26-1038
User’s Guide
Please read this user’s guide before using your new hub.
4-Port
Stackable USB 2.0 Hub
®
2
Package contents
• 4-PortStackableUSB2.0Hub
• User’sGuide • QuickStart
Features
• Connectuptofourdevicesfromonecomputer’s
USBport
• Stabledesignsavesvaluabledesktopspace
System Requirements
• OperatingSystem:WindowsVista™,Windows®XP,
Windows2000,WindowsME,MacOS9orlater
• Processor:Pentium800MHz
• Memory:64MBRAM
• Connection:USB2.0,USB1.1,USB1.0
1Connect to computer
®
3
Connectthehub’sUSBplugtoyourcomputer.The
hubinstallsautomatically.Ifnecessary,followtheon-
screeninstructionstocompleteinstallation.
2Connect other USB devices
ConnectuptofourUSBdevices.
3Stack hubs
Youcanbuyadditionalhubsandstackthemvertically.
1.Alignthetabsonthe
additionalhubwiththe
slotsontheoriginalhub,
thenrotatetheadditional
hubclockwisetosecureit
inplace.
2.Toconnecthubsinseries,
plugtheadditionalhub’s
USBplugtooneofthe
originalhub’sports.Then
plugtheoriginalhub’sUSB
plugtothecomputer’sUSB
port.
Or,plugallstackedhubs’USBplugstothe
computer’sUSBports.
®
4
Troubleshooting
Specifications
USBStandardCompliances.........................1.0,1.1or2.0
DataSpeed...............................................Low,1.5Mbps;
................................................................... Full,12Mbps;
................................................................ High,480Mbps
OperatingTemperature..............32°to104°F(0°to40°C)
OperatingHumidity....................................... 5%to85%
............................................................. (Non-Condensing)
Weight.........................................................1.41oz(40g)
Specicationsaresubjecttochangeandimprovementwithoutnotice.Actual
productmayvaryfromtheimagesfoundinthisdocument.
Problem Cause Solution
TheUSBHub
isn’tworking
properly.
Yourhubauto-
maticallyshuts
offanyportwith
aloworexces-
sivecurrent.
Disconnectandrecon-
necttheaffected
device.
Iftheportstilldoesn’t
work,disconnectthe
hubandthedevice,
andthenreconnect
both.
“PowerSurge
OnHubPort”
message
appearsoncom-
puterscreen.
TheUSB
powereddevice
isdrawingmore
powerthanthe
hubcanprovide.
Clickonthemessage
boxandfollowthe
instructionsonscreen
tore-enabletheport.
®
5
FCC Information
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassB
digitaldevice,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedto
providereasonableprotectionagainstharmfulinterferenceinaresidentialinstalla-
tion.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,
ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmful
interferencetoradiocommunications.However,thereisnoguaranteethatinterfer-
encewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmful
interferencetoradioortelevisionreception,whichcanbedeterminedbyturning
theequipmentoffandon,theuserisencouragedtotrytocorrecttheinterference
byoneormoreofthefollowingmeasures:
•Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweentheequipmentandreceiver.
•Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthe
receiverisconnected.
•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
ChangesormodicationsnotexpresslyapprovedbyIgnitionL.P.maycause
interferenceandvoidtheuser’sauthoritytooperatetheequipment.
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothe
followingtwoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and
(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethat
maycauseundesiredoperation.
Product 4-PortStackableUSB2.0Hub
Model 26-1038
Responsible
Party
IgnitionL.P.
3102MapleAve.Suite450
Dallas,TX75201
1-866-315-0426
Limited Warranty
IgnitionL.P.warrantsthisproductagainstdefectsinmaterialsandworkmanship
undernormalusebytheoriginalpurchaserforninety (90) daysafterthedateof
purchase.IGNITIONL.P.MAKESNOOTHEREXPRESSWARRANTIES.
Thiswarrantydoesnotcover:(a)damageorfailurecausedbyorattributableto
abuse,misuse,failuretofollowinstructions,improperinstallationormaintenance,
alteration,accident,ActsofGod(suchasoodsorlightning),orexcessvoltageor
current;(b)improperorincorrectlyperformedrepairsbypersonswhoarenota
IgnitionL.P.AuthorizedServiceFacility;(c)consumablessuchasfusesorbatteries;
(d)ordinarywearandtearorcosmeticdamage;(e)transportation,shippingor
insurancecosts;(f)costsofproductremoval,installation,set-upservice,adjust-
mentorreinstallation;and(g)claimsbypersonsotherthantheoriginalpurchaser.
Shouldaproblemoccurthatiscoveredbythiswarranty,taketheproductand
thesalesreceiptasproofofpurchasedatetotheplaceofpurchase.IgnitionL.P.
®
6
will,atitsoption,unlessotherwiseprovidedbylaw:(a)repairtheproductwithout
chargeforpartsandlabor;(b)replacetheproductwiththesameoracomparable
product;or(c)refundthepurchaseprice.Allreplacedpartsandproducts,and
productsonwhicharefundismade,becomethepropertyofIgnitionL.P.New
orreconditionedpartsandproductsmaybeusedintheperformanceofwarranty
service.Repairedorreplacedpartsandproductsarewarrantedfortheremainder
oftheoriginalwarrantyperiod.Youwillbechargedforrepairorreplacementofthe
productmadeaftertheexpirationofthewarrantyperiod.
IGNITIONL.P.EXPRESSLYDISCLAIMSALLWARRANTIESANDCONDITIONS
NOTSTATEDINTHISLIMITEDWARRANTY.ANYIMPLIEDWARRANTIES
THATMAYBEIMPOSEDBYLAW,INCLUDINGTHEIMPLIEDWARRANTY
OFMERCHANTABILITYAND,IFAPPLICABLE,THEIMPLIEDWARRANTYOF
FITNESSFORAPARTICULARPURPOSE,SHALLEXPIREONTHEEXPIRATION
OFTHESTATEDWARRANTYPERIOD.
EXCEPTASDESCRIBEDABOVE,IGNITIONL.P.SHALLHAVENOLIABILITY
ORRESPONSIBILITYTOTHEPURCHASEROFTHEPRODUCTORANYOTHER
PERSONORENTITYWITHRESPECTTOANYLIABILITY,LOSSORDAMAGE
CAUSEDDIRECTLYORINDIRECTLYBYUSEORPERFORMANCEOFTHE
PRODUCTORARISINGOUTOFANYBREACHOFTHISWARRANTY,INCLUDING,
BUTNOTLIMITEDTO,ANYDAMAGESRESULTINGFROMINCONVENIENCE
ANDANYLOSSOFTIME,DATA,PROPERTY,REVENUE,ORPROFITANDANY
INDIRECT,SPECIAL,INCIDENTAL,ORCONSEQUENTIALDAMAGES,EVENIF
IGNITIONL.P.HASBEENADVISEDOFTHEPOSSIBILITYOFSUCHDAMAGES.
SomeStatesdonotallowlimitationsonhowlonganimpliedwarrantylastsor
theexclusionorlimitationofincidentalorconsequentialdamages,sotheabove
limitationsorexclusionsmaynotapplytoyou.Thiswarrantygivesyouspecic
legalrights,andyoumayalsohaveotherrightswhichvaryfromStatetoState.You
maycontactIgnitionL.P.at:
IgnitionL.P.,3102MapleAve.Suite450,Dallas,TX75201 02/09
Forproductsupport,call
1-866-315-0426
©2009.IgnitionL.P.Allrightsreserved.
GigawareisaregisteredtrademarkusedbyIgnitionL.P.
WindowsisaregisteredtrademarkandWindowsVistaisatrademarkof
MicrosoftCorporationintheUnitedStatesand/orothercountries.Macisa
trademarkofApple,Inc.,registeredintheU.S.andothercountries.
Protecttheenvironmentbyrecyclingusedelectronics.Goto
E-CyclingCentral.comtondanelectronicrecyclingcenternearyou.
Printed
inChina
11A09
26-1038A
