DT SERIES USER MANUAL

DT2 / DT2x/ DT4 / DT4x

USER MANUAL

VERSION

ISSUE DATE

P/N

: DT2 / DT4 series

: Rev. E

: 2013.06.25

: 920-014211-00

DT2 / DT4 series User Manual

FCC COMPLIANCE STATEMENT

FOR AMERICAN USERS

This equipment has been tested and found to comply with the limits for a CLASS A digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in

a commercial environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. Operation of this equipment

in a residential area is likely to cause harmful interference in which case the user will be

required to correct the interference at own expense.

EMS AND EMI COMPLIANCE STATEMENT

FOR EUROPEAN USERS

This equipment has been tested and passed with the requirements relating to

electromagnetic compatibility based on the standards EN55022:2010 Class A,

EN61000-3-2:006/A2:2009, EN61000-3-3:2008 and EN55024:1998/A1:2001/A2:2003, IEC

61000-4-2:2008 series, The equipment also tested and passed in accordance with the

European Standard EN55022 for the both Radiated and Conducted emissions limits.

DT SERIES

TO WHICH THIS DECLARATION RELATES

IS IN CONFORMITY WITH THE FOLLOWING STANDARDS

IEC 60950-1:2005(2nd Edition)+Am 1:2009, GB9254-2008 (Class A ) ; GB17625. 1-2003;

GB4943.1-2011, EN55022:2010 Class A, EN61000-3-2:006/A2:2009, EN61000-3-3:2008 and

EN55024:1998/A1:2001/A2:2003, IEC 61000-4-2:2008 series, UL 60950-1,2nd

Edtion,2007-03-27, UL 60950-1,1st Edition,2007-10-31, CSA C22.2 No.60950-1-07,2nd

Edition, 2007-03, CSA C22.2 No. 60950-1-03, 1st Edition, 2006-07, CFR 47, Part 15

WARNING

This is a Class A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take

adequate measures.

此为Class A产品，在生活环境中，该产品可能造成无线电干扰，在这种情况下，

可能需要用户对其干扰采取切实可行的措施。

DT2 / DT4 series User Manual

Safety instructions

Please read the following instructions carefully.

1. Keep the equipment away from humidity.

2. Before you connect the equipment to the power outlet, please check the voltage of the

power source.

3. Make sure the printer is off before plugging the power connector into the power jack.

4. It is recommended that you connect the printer to a surge protector to prevent possible

transient overvoltage damage.

5. Be careful not to get liquid on the equipment to avoid electrical shock.

6. For safety and warranty reasons, ONLY qualified service personnel should open the

equipment.

7. Do not repair or adjust energized equipment under any circumstances.

CAUTION

Danger of explosion if battery is incorrectly replaced

Replace only with the equivalent type recommended by the manufacturer.

Dispose of used batteries according to the manufacturer’s instructions.

Only use with power supply adapter model: WDS060240P (9A).

Changes or modifications not expressly approved by the party responsible for compliance could

void the user's authority to operate the equipment.

Specifications are subject to change without notice.

DT2 / DT4 series User Manual

1. BARCODE PRINTER........................................................................................ 1

1-1. Box content.........................................................................................................................1

1-2. Specifications......................................................................................................................1

1-3. Getting to know your printer............................................................................................7

2. PRINTER SETUP............................................................................................. 9

2-1. Loading the label roll.........................................................................................................9

2-2. Installing the label roll holder........................................................................................ 11

2-3. Connecting the printer to the host computer........................................................... 12

2-4. Installing the driver.......................................................................................................... 13

3. OPERATOR PANEL ....................................................................................... 15

3-1. FEED button...................................................................................................................... 15

3-2. LED status.......................................................................................................................... 15

3-3. Label size calibration...................................................................................................... 15

3-4. Self test .............................................................................................................................. 16

3-5. Error alerts ......................................................................................................................... 17

4. NETSETTING FOR ETHERNET ......................................................................... 18

4-1. Installing the NetSetting software ................................................................................ 18

4-2. The interface of NetSetting........................................................................................... 19

5. ACCESSORIES.............................................................................................. 26

5-1. Installing the label dispenser......................................................................................... 26

5-2. Installing the cutter ......................................................................................................... 29

6. MAINTENANCE AND ADJUSTMENT ............................................................ 32

6-1. Cleaning the print head................................................................................................ 32

6-2. Adjusting the cutter........................................................................................................ 32

6-3. Labels with black marks................................................................................................. 33

A. Printer interfaces................................................................................................................ 35

DT2 / DT4 series User Manual

1. Barcode printer

1-1. Box content

Please check that all of the following items are included with your printer:

Barcode printer

Power cord

AC adapter

USB cable

Label stock

Quick reference guide

CD (with QLabel label software / user manual)

DT2 series DT4 series

1-2. Specifications

Model

DT2

DT4

Print Method

Direct Thermal

Resolution

203 dpi (8 dot/mm)

Print Speed

4 IPS (102 mm/s)

Print Width

2.12” (54 mm)

4.25” (108 mm)

Print Length

Min. 0.16” (4 mm)** ; Max. 68” (1727 mm)

Processor

32 Bit RISC CPU

Memory

4MB Flash (2MB for user storage) ;

16MB SDRAM

8MB Flash (4MB for user storage) ;

16MB SDRAM

Sensor Type

Adjustable reflective sensor. Fixed transmissive sensor, central aligned

Media

Types: Continuous form, gap labels, black mark sensing, and punched

hole; label length set by auto sensing or programming

Width: 0.6” (15 mm) Min. - 2.36” (60

mm) Max.

Thickness: 0.003” (0.06 mm) Min. -

0.008” (0.20 mm) Max.

Label roll diameter: Max. 5” (127

mm)

Core diameter: 1”, 1.5” (25.4 mm,

38.1 mm)

Width: 1” (25.4 mm) Min. - 4.64” (118

mm) Max.

Thickness: 0.003” (0.06 mm) Min. -

0.008” (0.20 mm) Max.

Label roll diameter: Max. 5” (127

mm)

Core diameter: 1”, 1.5” (25.4 mm,

38.1 mm)

Printer Language

EZPL, GEPL, GZPL, auto switch

Software

Label design software: GoLabel (for EZPL only)

Driver: Windows 2000, XP, Vista, 7, 8 , Windows Server 2003 & 2008

DLL: Windows 2000, XP and Vista

DT2 / DT4 series User Manual

Resident Fonts

Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B

Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270°

rotatable

Bitmap fonts 8 times expandable in horizontal and vertical directions

Scalable fonts 90°, 180°, 270° rotatable

Download Fonts

Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270°

rotatable

Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in

horizontal and vertical directions

Scalable fonts 90°, 180°, 270° rotatable

Barcodes

1-D Bar codes:

Code 39, Code 93, EAN 8 /13 (add on 2 & 5), UPC A/E (add on 2 & 5), I 2

of 5 & I 2 of 5 with Shipping Bearer Bars,

Codabar, Code 128 (subset A, B,

C), EAN 128, RPS 128, UCC 128, UCC/EAN-128 K-Mart, Random Weight,

Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM and

GS1 DataBar

2-D Bar codes:

PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR

code and Aztec code

Code Pages

CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869,

737

WINDOWS 1250, 1251, 1252, 1253, 1254, 1255, 1257

Unicode (UTF8, UTF16)

Graphics

Resident graphic file types are BMP and PCX, other graphic formats are

downloadable from the software

Interfaces

USB Device (B-Type)

Serial port: RS-232 (DB-9)

IEEE 802.3 10/100Base-Tx Ethernet port (RJ-45)

Control Panel

One Tri-color LED: Power (Green, Orange and Red)

Control key: FEED

Real Time Clock

Standard

Power

Auto Switching 100-240VAC, 50-60Hz

Environment

Operation temperature: 41°F to 104°F (5°C to 40°C)

Storage temperature: -4°F to 122°F (-20°C to 50°C)

Humidity

Operation: 30-85%, non-condensing.

Storage: 10-90%, non-condensing.

Agency

Approvals

CE(EMC), FCC Class A, CB, cUL, CCC

Dimension

Length: 8.58” (218 mm)

Height: 6.77” (172 mm)

Width: 3.94” (100 mm)

Length: 8.58” (218 mm)

Height: 6.53” (166 mm)

Width: 6.61” (168 mm)

Weight

2.65 lbs (1.2Kg) ,excluding

consumables

3.3 lbs (1.5Kg) ,excluding

consumables

Options

Cutter Module

Label Dispenser

External label roll holder for 10” (250 mm) O.D. label rolls

External label rewinder

* Specifications are subject to change without notice. All company and/or product names are trademarks and/or

registered trademarks of their respective owners.

** Minimum print height and maximum print speed specification compliance can be dependent on non-standard

material variables such as label type, thickness, spacing, liner construction, etc. Godex is pleased to test

non-standard materials for minimum print height and maximum print speed capability.

DT2 / DT4 series User Manual

Model

DT2x

Print Method

Direct Thermal

Resolution

203 dpi (8 dot/mm)

Print Speed

7 IPS (177 mm/s)

Print Width

2.12” (54 mm)

Print Length

Min. 0.16” (4 mm)** ; Max. 68” (1727 mm)

Processor

32 Bit RISC CPU

Memory

4MB Flash (2MB for user storage) ; 16MB SDRAM

Sensor Type

Adjustable reflective sensor. Fixed transmissive sensor, central aligned

Media

Continuous form, black mark sensing, and punched hole; label length

set by auto sensing or programming

Width: 0.6” (15 mm) Min. - 2.36” (60 mm) Max.

Thickness: 0.003” (0.06 mm) Min. - 0.008” (0.20 mm) Max.

Label roll diameter: Max. 5” (127 mm)

Core diameter: 1”, 1.5” (25.4 mm, 38.1 mm)

Printer Language

EZPL, GEPL, GZPL, auto switch

Software

Label design software: GoLabel (for EZPL only)

Driver: Windows 2000, XP, Vista, 7, 8 , Windows Server 2003 & 2008

DLL: Windows 2000, XP and Vista

Resident Fonts

Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B

Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270°

rotatable

Bitmap fonts 8 times expandable in horizontal and vertical directions

Scalable fonts 90°, 180°, 270° rotatable

Download Fonts

Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270°

rotatable

Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in

horizontal and vertical directions

Scalable fonts 90°, 180°, 270° rotatable

DT2 / DT4 series User Manual

Model

DT2x

Barcodes

1-D Bar codes:

Code 39, Code 93, EAN 8 /13 (add on 2 & 5), UPC A/E (add on 2

& 5), I 2

of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B,

C), EAN 128, RPS 128, UCC 128, UCC/EAN-128 K-Mart, Random Weight,

Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM and

GS1 DataBar

2-D Bar codes:

DF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR

code and Aztec code

Code Pages

CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869,

737

WINDOWS 1250, 1251, 1252, 1253, 1254, 1255, 1257

Unicode (UTF8, UTF16)

Graphics

Resident graphic file types are BMP and PCX, other graphic formats are

downloadable from the software

Interfaces

USB Device (B-Type)

Serial port: RS-232 (DB-9)

IEEE 802.3 10/100Base-Tx Ethernet port (RJ-45)

Control Panel

One Tri-color LED: Power (Green, Orange and Red)

Control key: FEED

Real Time Clock

Standard

Power

Auto Switching 100-240VAC, 50-60Hz

Environment

Operation temperature: 41°F to 104°F (5°C to 40°C)

Storage temperature: -4°F to 122°F (-20°C to 50°C)

Humidity

Operation: 30-85%, non-condensing.

Storage: 10-90%, non-condensing.

Agency

Approvals

CE(EMC), FCC Class A, CB, cUL, CCC

Dimension

Length: 8.58” (218 mm)

Height: 6.77” (172 mm)

Width: 3.94” (100 mm)

Weight

2.65 lbs (1.2Kg) ,excluding consumables

Options

Cutter Module

Label Dispenser

External label roll holder for 10” (250 mm) O.D. label rolls

External label rewinder

* Specifications are subject to change without notice. All company and/or product names are trademarks and/or

registered trademarks of their respective owners.

** Minimum print height and maximum print speed specification compliance can be dependent on non-standard

material variables such as label type, thickness, spacing, liner construction, etc. Godex is pleased to test

non-standard materials for minimum print height and maximum print speed capability.

DT2 / DT4 series User Manual

Model

DT4x

Print Method

Direct Thermal

Resolution

203 dpi (8 dots/mm)

Print Speed

7 IPS (177 mm/s)

Print Width

4.25” (108 mm)

Print Length

Min. 0.16” (4 mm)** ; Max. 68” (1727 mm)

Processor

32 Bit RISC CPU

Memory

8MB Flash (4MB for user storage); 16MB SDRAM

Sensor Type

Adjustable reflective sensor. Fixed transmissive sensor, central aligned

Media

Types: Continuous form, gap labels, black mark sensing, and punched

hole; label length set by auto sensing or programming.

Width: 1” (25.4 mm) Min. - 4.64” (118 mm) Max.

Thickness: 0.003” (0.06 mm) Min. - 0.008” (0.2 mm) Max.

Label roll diameter: Max. 5” (127 mm)

Core diameter: 1”, 1.5” (25.4 mm, 38.1 mm)

Printer Language

EZPL, GEPL, GZPL auto switch

Software

Label design software: GoLabel (for EZPL only)

Driver: Windows 2000, XP, Vista, 7, Windows Server 2003 & 2008

DLL: Windows 2000, XP and Vista

Resident Fonts

Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B

Bitmap fonts 0°, 90°, 180°, 270° rotatable, single characters 0°, 90°, 180°,

270° rotatable

Bitmap fonts 8 times expandable in horizontal and vertical directions

Scalable fonts 0°, 90°, 180°, 270° rotatable

DT2 / DT4 series User Manual

Model

DT4x

Download Fonts

Bitmap fonts 0°, 90°, 180°, 270° rotatable, single characters 0°, 90°, 180°,

270° rotatable

Asian fonts 0°, 90°, 180°, 270° rotatable and 8 times expandable in

horizontal and vertical directions

Scalable fonts 0°, 90°, 180°, 270° rotatable

Barcodes

1-D Bar codes:

Code 39, Code 93, EAN 8 /13 (add on 2 & 5), UPC A/E (add on 2 & 5), I 2

of 5 & I 2 of 5 with Shipping Bearer Bars,

Codabar, Code 128 (subset A, B, C), EAN 128, RPS 128, UCC 128,

UCC/EAN-128 K-Mart, Random Weight,

Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey,

Telepen, FIM, GS1

DataBar

2-D Bar codes:

PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR

code and Aztec code

Code Pages

CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869,

737

WINDOWS 1250, 1251, 1252, 1253, 1254, 1255, 1257

Unicode (UTF8, UTF16)

Graphics

Resident graphic file types are BMP and PCX, other graphic formats are

downloadable from the software

Interfaces

USB Device (B-Type)

Serial port: RS-232 (DB-9)

IEEE 802.3 10/100Base-Tx Ethernet port (RJ-45)

RTC

Standard

Control Panel

One Tri-color LED: Power (Green, Orange and Red)

Control key: FEED

Power

Auto Switching 100-240VAC, 50-60Hz

Environment

Operation temperature: 41°F to 104°F (5°C to 40°C)

Storage temperature: -4°F to 122°F (-20°C to 50°C)

Humidity

Operation: 30-85%, non-condensing.

Storage: 10-90%, non-condensing.

Agency

Approvals

CE EMC, FCC Class A, CB, cUL

Dimension

Length: 8.58” (218 mm)

Height: 6.53” (166 mm)

Width: 6.61” (168 mm)

Weight

3.3 lbs (1.5Kg) ,excluding consumables

Options

Cutter Module

Label Dispenser

External label roll holder for 10” (250 mm) O.D. label rolls

External label rewinder

* Specifications are subject to change without notice. All company and/or product names are trademarks and/or

registered trademarks of their respective owners.

** Minimum print height and maximum print speed specification compliance can be dependent on non-standard

material variables such as label type, thickness, spacing, liner construction, etc. Godex is pleased to test

non-standard materials for minimum print height and maximum print speed capability.

Altri manuali per DT2

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Godex Lettore di codici a barre

Manuali Lettore di codici a barre popolari di altre marche

POSMicro

POSMicro Datalogic PowerScan D7100 Manuale utente

Marson

Marson MT780 Guida rapida alla configurazione

NCR

NCR RealPOS Manuale utente

Motorola

Motorola SE3300 Guida rapida alla configurazione

Element

Element P130BT Manuale utente

Motorola

Motorola Symbol LS3008 Manuale di installazione e funzionamento

Meec tools

Meec tools OBD-II / VAG Manuale utente

SICK

SICK CLP 100 Manuale utente

Royal Tag SA

Royal Tag SA I-Read Manuale utente

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manuale utente

Meteor

Meteor 8310 Manuale utente

Denso

Denso BHT-500B Manuale utente

Datalogic

Datalogic Heron HD3130 Manuale utente

Motorola

Motorola MP6000 Istruzioni di montaggio

Newland

Newland NLS-HR15-BT Manuale utente

ARTDEV

ARTDEV AS-1310 Manuale utente

Aopos

Aopos AS290 Manuale utente

ENS

ENS 367-5455 Manuale utente
