Grace Company QuiltMotion Manuale utente
QuiltMotion
Frame Assembly Instructions
Copyright June 25, 2020
Grace Company
(Reproduction Prohibited)
Version 1.2
ii
?
X
Warranty
1-800-264-0644
Warranty Information for your QuiltMotion.
The QuiltMotion has a One-Year limited warranty on all parts. The Grace Company will repair or replace,
at its discretion, any part with problems due to our manufacturing or defects in materials. This warranty
does not cover parts damaged through misuse, improper storage, improper assembly, loss, natural
events, and willful destruction. Parts must be returned to the Grace Company, shipping prepaid, before
we can repair or replace them. We will promptly return the repaired/replaced part at our expense if done
within a year of the purchase date.
|Warranty QuiltMotion
iii
|Choose your Frame QuiltMotion
Continuum Frame
Turn to page 1 Q-Zone Queen Frame
Turn to page 20
Q-Zone Hoop-Frame
Turn to page 37 Q’nique Frame
Turn to page 54
Choose your Frame from the images below.
Proceed to the page number associated with your
Frame.
iv
|Choose your Frame QuiltMotion
GQ Frame
Turn to page 71
Bernina & Bernina V2
Turn to page 118
SR2 & SR2+ Frames
Turn to page 97
Majestic Frame
Turn to page 134
Pinnacle Frame
Turn to page 71 Next Generation Frame
Turn to page 71
v
GMQ Pro Frame
Turn to page 151 Little Gracie II Frame
Turn to page 151
|Choose your Frame QuiltMotion
Gracie King/Queen Frame
Turn to page 169
B
A
vi
Part Name
(quantity) Part Name
(quantity)
Part Name
(quantity) Part Name
(quantity)
Part Name
(quantity) Part Name
(quantity)
Part Name
(quantity) Part Name
(quantity)
Part Name (quantity)
Part Name
(quantity) Part Name
(quantity)
Part Name (quantity)
Part Name
(quantity) Part Name
(quantity)
|Parts List Box 1 QuiltMotion
Motor Plate
Clamp (5)
Back Belt
Clamp (2)
Q-Zone Hoop-
Frame QM Belt
Bracket (2)
Majestic QM Belt
Bracket Left (1) Majestic QM Belt
Bracket Right (1)
SR2 & SR2+ QM
Belt Bracket (2) Wood Frame QM
Belt Bracket (2)
Next Generation
QM Belt Bracket (2)
Motor Plate (1)
Continuum QM
Belt Bracket (2)
Q-Zone Queen QM
Belt Bracket (2)
Top Belt Bracket (1)
Belt Tensioner (2) Front Belt
Clamp (2)
vii
|Parts List Box 1 QuiltMotion
QCT Bracket
Q’nique 15 (1)
QCT Bracket
Q’nique 19 (1) QCT Bracket
Q’nique 21 (1) QCT Angle Support
Bracket (1)
Long Belt (1) Short Belt (1)
QCT Top Plate
U-Bracket (1)
Tablet Tray (1)
Power Strip
(1)
M6 Knob (1)
QCT Bracket
Top Plate (1)
viii
|Parts List Box 1 QuiltMotion
M6 x 40mm
SBHCS (2) M6 x 25mm
SBHCS (6)
M5 x20mm
SBHCS (4) M5 x 10mm
SBHCS (8)
M6 x 20mm
SBHCS (7)
M5 x 35mm
SBHCS (1)
M6 x 10mm
SBHCS (8)
M6 x 40mm
Hex Bolt (6)
M6 x 20mm
Hex Bolt (4) M6 x 10mm
Hex Bolt (4) Hex Nut M6 (15)
M6 Metal
Spacer (2) M6 Plastic
Spacer (2)
2.5mm Allen
Wrench (1) 3mm Allen
Wrench (1) 4mm Allen
Wrench (1)
2mm Allen
Wrench (1)
10mm &
13mm Box End
Wrench (1)
M6 x 25mm
Hex Bolt (2)
ix
|Parts List Box 1 QuiltMotion
Stylus (1)
6P/6C QuiltMotion
Cable (1) 7’ QuiltMotion
USB Cable (1) Male to Male USB
Adapter Cable (1) Q’nique to
QuiltMotion USB (1)
Sewing Cable (Juki
2000Q/2010Q) (1)
Sewing Cable
(Juki 98) (1) Sewing Cable 3
Prong (Janome) (1)
Zip Tie Mount (6)
Velcro Strips (6)
Zip Tie (8) Cable Wrap (1)
Software Box (1) Cloth (1) Long Arm Sewing
Board (1) Short Arm Sewing
Board (1)
1
|Continuum Frame QuiltMotion
Bottom Carriage
Step 1: Motor Plate Installation: ........................................................................................page 2
Step 2: Power Strip Installation: ........................................................................................ page 3
Top Belt Bracket
Step 3a: Short Belt Installation - Q’nique 15” & 19”............................................................. page 5
Step 3b: Short Belt Installation - Q’nique 21”......................................................................page 7
Step 3c: Short Belt Installation - Top Plate .........................................................................page 9
Continuum Frame
Step 4: Long Belt Installation...........................................................................................page 10
Step 5: Aligning the Belts ................................................................................................page 16
|Table of Contents Continuum
