GOAL ZERO Lighthouse 600 Manuale utente
1
2
DEMO MODE
Take the Lighthouse 600 out of the current demo
mode by quickly turning the hand crank three times,
enough for the blue battery indicator to illuminate.
Getting Started
i. Get to Know Your Gear 2
ii. How It Works 5
Frequently Asked Questions 6
Technical Specifications 7
Français 9
Deutsch 17
Español 25
Italiano 33
日本語 41
1
Getting Started
i. Get to Know Your Gear 2
ii. How It Works 5
Frequently Asked Questions 6
Technical Specifications 7
Français 9
Deutsch 17
Español 25
Italiano 33
日本語 41
Table of Contents
2
GET TO KNOW YOUR GEAR
3
HANG IT
Put the Lighthouse 600 anywhere
with the built-in hanger.
CHARGE IT
Charge through any USB port, with the
dynamo crank, or with Goal Zero solar panels.
POWER IT
Use the USB port to recharge a
phone or boost a tablet.
LIGHT IT
Multiple brightness and directional lighting
options. Red light for emergencies.
STAND IT
Convenient foldaway legs for easy
transport and hassle-free storage.
4
Dynamo Crank
Recharge by dynamo crank function: flip the
crank handle up from the top of the lantern
and rotate. One minute of cranking will provide
approximately ten minutes of light on low power.
USB Rechargeable Light
Power up the Lighthouse 600 from any USB
port with the built-in cord. Blue LED lights
indicate battery level.
Dualite™ Directional Lighting
Turn the knob right or left for different
directional lighting and brightness options.
Emergency Light
Push the triangle button for red, emergency
alert mode.
Power Your Gear
Recharge smartphones, and boost tablets
through the USB port.
HOW IT WORKS
5
6
FREQUENTLY ASKED QUESTIONS
How often do I need to charge the Lighthouse 600?
It is recommended to charge your Lighthouse 600
lantern every 3 months. The blue LED lights indicate
the current battery level.
Does it matter what direction I turn the hand crank?
Nope. You can turn the hand crank in either direction
for power. Remember, 1 minute of crank time equals
about 10 minutes of light on low.
Charge times:
Nomad 10 7 hrs
USB Source 7 hrs
Run time:
One Side Lit (low power) 320 hrs
One Side Lit (high power) 5 hrs
Both Sides Lit (low power) 180 hrs
Both Sides Lit (high power) 2.5 hrs
Battery:
Cell Chemistry Li-ion NMC
Cell Capacity 18.7Wh (3.6V, 5200mAh)
Lifecycles Hundreds of cycles
Shelf-life Charge every 3-6 months
Fuses None
Management System Charging and low-battery
protection built-in
Light:
LED (output) 2x 5W warm white LED 600
Lumens
Color Temperature 3,200 Kelvin
7
Charge times:
Nomad 10 7 hrs
USB Source 7 hrs
Run time:
One Side Lit (low power) 320 hrs
One Side Lit (high power) 5 hrs
Both Sides Lit (low power) 180 hrs
Both Sides Lit (high power) 2.5 hrs
Battery:
Cell Chemistry Li-ion NMC
Cell Capacity 18.7Wh (3.6V, 5200mAh)
Lifecycles Hundreds of cycles
Shelf-life Charge every 3-6 months
Fuses None
Management System Charging and low-battery
protection built-in
Light:
LED (output) 2x 5W warm white LED 600
Lumens
Color Temperature 3,200 Kelvin
TECHNICAL SPECIFICATIONS
8
Hand Crank:
Hand Crank 1 W (cranking at 130 RPM)
1 minute of crank =
10 minutes of light on low
Ports:
USB Port (output) 5V, up to 1.5A (7.5W max),
regulated
USB Port (input) 5V, up to 1A (5W max)
General:
Weight 1.1 lbs (498 g)
Dimensions 4.5 x 5 x 6.5 in
(11.4 x 12.7 x 16.5 cm)
Operating Usage Temp. 32-104 F (0-40 C)
Certs
Warranty 12 months
Be sure to activate your warranty at
goalzero.com/warranty
TECHNICAL SPECIFICATIONS
