GeoVision GV-IR Manuale utente

2004/05

IR Remote Control User's Manual

Installation

Inserting Batteries

Remote Control Buttons

Changing the Main System OSD options

Changing the ViewLog OSD options

Fast Key Reference

Troubleshooting

Table of Contents

IR Remote Control User's Manual

Main System

ViewLog

PTZ Camera

Fo c us

Menu Ca n c el

OK Buttons function

in ViewLog mode

Menu navigation

and camera's pan

tilt control buttons

Camera select buttons

IR Remote Control User's Manual

Note: There are three types of remote controls, A, B and C type.

Type A remote control can only be used with Type A receiver. It

can't be used to Type B or C receiver.

Plug the receiver into a USB port. Immediately you are able to use

the remote control.

Make sure the following requirements have been met:

Packing List

Installation

Insert two AAA batteries into the remote control. Make sure that

you match the "+" and "-" on the batteries with the "+" and "-"

symbols inside the battery compartment.

Inserting Batteries

Remote Control x 1

Receiver x 1

System Requirement

Windows 2000 or XP

Software Requirement

V 6.1 or above

Men u Ca n c e l

USB Interface

Connect to PC

IR Remote Control User's Manual

Remote Control Buttons

Main System

Enter the Main System mode

Enter the ViewLog mode

Navigate the on-screen display (OSD) menu; Change the

Time Setting in the ViewLog mode; Control PTZ camera

ViewLog

Direction buttons

Open the OSD menu; Enter the settings

OK/Menu

Close the OSD menu; Return to the previous menu;

Call up the menu to exit Main System or ViewLog

Cancel

Me nu

Ca nc e l

IR Remote Control User's Manual

Rewind to view the previous event

Previous Event

Play and pause a video file

Play/Pause

Rewind and pause a video file

Rewind

Forward to view the next event

Next Event

Forward to view the next frame

Next Frame

Stop a video file

Stop

Rewind to view the previous frame

Previous Frame

Zoom in/out

Zoom in and out the display image of PTZ camera in the Main

System mode; Zoom in and out the display image in the

ViewLog mode

Increase and decrease the focus of PTZ camera in the Main

System mode; Speed up and slow down the playing of a video

file in the ViewLog mode

Switch the screen divisions

SPD/Focus + -

Screen Division

Turn the full-screen mode on and off

Full Screen

Turn the sound on and off

Mute

Change the camera channel; Change the Time

Setting in the ViewLog mode

Number buttons

Switch to the next screen

Page Down

Switch to the previous screen

Page Up

To change the Main System on-screen display (OSD) options

with the remote control, follow the steps below:

Changing the Main System OSD options

Press Main System to enter the Main System mode.

Press OK/Menu to open the OSD (see Figure 1).

Use Direction to select a menu you want.

Press OK/Menu to open the menu.

Use Direction to select a menu option and then press

OK/Menu to change the setting. Or simply press OK/Menu to

enable or disable an option in the case of Schedule and Camera

Scan menus.

IR Remote Control User's Manual

Select the screen division from 1-channel to 16-channel modes

Screen Division

Figure 1

Select showing all input module panels or several module panels

on the screen

Input Device

Enable and disable output devices

Output Device

Select cameras to start or stop monitoring

Monitor

Enable and disable schedules

Schedule

Enable and disable PTZ camera, the function of Preset Go, Auto

(Auto pan), AF (Auto focus) and Hiding PTZ Panel

PTZ Camera

Select remote applications, including Modem Server, TCP Server,

Multicast Server, Connect to VSM, Twin Server, WebCam Server

and Connect to Center V2

Network

Enable and disable the rotation through screen divisions

Camera Scan

To change the ViewLog on-screen display (OSD) options with

the remote control, follow the steps below:

Changing the ViewLog OSD options

Press ViewLog to enter the ViewLog mode.

Press OK/Menu to open the OSD (see Figure 2).

Use Direction to select a menu you want.

Press OK to open the menu.

Use Direction to select a menu option and then press

OK/Menu to change the setting.

Figure 2

Video Event Search

Select the view modes, including Single View, Thumbnail View,

Quad View and Multi View.

View Mode

Press the Direction buttons and to move back and

forward on an OSD time. (Month/Date/Year Hr.:Min.:Sec.)

Use number buttons to enter a desired time or press the

Direction buttons and to change the display time.

Press OK/Menu to view the search result

If the specified time can't be located, you will be prompted to

select the previous or next video event available.

IR Remote Control User's Manual

109

IR Remote Control User's Manual

Fast Key Reference

Num

Page

Down

End

HomeInsert

Back

Shift

CtrlCtrl AltAlt Space Bar

Enter

Print Scroll Pause

Delete

Enter

0987654321~

][

POIUYTREWQTab

Esc F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12

;LKJHGFDSACaps

?><MNBVCXZShift

Key FunctionKeyIcon

Ctrl+Alt+'1'

Alt+ ' ', Alt+ ' '

Enter the Main System mode

Navigate the on-screen display (OSD) menu

Ctrl+Enter Open the OSD menu; Enter the settings

ESC Close the OSD menu; Return to the previous menu

Ctrl+Alt+'9' Switch the screen division

Alt+Enter Turn the full-screen mode on and off

Alt+Num 1 ~ 9 and 01 ~ 9,0 Change the camera channel

Ctrl+Alt+F1 Switch to the previous screen

Alt+'M' Turn the sound on and off

Ctrl+Alt+F2 Switch to the next screen

* **

Icon for GeoVision IR Remote Control

Key for PC keyboard

Main System

Caution: Don't define the same shortcut keys that the remote

control has used, or it will lead to the malfunction of the IR

remote control. Num

Page

Down

End

HomeInsert

Back

Shift

CtrlCtrl AltAlt Space Bar

Enter

Print Scroll Pause

Delete

Enter

0987654321~

][

POIUYTREWQTab

Esc F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12

;LKJHGFDSACaps

?><MNBVCXZShift

Key FunctionKeyIcon

Ctrl+Alt+'2'

Alt+ ' ', Alt+ ' '

Enter the ViewLog mode

Navigate the on-screen display (OSD) menu;

Change the Time Setting

Ctrl+Enter Open the OSD menu; Enter the settings

ESC Close the OSD menu; Return to the previous menu

Alt+ '+'

Alt+ '-'

Alt+

Page Up

Zoom in the display image

Zoom out the display image

Speed up the playing of a video file

Alt+ Page Down Slow down the playing of a video file

Alt+'M' Turn the sound on and off

Alt+Num 1 ~ 9 and 01 ~ 9,0 Change the Time Setting;

Change the camera channel

(Media button)

(Media button) Play and pause a video file

(Media button) Rewind and pause a video file

Rewind to view the previous event

(Media button) Forward to view the next event

(Media button) Rewind to view the previous frame

(Media button)

Forward to view the next frame

Stop a video file

Ctrl+Alt+'9' Switch the screen division

* **

Icon for GeoVision IR Remote Control

Key for PC keyboard

ViewLog

IR Remote Control User's Manual

1211

IR Remote Control User's Manual

Use the following information to solve common problems.

The LED does not blink when a button is pressed.

Replace the batteries. See "Inserting batteries".

Make sure that you are less than 7-meter operating

distance and 30-degree receiving angle from the receiver.

Make sure that nothing is blocking the infrared remote

sensors on the remote control or the receiver.

The LED blinks when a button is pressed, but the system

does not respond.

Troubleshooting

Num

Page

Down

End

HomeInsert

Back

Shift

CtrlCtrl AltAlt Space Bar

Enter

Print Scroll Pause

Delete

Enter

0987654321~

][

POIUYTREWQTab

Esc F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12

;LKJHGFDSACaps

?><MNBVCXZShift

Key FunctionKeyIcon

Alt+ ' ', Alt+ ' '

Control PTZ camera

Ctrl+Enter Open the OSD menu; Enter the settings

ESC Close the OSD menu; Return to the previous menu

Alt+ '+'

Alt+ '-'

Alt+ Page Up

Zoom in the display image of PTZ camera

Zoom out the display image of PTZ camera

Increase the focus of PTZ camera

Alt+ Page Down Decrease the focus of PTZ camera

* **

Icon for GeoVision IR Remote Control

Key for PC keyboard

PTZ Camera
