Genius EYE 310 Manuale utente

English

-1-

Eye 310 Features

1 SnapShot Button

2 Lens

Adjust the focus by twisting the

lens.

3 LED Indicator

4 Swivel Base

Installing the Eye 310

1. Please install the driver first and then connect Eye 310 to

the USB port.

2. Installing the Eye 310 driver

a. Insert the Eye 310 Installation CD into the CD-ROM drive.

b. The Autorun screen will bring up the installation screen. Click on

“Driver” then simply follow the on-screen instructions.

c. Install “DirectX”from the CD.

Notice: If theAutorun screen doesn’t start, please follow these steps:

zClick on “Start Menu”.

zType D：\SETUP.EXE , then click “Enter” key.

(Assume your CD-ROM is in Drive D)

3. Insert the Eye 310’s USB cable to your desktop’s or laptop’s

USB port.

English

-2-

4. Complete software and hardware installation. You can

install the software you would like for video

conferencing or chat with your friends.

NOTE

To remove the driver installation:

Please go to the taskbar and follow “Start” Æ“Program” Æ“Eye 310”Æ

Click “Uninstall”, then follow the on-screen instructions to remove the

driver.

Genius Application (Windows Only)

You can use our software to capture the real-time image, record or

execute the simply security function.

To run the software, please go to the task bar and follow “Start”Æ

Click “Program”ÆChoose “Eye 310”ÆClick “Eye 310”. Or you may

execute the software by simply clicking the shortcut of “Eye 310”.

NOTE

After installing the driver of Eye 310, the system will automatically create a

file (C:\WINDOWS\Album or C:\WINNT\Album)to save the images you take

using the Genius Application.

English

-3-

1. Description for the major icon

Preview mode

Snapshot mode

Video Clip Mode

Security monitoring system

Exit the Genius UI

Camera Control

NOTE

In the “camera control section”, you can personalize your camera

settings for different circumstances.

English

-4-

1-You can flip the image horizontally or vertically by choosing “Image Mirror”

or “Image Flip”.

-When the light is not sufficient, you may click on “Low Light” to get a clear

image.

2You can adjust different values for different circumstances and environment

3When you want a still image capture, you can select a resolution size you want.

4You may adjust values toward image appearance. Before adjusting values, you

have to unclick “Auto” to unlock.

5-Press “Reset” to return to the manufacturer’s settings.

-Press “Restore” to return to the previous settings.

-Press “Save” to save the values you set up.

English

-5-

6Select the correct frequency according to the country where you are using the

web camera. (Before doing this, you will need to select “Indoor”.)

7For high quality image, please click the monitor type you are using with the

web camera

8-If your web camera is located in backlight position, you may click “Backlight

compensation” to get a sharper image.

-You can have a black-and-white photo effect by clicking on “B/W Mode”.

2. Preview Mode

You can use the function buttons on the control panel to zoom in/out and

move upward/downward/left/right.

Zoom in the image

Zoom out the image

English

-6-

Move the image upward

Move the image downward

Move the image to the left

Move the image to the right

Resolution Selection

There are 2 categories of resolution: RGB24 and

I420. You can select 5 different image resolutions for

each of them. The file size of I420 will be smaller than

RGB24. So, I420 may be the better choice for

transmission.

3. SnapShot Mode

You can press the Snapshot button in the right of the circle to take a

picture right away and share with your friends.

English

-7-

Send photo by e-mail

Shoot continuously

Resolution selection

This section shows the resolution you selected in

the “Preview Mode”. If you want to change the

resolution, please click “ ”to go back to the

“Preview Mode” to make the changes.

4. Video Clip Mode

You can record real-time image in this section.

Send photo by e-mail

English

-8-

Convert AVI files into MEPG-1 format

Start recording

Stop recording

Exit the Video Clip Mode

To Create animation

Press to start; Press to stop

Press to return to the video recording mode

This function has to be under the resolution of RGB24 320 x

240 or I420 320 x 240. Please make sure the resolution is

correct before executing this function.

Resolution selection

This section shows the resolution you selected in the “Preview

Mode”. If you want to change the resolution, please click

“”to go back to the “Preview Mode” to make the changes.

5. Security Monitoring S

monitor automatically. It can also record anytime until the HD is fu

there’s no movement, it will shut down automatically after four

seconds or otherwise it will be active when detecting new movem

It’s a great security monitoring system at times when you’re not

around.

ystem

his function records any movements that appear in front of your ll. If

ent.

English

-9-

Start recording

Stop recording

Setup time of the security monitoring system

Set up the degree of the variance for every encessecond of recording image. When the differ

are over the setup degree, the system will alert

you.

Set up the different alerting sound effects

NOTE

rity Monitoring System” section, you can record in any size ofIn “Secu

image resolution. If you want to change the resolution, please click

“”to go back to the “Preview Mode” and make the changes.

English

-10-



MSN Messenger, Yahoo Messenger, AOL

MSN Messenger ction, you’ll need MSN Messenger version 6 or later. Ifa. For live video fun

you don’t have it, please refer to the website:

http://www.msnmessenger-download.com to d

Now, get to sign onto MSN Messenger service.

ownload.

” to confirm.

the web

c. Choose a friend on the contact list and Click “OK

d. Double-click on your friends, who are available to chat. Click on

camera icon .

Your friend w ll te. i hen receive an invitation message. When your friend

Ya senger essenger at http://messenger.yahoo.com

confirms to talk, the video chat will start.

hoo Mes

a. Download Yahoo M and finish the

Tools menu, then select “Start My Webcam”.

e. will then receive an invitation message. When your friend

AOL Instant Messenger stant Messenger free at http://www.aim.com

registration, if you don’t have it.

Sign onto Yahoo Messenger.

c. From the main window, click

d. Right-click on a name in your Messenger List and choose “View

Webcam”.

Your friend

clicks YES, the video chat will start.

a. You can download AOL In

nd choose the friend you want to start

and finish the registration, if you don’t have it.

Sign onto AOL Instant Messenger.

c. Click on “Show Messenger Lists” a

with video chat.
