GlobalSat TR-313

User Manual

TABLE OF CONTENTS

1. Warning.................................................................................................................... 3

2. Welcome.................................................................................................................. 4

3. Introduction and Features...................................................................................... 5

3.1 Introduction…………………………………………………………………………...5

3.2 LED Indicators................................................................................................. 6

4. Device Operation .................................................................................................... 7

4.1 Device charging……………………………………………………………………...7

4.2 SIM card Installation........................................................................................ 8

4.3 Power .............................................................................................................. 9

4.4 Emergency button...........................................................................................10

5. Contact Information...............................................................................................11

6. Safety Information .................................................................................................11

7. Limited Warranty....................................................................................................12

1. Warning

USE RESPONSIBLY. READ ALL INSTRUCTIONS AND

SAFETY INFORMATION BEFORE USE.

Globalsat Worldcom Corporation / USGlobalsat, Inc., will not accept any responsibility

whatsoever for accidents or violations of local Laws resulting from failure to observe

common sense precautions and local laws. Your personal judgment, traffic regulations,

and common sense must always take precedence over any directions produced by GPS

receiver or the mapping software.

Indemnification:

User agrees to defend, indemnify and hold harmless GlobalSat WorldCom Corp. and USGlobalsat,

Inc., its officers, directors, employees and agents against and from any third party claims, actions,

damages or demands, including but not limited to, reasonable legal and accounting fees, resulting from

user's use or misuse of this product, violation of these Terms, or any activities related to this product, or

from user's violations of the rights of any other user of this product. Use of this Product is at user's own

risk.

2. Welcome

Thank you for purchasing the GlobalSat TR-313. The TR-313 is a sleek, compact and

feature rich Personal / Personnel tracking device. In addition to its telemetry abilities, the

TR-313 unit incorporates a wide array of custom feature, functions and configurations for

unique client requirements. TR-313 is a versatile device which can be used for many

Personal & Personnel tracking applications. We appreciate your purchase of a GlobalSat

Worldcom Product!

3. Introduction and Features

3.1 Introduction

TR-313 is a 3G personal tracking device with fast GPS acquisition time. It is compact,

portable and stylish in design capable to connect both GSM and GPRS wireless networks.

Users can easily and remotely configure TR-313 and display GPS locations on remote

monitoring / tracking platforms.

3. Introduction and Features (Continued)

3.2 LED Indicators

Power Status LED

LED

Orange Constantly Lit

Red Constantly Lit

Red Blinking

Quickly

State

TR-313 is being

charged.

Battery power is low

USB configuration

mode

GSM LED

LED

Blinking Quickly

(Once every 200

millisecond)

Constantly Lit

Blinking Slowly

(Once every 1

seconds)

State

1. Data transmitting.

1. TR-313 is

searching for GSM

network

2. No SIM card

inserted

1. In Standby Mode,

network already

registered.

GPS LED

LED

Blinking Quickly

(Once per second)

Blinking Slowly

(Once every 3 seconds)

State

TR-313 is searching for GPS fix

TR-313 receives GPS fix

Bluetooth LED (Optional function)

LED

Blinking Quickly

Blinking Quickly (Once per

second)

State

Standby mode

Connecting to Bluetooth device

Note: The TR313 BLE-enabled devices must be an authorized and

pre-integrated TR-313 accessory in order to connect, not all BLE devices will

connect without pre-integration.

4. Device Operation

4.1 Device charging

Using the device for the first time, rechargeable battery will require a complete 100%

charge before TR-313 is operable. To maximize your device’s battery life, proceed by

performing the steps listed below.

1. Place the device on the charging cradle.

2. Connect the Micro USB side of the cable to the cradle port and connect the other

end of the cable to the designated AC power source (USB/AC adaptor).

3. Allow at least 6 hours of battery charging time.

4. Device Operation (Continued)

4.2 SIM Card Installation

1. Unscrew the SIM card cover.

2. Remove the cover.

3. With the metal contacts facing down, with the notch of the SIM card positioned to

your lower left side as seen in the above #3 image, place the SIM card onto the SIM

card compartment.

4. Replace the back cover in its original compartment and re-screw the cover.

Note: Before installing or taking out the SIM card, please power off the device.

4. Device Operation (Continued)

4.3 Power

1. To turn the device “ON”, press and hold the power button for 1 second.

2. To turn the device “OFF”, press and hold the power button for 3 seconds until the

device vibrates.

3. To perform a hard reset, press and hold the power button for 8 to 10 seconds.

4. For developers accessing COM port connection from the device, press the power

button once quickly while the device is sitting on the cradle with the USB cable

connected to PC.

4. Device Operation (Continued)

4.3 Emergency button

1. While pressing and holding the emergency button, TR-313 will send the emergency

SMS messages to pre-programmed phone numbers and continuously dial out to these

phones numbers until one phone call is picked up. Call rotary.

2. Once the emergency call is answered, the user and the contact may speak through the

hands-free speakerphone.

3. By default TR-313 allows the user to end a call by pushing the emergency button once.

4. Users may also answer incoming phone calls by pushing the emergency button once

when TR-313 exhibits ring tones.

Note: .Please contact Technical Support for programming emergency phone numbers.
