~5~ ~6~
CONNECT TO GWN7615 DEFAULT Wi-Fi NETWORK
GWN7615 can be used as standalone access point out of box, or after
factory reset with Wi-Fi enabled by default.
After powering the GWN7615 and connecting it to the network, GWN7615
will broadcast a default SSID based on its MAC address GWN[MAC’s
last 6 digits] and a random password.
Note: GWN7615’s default SSID and password information are printed
on the MAC tag of the unit.
A computer connected to the GWN7615’s SSID, or to the same network
as the GWN7615 can discover and access its conguration interface us-
ing one of the below methods:
Method 1: Discover GWN7615 using its MAC Address
1. Locate the MAC address on the MAC tag of the unit, which is on the
underside of the device, or on the package.
2. From a computer connected to same network as the GWN7615, type
in following address using GWN7615’s MAC address on your brows-
er: https://gwn_<mac>.local
Example: If a GWN7615 has the MAC address C0:74:AD:8B:4E:28, this
unit can be accessed by typing https://gwn_c074ad8b4e28.local on the
browser.
Method 2: Discover GWN7615 using GWN Discovery Tool
1. Download and install GWN Discovery Tool from the following link:
http://www.grandstream.com/tools/GWNDiscoveryTool.zip
2. Open the GWN DiscoveryTool, and click on Scan.
ACCESSING THE CONFIGURATION INTERFACE
This device has not been authorized as required by
the rules of the Federal Communications Commission.
This device is not, and may not be,
offered for sale or lease, or sold or leased,
until authorization is obtained.
GWN7615
48V 0.5A GigE POE
WiFi
Enter username and password to login. (The default administrator user-
name is “admin” and the default random password can be found at the
sticker on the GWN7615).
●Make sure that the GWN7615 is not already paired with another
GWN76xx Access Point as slave, GWN7000 Router Series or GWN.
Cloud, otherwise the conguration interface cannot be accessed
● If the GWN7615 is already paired, make sure to unpair it rst, or do
a factory reset.
●It is customer’s responsibility to ensure compliance with local regula-
tions for frequency bands, transmit power and others.
●To manage GWN7615 over cloud, please refer to https://www.gwn.
cloud.
The GNU GPL license terms are incorporated into the device rmware and can
be accessed via the Web user interface of the device at my_device_ip/gpl_li-
cense. It can also be accessed here:
http://www.grandstream.com/legal/open-source-software
To obtain a CD with GPL source code information please submit a written re-
Refer to online documents and FAQ for more detailed information:
http://www.grandstream.com/our-products
Notes:
3. The tool will discover all GWN76XX Access Points connected on
the network showing their MAC and IP addresses.
4. Click on Manage Device to be redirected directly to the GWN7615’s
conguration interface, or type in manually the displayed IP address
on your browser.
