Global Technology Associates GBWA200501-01 Manuale utente

GB-Ware

SOFTWARE

Firewall

Product Guide

GBWA200501-01

GNAT Box

System Software

Except as permitted under copyright law, no part of this manual may be reproduced or distributed in any form or by any

means without the prior permission of Global Technology Associates, Incorporated.

Technical Support

GTA includes 30 days “up and running” installation support from the date of purchase. See GTA’s web site for more

information. GTA’s direct customers in the USA should call or email GTA using the telephone and email address below.

International customers should contact a local GTA authorized channel partner.

Tel: +1.407.380.0220 Email: [email protected]

Disclaimer

Neither GTA, nor its distributors and dealers, make any warranties or representations, either expressed or implied, as

to the software and documentation, including without limitation, the condition of software and implied warranties of its

merchantability or fitness for a particular purpose. GTA shall not be liable for any lost profits or for any direct, indirect,

incidental, consequential or other damages suffered by licensee or others resulting from the use of the program or

arising out of any breach of warranty. GTA further reserves the right to make changes to the specifications of the

program and contents of the manual without obligation to notify any person or organization of such changes.

Mention of third-party products is for informational purposes only and constitutes neither an endorsement nor a recom-

mendation for their use. GTA assumes no responsibility with regard to the performance or use of these products.

Every effort has been made to ensure that the information in this manual is accurate. GTA is not responsible for printing

or clerical errors.

Trademarks & Copyrights

GNAT Box, GB-Commander and Surf Sentinel are registered trademarks of Global Technology Associates, Incorporated.

RoBoX, GB-Ware and Firewall Control Center are trademarks of Global Technology Associates, Incorporated. Global

Technology Associates and GTA are registered service marks of Global Technology Associates, Incorporated.

Microsoft, Internet Explorer, Microsoft SQL and Windows are either trademarks or registered trademarks of Microsoft

Corporation in the United States and/or other countries.

Adobe and Adobe Acrobat Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the

United States and/or other countries.

UNIX is a registered trademark of The Open Group.

Linux is a registered trademark of Linus Torvalds.

BIND is a trademark of the Internet Systems Consortium, Incorporated and University of California, Berkeley.

WELF and WebTrends are trademarks of NetIQ.

Sun, Sun Microsystems, Solaris and Java are trademarks or registered trademarks of Sun Microsystems, Inc. in the

United States and other countries.

Java software may include software licensed from RSA Security, Inc.

Some products contain software licensed from IBM are available at http://oss.software.ibm.com/icu4j/.

SurfControl is a registered trademark of SurfControl plc. Some products contain technology

All other products are trademarks of their respective companies.

Global Technology Associates, Inc.

3505 Lake Lynda Drive, Suite 109 • Orlando, FL 32817 USA

Tel: +1.407.380.0220 • Fax: +1.407.380.6080 • Web: http://www.gta.com • Email: [email protected]

Table of Contents iii

Contents

1 INTRODUCTION ............................................................................................... 1

About GTA Firewalls ....................................................................................... 1

About GB-Ware ............................................................................................... 1

Features ..................................................................................................... 1

Additional Software Products ..................................................................... 2

Optional Features ....................................................................................... 2

Additional Options for 10-User Version ................................................... 2

Software Speciﬁcations .............................................................................. 3

Hardware Speciﬁcations ............................................................................. 3

System Requirements ............................................................................. 4

Optional Components ............................................................................. 5

Memory Recommendations .................................................................... 5

PPP Hardware ......................................................................................... 5

Support ............................................................................................................ 6

Support Options .......................................................................................... 6

Upgrades .................................................................................................... 7

About This Guide ............................................................................................ 7

Documentation Conventions ...................................................................... 7

Additional Documentation ........................................................................... 8

Mailing List .............................................................................................. 8

2 INSTALLATION ................................................................................................. 9

Registration ..................................................................................................... 9

Getting Your Activation Code ...................................................................... 9

Installing GB-Ware on PC Hardware ............................................................. 10

Requirements ............................................................................................. 10

Setup for GB-Ware Installation ................................................................... 11

Setting the Boot Sequence ..................................................................... 11

Installing the Compact Flash Card Reader or IDE Adapter ..................... 11

Selecting a GB-Ware Runtime ................................................................ 13

Selecting an Installation Disk .................................................................. 14

Installing the Runtime .............................................................................. 15

Completing Installation ............................................................................... 16

Attaching the Hardware Key Block .......................................................... 16

3 CONFIGURATION ............................................................................................. 19

Setting the Boot Sequence ............................................................................ 19

Loading the Correct Memory Slice (Partition) ............................................. 19

Selecting a User Interface .............................................................................. 19

Physically Connecting Your GB-Ware Firewall ............................................ 20

Requirements ............................................................................................. 21

Making a Temporary Peer Network Connection ......................................... 21

Making a Serial Connection ........................................................................ 23

Making a Video Connection ........................................................................ 23

Conﬁguring Your Firewall .............................................................................. 24

Requirements ............................................................................................. 24

Browser Compatibility ............................................................................. 24

Conﬁguration Using a Web Browser .......................................................... 25

Entering Your Network Information ......................................................... 26

GB-Ware Firewall Product Guideiv

Re-conﬁguring Your Computer ................................................................ 28

Accessing the Firewall ............................................................................ 28

Conﬁguration Using GBAdmin .................................................................... 29

Entering Your Network Information ......................................................... 30

Re-conﬁguring Your Computer ................................................................ 31

Accessing the Firewall ............................................................................ 31

Conﬁguration Using the Serial Console ...................................................... 31

Conﬁguration Using the Video Console ...................................................... 32

Video Console Navigation ....................................................................... 33

Using the Setup Wizard .......................................................................... 33

Accessing Your GTA Firewall .................................................................. 37

4 TROUBLESHOOTING ...................................................................................... 39

Troubleshooting Basics ................................................................................. 39

Frequently Asked Questions (FAQ) ............................................................... 39

APPENDIX .............................................................................................................. 47

Installing the Compact Flash Card ................................................................ 47

Requirements ............................................................................................. 47

Assembling the Compact Flash IDE Adapter ............................................. 48

Installing the Compact Flash IDE Adapter .................................................. 48

Locating IDE Controller Ports .................................................................. 48

Mounting the Compact Flash Card ......................................................... 49

Connecting the IDE Cable ....................................................................... 50

Connecting the Power Supply ................................................................. 50

Moving an Old Conﬁguration to GB-Ware .................................................... 50

Merging Conﬁgurations Using GBAdmin .................................................... 51

INDEX...................................................................................................................... 55

1 - Introduction 1

1 Introduction

About GTA Firewalls

Global Technology Associates, Inc. (GTA) has been designing and building

Internet ﬁrewalls since 1994. In 1996, GTA developed the ﬁrst truly

affordable commercial-grade ﬁrewall, the GNAT Box®. Since then, ICSA-

certiﬁed GNAT Box System Software has become the engine that drives all

GTA hardware appliance and software ﬁrewall systems.

About GB-Ware

GB-Ware is a complete software ﬁrewall system that runs from a Compact

Flash module or hard drive installed on x86 (PC) hardware. After software

installation, GB-Ware must be conﬁgured for local network requirements

using either the setup wizard (video console) or manually (serial console,

GBAdmin or browser).

Features

• 10/100/1000 Mbps Ethernet WAN/LAN speed support

• ICSA-certiﬁed GNAT Box System Software (version 3.5 and higher)

• Stateful packet inspection

• User authentication (GTA, LDAP & RADIUS)

• SSL encrypted management

• DES, 3DES, AES, and Blowﬁsh VPN encryption

• IPSec VPN with 1 mobile user license

• PPP, PPPoE and PPTP support

• SMTP email proxy

• Transparent NAT (network address translation)

• Async Modem and ISDN TA support

• RIP (Routing Information Protocol)

• Remote logging using WELF

• Gateway routing failover

• DMZ (PSN, Private Service Network; optional on 10 user version)

GB-Ware Firewall Product Guide2

• Dynamic DNS

• DNS proxy

• Transparent and traditional web proxy with script blocking

• DNS server (optional on 10 user version)

• DHCP server

• Web and GBAdmin user interfaces for remote management

• SNMP (read-only)

• Trafﬁc shaping (bandwidth limiting)

• NTP (network time protocol) server

Additional Software Products

• GTA Reporting Suite™ (ﬁrewall log reporting)

• GB-Commander™ (ﬁrewall management)

Optional Features

• VPN hardware acceleration

• Additional mobile VPN clients

• Surf Sentinel® content ﬁltering

• Mail Sentinel™ Anti-Spam email ﬁltering

• Mail Sentinel™ Anti-Virus email ﬁltering

• GTA-certiﬁed 512 MB Compact Flash disk

• Multi-Interface option (up to 20 network interfaces)

• Support contracts

Additional Options for 10-User Version

• 25, 50 or unlimited user license upgrades

• GB-Ware Plus Package (DNS Server and DMZ (PSN))

1 - Introduction 3

Software Specifications

Speciﬁcation GB-Ware 10 users GB-Ware unrestricted users

Concurrent connec-

tions (standard)

1,000 128,000

Concurrent out-

bound users (stan-

dard)

10 Unrestricted

Network interfaces

(standard)

2 3

User authentication 50 750

Address objects 50 600

Aliases 5 300

Pass-through hosts 10 300

Filters, outbound

& remote access

objects

75 400

Trafﬁc shaping

objects

5 50

Static outbound

maps

25 300

Static routes 10 300

Time groups 75 100

Tunnels 25 300

Protocols 255 255

URL access lists 10 300

Local content lists 25 250

DNS domains Optional 20

DNS hosts Optional 500

DNS networks Optional 80

VPN objects 5 100

VPN security asso-

ciations

20 600

Concurrent Mobile

VPN (max)

10 300

Hardware Specifications

The GB-Ware ﬁrewall is designed to operate efﬁciently on a broad spec-

trum of hardware, but the hardware you select will impact GB-Ware’s

performance. This is especially true when GB-Ware is used in an intranet

GB-Ware Firewall Product Guide4

conﬁguration with full network speeds on all interfaces. The best possible

performance can be obtained by using a Pentium class or higher CPU with

PCI network cards.

Network performance bottlenecks usually occur at the connection to the

Internet when using DSL or T1 class connectivity. GB-Ware with 10 Mbps

Ethernet cards easily provides enough throughput for network connectivity

of up to T1 speeds (1.5 Mbps). However, when the WAN connectivity is a

T3 or faster, GTA recommends that 100 Mbps network cards be used.

If you encounter problems, check your motherboard and IRQ assignments.

Make sure any unused devices, such as IDE and SCSI controllers, sound

cards and serial ports are disabled. Scan the hardware conﬁguration report

for error messages–often the cause of a problem is indicated in this report.

Note

Check gta.com for an up-to-date list of compatible network interface

cards and drivers.

System Requirements

• x86 architecture processor (Intel 486, Pentium, or Xeon; compatible

AMD or Cyrix CPUs); Pentium-class or faster CPU recommended

• 64 MB RAM (128 MB if using Mail Sentinel Anti-Virus and/or Mail

Sentinel Anti-Spam options)

• 512 MB ATA (IDE) compliant hard disk drive or 512 MB GTA-certi-

ﬁed Compact Flash card with Compact Flash IDE adapter

• 2 compatible network cards (NICs)

• 1 Serial (RS-232/COM) port

• 1 USB port or parallel (printer) port on the motherboard (for hard-

ware key block installation)

Note

PCI cards with USB or parallel ports will not function correctly. The

USB or parallel ports must be located directly “on-board” (as an

integrated part of the motherboard).

• 1 ATAPI (IDE) CD-ROM (installation and recovery only)

• 1 Video card, 1 monitor and 1 keyboard (for video console use only;

keyboard may not be required for operation if the motherboard’s

BIOS supports booting without a keyboard)

• Ethernet cables: crossover cables for connections to routers or

computers; straight-through sables for connections to hubs or

switches

For installation requirements, see page 10.

1 - Introduction 5

Optional Components

• 1-18 additional network cards (if using the Multi-Interface Option)

• Async modem (PPP connections or pager only)

• ISDN TA with RS-232 interface (PPP connections only)

• Cable modem

• Serial ports for COM 1-4 (1645x/1655x UARTs only)

Note

GTA recommends installing only the GB-Ware required or GB-Ware

optional components in the system. Devices such as SCSI controllers

and sound cards remain unused and may decrease performance.

Memory Recommendations

Adding RAM is an easy way to boost system performance. Using 64 MB

RAM, the physically possible maximum number of concurrent sessions is

32,765; using 128 MB RAM, the physically possible maximum is 128,000

connections. Generally, the more features that are being utilized (e.g. DNS

server or Mail Sentinel email proxy), the more RAM is recommended for

optimum performance.

Note

Some GB-Ware options may require additional RAM.

PPP Hardware

GNAT Box System Software supports the use of a PPP network connection

in place of a network interface card for the external network interface. The

PPP interface supports only a dial-up connection and a single remote system

conﬁguration. Once of the following should be used:

• An external asynchronous modem. COM ports 1-4 are supported;

only COM ports based on the 1645x/1655x UARTs are supported.

• An internal asynchronous modem. Only modems that use

1645x/1655x compliant UARTs are supported.

• An ISDN external modem/terminal adapter. COM ports 1-4 are

supported; only COM ports based on the 1645x/1655x compliant

UARTs are supported.

• Network interface card (NIC) for use with PPPoE (ADSL) or PPTP.

Serial Port Hardware

Most serial ports will easily support any asynchronous modem or a single

BRI 64Kbps ISDN connection. If both channels of a BRI line are used to

achieve 128Kbps, throughput may be limited to 115Kbps due to serial port

limitations.

GB-Ware Firewall Product Guide6

Modem/ISDN TA Hardware

GTA recommends conﬁguring the modem or ISDN TA on another system

before installing it on GB-Ware. Most modems allow the storage of a user

conﬁguration and the recall of this conﬁguration using a speciﬁc command

(e.g. ATZ). It is usually easiest to conﬁgure the modem before installa-

tion, and then to recall that conﬁguration and set the modem with a few

commands.

Note

The default conﬁguration for most modems will generally work with

GB-Ware.

You should conﬁgure the modem to use a ﬁxed DTE speed (the speed

at which the computer talks to the modem). If the modem supports DTE

speeds of 38,400 or 57,600 baud, use whichever of these values will ensure

the highest throughput. Conﬁgure your serial port to the highest possible

speed when using an ISDN TA. Unless you wish to connect at a speciﬁc

speed, set DCE (the speed at which the modem talks to a remote modem) to

auto-negotiate.

Cable Modems and xDSL Hardware

Cable modems and DSL (ADSL etc.) conﬁgurations utilize a passive inter-

connection device (cable modem, xDSL box) that is typically connected

to an Ethernet network interface card via a special network patch cable

(crossover cable).

Support

Installation ("up and running") support is available to registered users. If

you have registered your product and need installation assistance during

the ﬁrst 30 days, contact the GTA Support team by email to support@gta.

com. Include your product name, serial number, activation code, feature

activation code numbers for your optional/subscription features, and a

Conﬁguration Report (available in Reports under Conﬁguration in the web user

interface), if possible.

Installation support only covers installation and default conﬁguration of the

ﬁrewall. For further assistance, contact an authorized GTA Channel Partner

or GTA Sales staff for information about support offerings.

Support Options

If you need support after installation and default conﬁguration, a variety of

support contracts are available. Contact an authorized GTA Channel Partner

or GTA Sales staff for more information. Support ranges from support per

incident to annual contract coverage.

Questo manuale è adatto per i seguenti modelli

Indice

Manuali Software popolari di altre marche

COMPRO

COMPRO COMPROFM Manuale utente

Muratec

Muratec OFFICEBRIDGE ONLINE Manuale utente

Oracle

Oracle Contact Center Anywhere 8.1 Manuale utente

Adobe

Adobe 65007312 - Photoshop Lightroom Manuale

Avaya

Avaya NULL One-X for RIM Blackberry Manuale utente

HP ProLiant BL420c Manuale utente

PS Audio

PS Audio PowerPlay Manuale del proprietario

Brady

Brady LOCKOUT PRO 3.0 Manuale di servizio

Avaya

Avaya Interaction Center Manuale utente

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuale

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuale utente

Oracle

Oracle Application 9i Manuale utente

Acer

Acer RDM Manuale utente

Canon

Canon Vixia HF21 Manuale utente

Canon

Canon ZR950 Manuale utente

Samsung

Samsung Auto Backup Manuale utente

Polycom

Polycom Vortex EF2201 Istruzioni per l'installazione e il funzionamento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuale utente
