GILMAN Gemini GMDF5 Manuale utente
Model No./ 型號 : GMDF5
5吋手提式座抬風扇
(USB / 4顆D號電蕊使用)
5-INCH HAND
CARRY DESK FAN
(USB / 4PCS D TYPE
BATTERY OPERATION)
1
SAFETY INSTRUCTION
Attention! When using electric tools, basic safety precautions should be
followed to reduce the risk of fire,electric shock and personal injury,including the
following,
Read all these instructions before operating this product and keep these
instructions for future reference.
1.Read and save these instruction.
2.Check the voltage indicated on the rating plate. This fan is designed for USB 5V
1A or 4 pcs D type battery operation supply.
3.Cleaning and user maintenance shall not be made by children without
supervision.
4.This appliance is only to be used with the power : 5v 1A power supply or 4pcs D
type battery ( not included )
5.Incorrect operation and improper handling can lead to faults on the appliance
and injuries to the user
6.In the event of improper use or incorrect handling, no liability can be accepted
for any damage that may occur.
7.Do not operate the appliance if the USB cable show signs of damage, if the
appliance has fallen on the floor or has been otherwise damaged. In such cases
take the appliance to a specialist for checking and repair if necessary.
8.Ensure that the mains cable does not hang over sharp edges or allow it to
become trapped.
9.Keep the appliance away from damp, and protect from splashes.
10.Keep the appliance and its cord out of reach of children less than 8 years.
11.Use the appliance on a flat, dry and heat resistance surface.
12.Do not operate the fan in an area where gasoline painting or such flammable
liquids is used or stocked.
13.Do not let hair, curtains, tablecloth, clothes or other objects next to the air
outlet of the fan. They could be sucked into the fan, causing damage or injuries.
14.Do not use this fan in a damp area such as bathroom.
15.Do not use this fan near a window.
16.Use this fan only as it is describe in this manual.
17.Do not try to disassemble this fan and fix it by user, If you need maintenance,
please send back the fan to our After-sales Service Center.
18.All components of this fan must not be replaced by the user.
2
1. This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
2. Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervised.
3. There are no serviceable parts in this unit. Do not attempt to disassemble.
4. Never use this fan with any solid-state speed control device. Doing so will
create fire and/or shock hazards.
5. Not allow children/Baby to put finger inside the fan grilles to avoid injury/dange.
WARNING
APPLIANCE COMPONENTS
!
1 3 5 L M H TIMER POWER
Timer button
Handle
ON/OFF/ wind
mode control
USB cable port
Timer Indicator
Wind mode
indicator
3
1 3 5 L M H TIMER POWER
Notice:
Start with the side close to the buttons when 4 D batteries are all set to be
placed. If not, then cells cannot be put in.
Start with the side close to the buttons when 4 D batteries are all set to be
Start with the side close to the buttons when 4 D batteries are all set to be
placed. If not, then cells cannot be put in.
IMPORTANT
Please remove the sponge (inside the fan, this sponge is used to protect blades
during long time shipment) before use. If the sponge is not removed, the fan will
not work.
How to take the sponge off:
Place your two hands like the below image;
Rotate the cover anticlockwise with TWO hands at the same time gently
until the both lines on top of fan head are matched together to remove the
cover.
3
1
3
5
L
M
H
TIMER
POWER
during long time shipment) before use. If the sponge is not removed, the fan will
not work.
How to take the sponge off:
Place your two hands like the below image;
Rotate the cover anticlockwise with TWO hands at the same time gently
until the both lines on top of fan head are matched together to remove the
cover.
①
②
1 3 5 L M H
TIMER POWER
1 3 5 L M H
TIMER POWER
More to left
4
1 3 5 L M H TIMER POWER
4
1
3
5
L
M
H
TIMER
POWER
Press the cover tightly；
Place your two hands like the below image；
Rotate the cover clockwise with TWO hands gently at the same time until
the both lines on the top of the fan head are matched together and well
locked before use.
①
②
③
③
How to put the cover back:
Open the cover and take the sponge out.
More to right
1 3 5
L M H
Power Supply
Working Temperature -10℃~50℃ (14℉~ 122℉)
Storage Temperature -20℃~60℃ (-4℉~140℉)
Material ABS
Product Dimensions W*H*D: 180W×245H×74D mm
Cable Length 100cm（USB cable included）
Weight 0.33 kg
5
What’s in the box
If anything is missing in the packaging, please contact the seller.
Fan
USB cable
Sponge
User Manual
1
1
1
1
Adjustable Degree
TIMER
POWER
Timer off button :
press once : 5 Hours ( All indicator On ) ,
press twice : 3 Hours ( 1&3 indicators On ),
press thrice : 1 Hour ( 1 indicator On ),
press fourth turn off timer ( no indicator )
ON/OFF/wind speed mode control:
Fan speed indicator :
press once : Low indicator on,
press twice : Mid indicator on,
press thrice : High indicator on,
press fourth turn off the fan（no indicator）
USB cable port
Timer indicator
USB port / 4 D batteries (Not included)
Battery Type D Battery (Not included)
Up and down 350 degree
Fan speed indicator: Low - Mid - High
Note
1. This appliance is to be used with the power : 5v 1A power supply or 4pcs D
type battery ( not included ).
2. If power supply Less than 1A , fan speed will slow down.
3. This fan is designed to automatically slows down when fan input current is
less than normal operating current.
4. The battery can only be used if the ambient temperature is below 50℃. It is
strictly instructed to stop its usage in case the temperature rises above 50℃.
5. Remove the batteries if the fan is to be left unused for a long time (a month
or more.)
Caution: Remove the batteries only after disconnecting the USB power.
6. Avoid putting your fingers or any other objects into the fan to maintain your
safety.
7. Alkaline D battery and rechargeable D battery would be highly recommend for
environment protecting.
How to Clean
Front grille
6
1.Turn off the fan
2.Rotate the fan's front grille counterclockwise, and take off the front grille
3.Clean the fan grille and housing with dry clean cloth (The fan is not waterproof,
don't immerse it into water) after cleaned,assemble the front grille at clockwise
direction tightly
Notice: Cleaning and maintenance shall not be made by children without
supervision.
More to left
TECHNICAL DATA
Model No. : GMDF5
Power supply: DC 5V/ 1A
Power : 5W
Product Dimensions: 180(W)x245(H)x74(D)mm
Net Weight: 0.33kg
CAUTION
DOUBLE CIRCUIT PROTECTION
This marking indicates that this product should not be disposed with
other household wastes.
To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used device,
please use the return and collection systems or contact the retailer
where the product was purchased. They can take this product for
environmental safe recycling.
PCB over current : When the current is over 1A 5V, the fan will automatically
limits the current.
PCB under current : This fan is designed to automatically slows down when
fan input current is below than normal operating current.
7
重要安全事項
警告
注意：當使用此產品時，應遵循基本的安全預防措施，以減少火災，觸電和人身傷害
的風險，包括以下內容：
1.閱讀並保存此說明書。
2.檢查銘牌上標示的電壓。本產品應在DC 5V/1A 的電力供應中或4顆D號電蕊中使用。
3.兒童不得在沒有監督的情況下進行清潔和維護。
4.本產品只可與該產品所設置的供電裝置一起使用。
5.不正確的操作和不當的操作可能會導致設備故障和用戶受傷。
6.如果使用不當或操作不當，任何可能發生的損壞都不承擔任何責任。
7.如電線或插線位有損壞痕跡，則不要操作本產品。在這種情況下，如有必要，可將
本產品交給專業人員進行檢查和維修。
8.確保電源線不懸掛在有鋒利邊緣的地方。
9.防止本產品受潮，本產品不能被水濺濕。
10.不要讓8歲以下的兒童接觸到設備及電源線。
11.該產品請在平坦、乾燥的表面使用。
12.不要在有汽油、油漆或易燃液體的地方使用。
13.不要讓頭髮、窗簾、桌布、衣服或其他物品靠近風扇的入風口。他們有可能被吸進
風扇而造成損傷或受傷。
14.不要在浴室等潮濕地方使用該產品。
15.不要在窗戶上用該產品。
16.請按此手冊使用該產品。
17.不要試圖拆卸此產品進行維修，如果要維修，請將該產品送回我們的售後服務中心。
18.該產品所有部件不能隨意讓用戶自行替換。
8歲以上的兒童、身體、感觀、智力比較弱、欠經驗和知識的人仕，在經過指導說明
安全使用方法和知道可能的危險後，可以使用本機。兒童不可以把玩本產品，清潔
和維修不可給兒童處理。
此產品沒有可移除部件。請不要自行拆卸。
此產品切勿與任何固態速度控制裝置使用，以免造成火災和/或斷路危險。
禁止幼兒/兒童伸手指進風扇網內，以免發生危險傷害。
!
8
8歲以上的兒童、身體、感觀、智力比較弱、欠經驗和知識的人仕，在經過指導說明
安全使用方法和知道可能的危險後，可以使用本機。兒童不可以把玩本產品，清潔
产品部件
9
1 3 5 L M H TIMER POWER
定時按键
提手
開/關 按键
及風速按键
充电接口
注意：
當4顆D號電池都準備好放置時，從靠近按鈕的一側開始放置電池。如果沒有，則不能
放入電池儲存格
9
當4顆D號電池都準備好放置時，從靠近按鈕的一側開始放置電池。如果沒有，則不能
當4顆D號電池都準備好放置時，從靠近按鈕的一側開始放置電池。如果沒有，則不能
1 3 5 L M H
TIMER POWER
1 3 5 L M H
TIMER POWER
風速指示灯
定時指示灯
