GeoVision GV-PTZ010D Manuale utente

Hardware Manual

GV-IPCam H.264

Before attempting to connect or operate this product,

please read these instructions carefully and save this manual for future use.

PT Camera

PTZ Camera

ICH264TG2V10

Under the copyright laws, this manual may not be copied, in whole or in

part, without the written consent of GeoVision.

Every effort has been made to ensure that the information in this manual is

accurate. GeoVision, Inc. makes no expressed or implied warranty of any

kind and assumes no responsibility for errors or omissions. No liability is

assumed for incidental or consequential damages arising from the use of

the information or products contained herein. Features and specifications

are subject to change without notice. Note: no memory card slot or local

storage function for Argentina.

GeoVision, Inc.

9F, No. 246, Sec. 1, Neihu Rd.,

Neihu District, Taipei, Taiwan

Tel: +886-2-8797-8377

Fax: +886-2-8797-8335

http://www.geovision.com.tw

Trademarks used in this manual: GeoVision, the GeoVision logo and GV

series products are trademarks of GeoVision, Inc. Windows and Windows

XP are registered trademarks of Microsoft Corporation.

September 2015

Content

Content ................................................................................i

Options ..............................................................................iii

Chapter 1 PTZ Camera .....................................................

1.1 Packing List..............................................................................2

1.2 Features...................................................................................

1.3 Overview ..................................................................................

1.4 Installation................................................................................

1.4.1 Ceiling Mount...............................................................

1.4.2 L-Shaped Wall Mount...................................................

1.5 Connecting the Camera..........................................................

1.6 Focus Adjustment...................................................................

1.7 I/O Terminal Block..................................................................

1.7.1 Pin Assignment..........................................................

1.7.2 Voltage Load Expansion (Optional)............................

1.8 PTZ Control............................................................................

1.8.1 The PTZ Control Panel ...............................................

1.8.2 Automatic Focus.........................................................

1.8.3 PTZ Camera Settings..................................................

1.8.4 Image Settings............................................................

1.8.5 Preset Settings ...........................................................

1.8.6 Sequence Settings...................................................... 25

1.8.7 Auto Pan Settings.......................................................

1.8.8 System Configuration.................................................

1.9 Loading Factory Default..........................................................

Chapter 2 PT Camera......................................................

2.1 Packing List............................................................................

2.2 Features.................................................................................

2.3 Overview ................................................................................

2.4 Installation..............................................................................

2.5 Connecting the Camera..........................................................

2.6 Focus Adjustment...................................................................

2.7 I/O Terminal Block..................................................................

2.7.1 Pin Assignment..........................................................

2.7.2 Voltage Load Expansion (Optional)............................

2.8 PT Control..............................................................................

2.9 Loading Factory Default ..........................................................

iii

Options

Optional devices can expand your camera’s capabilities and versatility.

Contact your dealer for more information.

Device Description

Power Adapter The power adapter is available for all PT and PTZ

Camera. Contact your sales representative for the

countries and areas supported.

GV-PA191 PoE

Adapter

The GV-PA191 PoE adapter is designed to provide

power and network connection to the cameras over

a single Ethernet cable.

GV-POE Switch

The GV-POE Switch is designed to provide power

along with network connection for IP devices. The

GV-POE Switch is available in various models with

different numbers and types of ports.

GV-Relay V2

The GV-Relay V2 is designed to expand the voltage

load of GV IP devices. It provides 4 relay outputs,

and each can be set as normally open (NO) or

normally closed (NC) independently as per your

requirement.

PTZ Camera

Chapter 1 PTZ Camera

The GV-PTZ010D camera is a ceiling-mount device that provides panning,

tilting and zooming functions. The camera is designed to monitor a wide

area and also to focus on a specific part on the live view when suspicious

events occur. There are two models:

Model Model No. Description

GV-PTZ010D-N NTSC, IPCAM, 10x Optical Zoom,

D1, H.264, Fixed Iris

GV-PTZ010D

GV-PTZ010D-P PAL, IPCAM, 10x Optical Zoom,

D1, H.264, Fixed Iris

1.1 Packing List

GV-PTZ010D

Mounting Base

Mounting Cover

Wall Mount Bracket

Screw Anchor x 3

Long Screw x 3

Short Screw x 3

Round Screw x 3

GV-PTZ010D Software CD Washer x 3

GV-NVR Software DVD Terminal block

Warranty Card

Note: Power adapter can be purchased upon request.

PTZ Camera

1.2 Features

1/4" CCD image sensor

Dual streams from H.264, MPEG4 or MJPEG

Up to 30 fps at 704 x 480 / Up to 25 fps at 704 x 576

Day and night function (electronic)

10x optical zoom lens

10x digital zoom

Pan and tilt (Pan: -175° ~ 175°; Tilt: -45° ~ 90°)

Micro SD card slot (SD/SDHC) for local storage

Two-way audio

One sensor input and alarm output

Input-triggered Preset points

Motion detection

Privacy mask

IP address filtering

DC 12 V / AC 24 V / PoE (IEEE 802.3af)

Support for iPhone, iPad, Android and 3GPP

28 languages on Web interface
