Goodmans GCR1888DABBT Manuale utente
GCR1888DABBT
ENTER
SNOOZE
MENU
PRESET
VOL
VOL
/MODE
2
Introduction
Thank you for buying this GOODMANS Digital Radio. The following instructions
will assist you in operating all the features of this product.
You may already be familiar with using a similar unit, but please take the time
to read the instructions relevant for your model.
Your safety is very important, so please ensure you read the safety instructions
before you operate this unit.
If you need help setting up or using your Digital Radio, please contact our UK
call centre on 0871 230 1777, or alternatively refer to our support section
at www.goodmans.co.uk.
01
02
03
04
05
06
...........................................................................4
Your DAB Radio.................................................................................5
What Is DAB.....................................................................................6
Getting Started .................................................................................7-8
Operating Instructions.......................................................................9-12
Troubleshooting/Specifications.........................................................13
......................................................................................... 14
Safety Instructions
Guarantee
3
Contents
07
Cleaning
Disconnect the unit from the mains supply before cleaning.
Do not use any liquids or aerosol cleaners, as this may damage the unit.
Use a soft, dust free cloth.
Servicing
There are no user serviceable parts in the unit. When servicing, refer to
qualified service personnel.
Consult your dealer if you are ever in doubt about the installation/operation/
safety of the product.
Safety Instructions
01
Please ensure that you read all of the safety instructions before using
this unit.
Position the power cable and other connected cables so that they are not
likely to be walked on, pinched or where items can be placed on or against them.
Do not use the unit in humid or damp conditions.
Do not allow the unit to get wet.
Never allow children to insert foreign objects into holes or slots on the unit.
The ventilation should not be impeded by covering the openings with items
such as news-papers, tablecloths, curtains, etc.
No naked flame sources, such as lit candles, should be placed on the unit.
Do not expose the unit to dripping or splashing and no objects filled with
liquids, such as vases, should not be placed on the unit.
Do not place the unit in closed bookcases or racks without proper ventilation.
Safety Considerations
4
11 12 13 14 15
10
21 345 6 78 9
Your DAB+ Radios
Top view
Back view
Your DAB Radio 02
5
Front view
2/4. /
Press to previous/next music or
selection.
Press to tune the radio.
3.ENTER
Press to confirm the selection.
Play/ Pause in Bluetooth mode.
5.SNOOZE
Press to enter SNOOZE mode.
Press to adjust the backlight.
Press and hold to set alarm.
6.MENU
Press to view channel/time/
date/RDS.
7/8.VOL-/VOL+
Press to adjust the volume level.
9.PRESET
Press to store and preset radio
stations.
10.DISPLAY
LED display showing all
information on the radio.
11.ANTENNA
The radio comes with a pigtail antenna.
Adjust the antenna for best reception.
12. (HEADPHONE)
You can connect your headphone
to this unit for personal listening.
13.USB PORT
For Mobile phone charge.
14.DC 5V IN
Use this to the enclosed DC power
supply.
15.AUX IN
Use 3.5mm audio cable to
connect to audio device.
1.
Press to turn on the product, press
and hold to go to STANDBY mode.
Press to switch DAB, FM, Bluetooth,
AUX IN mode when the power is on.
MENU
SNOOZE PRESETENTER VOL VOL
/MODE
/MODE
R
Bluetooth
Digital DAB was developed in Europe by a consortium of broadcasters and
manufactures. DAB uses digital compression techniques to transform the
source material, i.e. music and speech, into better quality audio.
Analogue systems suffer from an effect called "multipath distortion". This is
caused because waves do not behave in a orderly fashion, but bounce and
reflect off buildings etc. DAB sees this as an advantage and uses the direct
and reflected signals to actually reinforce the end result, allowing for better
service most of the time.
A signal DAB frequency can be used to cover the whole of U.K., solving
many of the problems experienced with the earlier analogue DAB scan
automatically tunes in all of the available stations in your area.
Broadcasters can transmit text to your radio, this way you can read the name
of the DJ, Artist, song title or any other information they choose.
Check your local coverage at www.getdigitalradio.com to check if you are in a
DAB broadcast area.
Interference free reception
No need to re-tune
Scrolling Test
DAB Coverage
What Is DAB
03
6
Carefully remove your DAB receiver from the box (we recommend you keep
the package for future reference).
Getting Started
7
04
Connect the power adaptor provided
to the unit and then connect to you wall
outlet and turn on the power.
Connect the power Extend the telescopic aerial
12
Extend the antenna aerial for the
best reception possible.
Turning on the radio
3
1.Press the button to turn on the radio.
2.Press the button and hold to enter STANDBY mode.
Note:
1.This unit is designed to enter STANDBY mode automatically after
15 minutes of inactivity. Press the button to wake the unit.
2.It is recommended that the unit is switched off and adapter is removed
from the power outlet during storms or if being left unused for long
periods of time.
MENU
SNOOZE PRESETENTER VOL VOL
/MODE
/MODE
/MODE
/MODE
Connect your headphones to the 3.5mm
headphone socket on the back of the unit as shown above.
Adjust the volume level by pressing the VOL+ button to
increase the volume or decrease the volume by pressing
the VOL- button.
Changing the volume
Getting Started
04
Connecting headphones
4
5
8
MENU
SNOOZE PRESETENTER VOL VOL
/MODE
9
Operating Instructions 05
Please make sure your unit is switched on.
Press the button to select the DAB radio mode.
Press the and buttons to scroll through the stations in the station list.
To scan for all new stations or to rescan for weak stations, please go to the Full Scan function,
then the radio will scan and store all available stations. We recommend scanning for new
stations every so often to pick up any newly launched digital radio stations.
<
<
<
<
1
2
3
4
Playing your DAB radio
You can store up to 10 DAB station presets for easy playback.
Select the station you wish to preset, press and hold the PRE-SET button until
the display shows, then release the button.
Using the and buttons choose the preset number(1-10) you wish to use, then
press the ENTER button to store the station.
Repeat this access to preset all 10 stations.
<
<
<
<
1
2
3
4
Storing a station preset
Recalling a station preset
Press the PRESET button and use the and buttons to select your desired pre-set station.
(This is to override any station you have pre-set which you no longer set in your list)
Press the ENTER button to play the station.
<
<
<
<
1
2
Using the menu in DAB mode
Press the MENU button to view the radio information.
/MODE
Operating Instructions
05
10
Press and hold the MENU button to enter the main menu, press the and buttons to
scroll through the options listed: Full scan, Manual tune, DRC, Prune, Alarm set, Sleep set,
Reset and SW version. After that press ENTER to select.
<Full scan>
In the main menu, use the navigation buttons to select the Full scan menu.
Press the ENTER button to confirm and the unit will perform a Full scan and store all
available DAB stations.
1
2
1
2
3
4
You can also choose to manually scan for your favourite DAB station to obtain optimum
reception.
In the main menu, use the navigation buttons to select the manual tune menu.
Press the ENTER button to confirm.
Use the navigation buttons to scroll through the available frequencies.
Press the ENTER button to confirm and play.
You can also press and hold the ENTER button to enter the Manual tune mode directly and
then repeat the step 2~4.
<Manual tune>
<DRC>
Dynamic range control (DRC) adds or removes a degree of compensation for the
differences in the dynamic range between radio stations.
Press the MENU button to access the main menu.
Press the and buttons until DRC is displayed.
Press the ENTER button to confirm.
Using the and buttons to select off, low or high to prune and then press the
ENTER button to confirm.
<
<
<
<
<
<
<
<
1
2
3
4
<Prune>
If your station list includes that you can no longer receive, you can select the Prune
option to remove any stations that can no longer be received form the station list.
Press the MENU button to access the main menu.
Press the and buttons until Prune is displayed.
Press the ENTER button to confirm.
Use the and buttons to select Yes or No to prune and then press the ENTER
button to confirm.
<
<
<
<
<
<
<
<
1
2
3
4
<
<
<
<
