fuel tank.

Remove Shipping Cap / Install Oil

Dipstick

To prevent oil from leaking from the pump, a shipping

cap has been installed on the oil breather of the

pump.

You must remove the shipping cap and the install oil

dipstick for your pressure washer to operate properly

(Figure 1).

unning unit with the shipping cap installed will

damage the pump and void your warranty.

Figure 1  emove shipping cap and install oil

Shipping Cap

Oil Dipstick

emove shipping cap and

install oil dipstick here.

Generac Portable Products 2700PSI High Pressure Washer

Attach the Handle

 Place the handle onto the bottom of the handle

supports already connected to the main unit. Make

sure the holes in the handle align with the holes in

the handle supports (Figure 2).

Note: It may be necessary to move the handle

supports from side to side in order to align the handle

so it will slide over the handle supports.

 Insert the carriage bolts from the outside through

the holes on the handle and attach the plastic

knobs on the inside. Tighten the knobs by hand

(Figure 3).

 Insert the wire support with the longer arm

positioned on the left. From this view (from rear of

unit), the hook resembles a J (Figure 4).

Add Engine Oil

WARNING! Any attempt to crank or start the

engine before being properly serviced with the

recommended oil will result in an engine

failure.

Note: When adding oil to the engine crankcase, use

only high quality detergent oil rated with API service

classification SF,SG, SH or SH/CD rated SAE 30

weight.

Select the oils viscosity grade according to your

expected operating temperature:

Do Not Use SAE 0W40 Oil.

Although multi-viscosity oils (5W30, 10W30, etc.)

improve starting in cold weather, these multi-viscosity

oils will result in increased oil consumption when used

above 32°F. Check your engine oil level more

frequently to avoid possible damage from running low

on oil.

To fill unit with oil:

 Place pressure washer on a level surface.

 Clean area around oil fill and remove oil fill cap

(Figure 5).

Figure 4  Fit wire form on handle.

Figure 3  Insert the carriage bolts and attach the

knobs.

colder 32°F warmer

5W30 SAE 30

Figure 2  Attach the top of the handle to the bottom of

the handle.

Make sure the

holes in the

handle

supports are

aligned with

the holes in

the handle.

Handle

Supports

Generac Portable Products 2700PSI High Pressure Washer

 Pour oil into the oil fill opening until it reaches point

of overflowing. DO NOT OVE FILL.

Note: The bottle of oil included with your pressure

washer contains more oil than the capacity of the

crankcase.

 Install oil fill cap, hand tighten securely.

Note: Check oil often during engine breakin.

Add Gasoline

DANGER! Never fill fuel tank indoors. Never

fill fuel tank when engine is running or hot. Do

not smoke when filling fuel tank.

WARNING! Never fill fuel tank completely full.

Fill tank to about 1/2" below the bottom of the

filler neck to provide space for fuel expansion.

Wipe away any fuel spillage from engine and

equipment before starting.

 Use fresh, clean fuel and store in approved

containers. Use clean fill funnels. Never use stale

gasoline left over from last season or gasoline

stored for long periods.

 Clean area around gas cap. emove cap

(Figure 6).

 Add UNLEADED gasoline, slowly, to fuel tank.

Use a funnel to prevent spillage.

 Install gas cap and wipe up any spilled gasoline.

Connect Hose and Water Supply to

Pump

WARNING! You must assemble wand and

attach all hoses before you start engine.

Starting engine without all hoses connected

and water supplied will damage pump.

 Uncoil high pressure hose and attach hose quick

connect coupler to the fitting on the spray gun

(Figure 7). To engage the fitting, pull back on the

coupler collar, insert the gun fitting, and release the

collar. Pull on the gun to make sure it is securely in

place.

Figure 7  Connect high pressure hose to spray gun.

Figure 6  Add gasoline to fuel tank.

Gas Cap

Connect High Pressure

Hose Here

Figure 5  Add oil to engine crankcase. Do not attempt

to start engine without adding oil.

Oil Fill Cap

Make sure unit is on a level

surface before filling with oil!

Coupler Collar

Generac Portable Products 2700PSI High Pressure Washer

 Similarly, attach other end of high pressure hose to

the high pressure quick connect fitting on the pump

(Figure 8). Pull on the hose to make sure it is

securely attached to the pump.

 Before you connect your garden hose to the water

inlet, inspect the water inlet screen (see Figure 9).

Clean the screen if it contains debris or have it

replaced if damaged. Do not run the pressure

washer if the water inlet screen is damaged.

 Connect garden hose to water inlet. Tighten firmly

by hand (Figure 9).

 Turn on the water (open valve completely).

 Squeeze trigger on gun to purge pump system of

air and impurities. Squeeze until a steady stream

appears.

WARNING! Before starting the pressure

washer, be sure you are wearing adequate

eye protection.

 Attach dual lance to spray gun. Tighten by hand.

CHECKLIST BEFORE

STARTING ENGINE

In review, look back over the assembly to see if you

have performed all of the following.

 Check for properly tightened hose connections

(high pressure and water supply). Make sure the

hoses have no kinks, cuts, or damage.

 Check that oil has been added to proper level in

engine crankcase before trying to start the pressure

washer.

 Add proper gasoline to fuel tank.

 Provide proper water supply (not to exceed 140°F).

 Be sure to read Safety ules and Operation

sections before using the pressure washer.

Figure 8  Connect high pressure hose to pump.

Connect High

Pressure Hose

Here

Figure 9  Connect the garden hose to water inlet and

turn ON the water.

Check Screen for

Damage and

Connect Garden

Hose Here

Generac Portable Products 2700PSI High Pressure Washer

HOW TO USE YOUR

PRESSURE WASHER

If you have any problems operating your pressure

washer, please call the pressure washer helpline at

-800-270- 408.

How to Start Your Engine

The best way to start your engine-powered pressure

washer for the first time is to follow these instructions

step-by-step. This starting information also applies

whenever you start the engine after you have let the

pressure washer sit idle for at least a day.

 This pressure washer requires a water source that

flows at least 3.0 gallons per minute. Do not attempt

to siphon water from a non-pressurized container.

Place the pressure washer close enough to an

outside water source so that no more than 50' of

garden hose is needed.

 Check that the high pressure hose is tightly

connected to the spray gun and to the pump. See

ASSEMBLY section for illustrations.

 Connect the garden hose to water inlet on the

pressure washer pump and turn the water valve on

all the way.

WARNING! Do not run pump without the

water supply connected and turned on. You

must follow this caution or the pump will be

damaged.

 emove dual lance from the spay gun.

 Squeeze trigger on spray gun until a steady

stream of water appears.

 Apply the safety latch to the spray gun trigger

(Figure 10).

 Place the un/Stop switch to Run.

 Press the primer bulb 3 times, waiting 2 seconds

between each push

Note: For a warm engine, do not prime.

 Grasp rope handle and pull slowly until you feel

some resistance. Then pull cord rapidly to

overcome compression, prevent kickback and start

the engine. Let rope return to starter slowly.

If after 3 pulls the engine fails to start, disengage the

spray gun safety latch, squeeze the trigger to relieve

water pressure, re-engage the spray gun safety latch

and pull the recoil starter handle rapidly (Max. 3

pulls).

How to Stop Your Pressure Washer

 Move the un/Stop switch to Stop.

 Simply shutting off the engine will not release

pressure in the system. Squeeze trigger on the

spray gun to relieve pressure in the hose.

Note: A small amount of water will spray out when

you release the pressure.

How to Use the Spray Gun and Dual

Lance

You now should know how to START your pressure

washer and how to STOP it. The information in this

section will tell you how to adjust pressure and apply

chemicals using the spray gun and dual lance.

DANGER! Never put hands in front of nozzle.

 For most effective cleaning, keep spray nozzle

between 8 to 24 inches away from cleaning surface.

 If you get spray nozzle too close, especially using

high pressure, you may damage the cleaning

surface.

 Do not get closer than 6 inches when cleaning

automobile tires.

Figure 10  Safety Latch.

Safety Latch Applied

Altri manuali Generac Power Systems Idropulitrice

Generac Power Systems

Generac Power Systems 2600 PSI Manuale utente

Generac Power Systems

Generac Power Systems 1300PSI Manuale utente

Generac Power Systems

Generac Power Systems 1700PSI Manuale utente

Generac Power Systems

Generac Power Systems OneWASH Manuale utente

Generac Power Systems

Generac Power Systems 1292-1 Manuale utente

Generac Power Systems

Generac Power Systems 2100PSI 1536-0 Manuale utente

Generac Power Systems

Generac Power Systems Power Washer Manuale utente

Generac Power Systems

Generac Power Systems 2000PSI Manuale utente

Generac Power Systems

Generac Power Systems Power Washer Manuale utente

Generac Power Systems

Generac Power Systems 1067-0 Manuale utente

Generac Power Systems

Generac Power Systems 1173-1 Manuale utente

Generac Power Systems

Generac Power Systems 4040 PRO GAS PW 49ST Manuale utente

Generac Power Systems

Generac Power Systems 1014-0 Manuale utente

Generac Power Systems

Generac Power Systems 6020-2 Manuale utente

Generac Power Systems

Generac Power Systems 7132 Manuale utente

Generac Power Systems

Generac Power Systems 1540-0 Manuale utente

Generac Power Systems

Generac Power Systems 1046-0 Manuale utente

Generac Power Systems

Generac Power Systems 1417-0 Manuale utente

Generac Power Systems

Generac Power Systems 1537-0 Manuale utente

Generac Power Systems

Generac Power Systems 1042-2 Manuale utente

Generac Power Systems

Generac Power Systems The Reliable Ones Manuale utente

Generac Power Systems

Generac Power Systems 1195-0 Manuale utente

Generac Power Systems

Generac Power Systems BELT DRIVEN POWER WASHER Manuale utente

Generac Power Systems

Generac Power Systems The Reliable Ones 1800PSI Manuale utente

Manuali Idropulitrice popolari di altre marche

Shark

Shark RG-232637 Manuale utente

Shakti Technology

Shakti Technology S3 Manuale utente

Kärcher

Kärcher K 4 Pure Manuale utente

Porter-Cable

Porter-Cable D25806-025-2 Manuale utente

REM POWER

REM POWER HDEm 662 Manuale utente

Landa

Landa HS-3000 Manuale utente

Craftsman

Craftsman 580.752270 Manuale utente

HIKOKI

HIKOKI AW 100 Manuale utente

Delco

Delco DC 1302 Manuale utente

Kärcher

Kärcher K 3 Full Control Manuale utente

BIEMMEDUE

BIEMMEDUE 120/10 - 170/13 Manuale utente

ARKSEN

ARKSEN 014-HG-14141-HR Manuale utente

Black & Decker

Black & Decker PW1700SPX Manuale utente

Kärcher

Kärcher 595 - SPARE Guida

Kranzle

Kranzle B 10 200 Manuale utente

Stihl

Stihl RE 90 Manuale utente

Husky

Husky HU80911 Manuale utente

PowR-Quip

PowR-Quip PQ-2600 Manuale utente
