Grundig MT 6830 Manuale utente
4 IN 1 BEARD
AND CONTOUR
HAIR TRIMMER
MT 6830
2
_________________________________________________________
A
B
F
C
D
E
G
H
I
J
3
_________________________________________________________
DEUTSCH 4- 16
ENGLISH 17 - 27
FRANÇAIS 28 - 38
ITALIANO 39 - 49
PORTUGUÊS 50 - 60
ESPAÑOL 61 - 71
POLSKI 72 - 82
ČESKY 83 - 93
TÜRKÇE 94 - 104
ΕΛΛΗΝΙΚA 105 - 115
ENGLISH 17
SAFETY_______________________________________________
Please note the following instructions
when using the appliance:
7The appliance is designed for
domestic use only.
7Observe these instructions in
order to prevent damage to the
appliance or danger arising
from improper use. Keep them
in a safe place.
7Never use the appliance in the
bath, shower or over a wash
basin filled with water; nor
should it be operated with wet
hands.
7Do not immerse the appliance in
water or let it come into contact
with water, even during
cleaning.
7Do not drop the appliance.
7Pull out the power supply unit
after use.
7If not already present, for addi-
tional protection it is recommend
to install a residual-current-oper-
ated protective device (RCD)
with a rated residual operating
current not exceeding 30 mA in
the electrical circuit of your bath-
room. Ask your plumber for
advice.
7Never use the appliance if it is
visibly damaged.
7Keep the appliance away from
children.
7Do not open the appliance
under any circumstances. No
warranty claims are accepted
for damage caused by incorrect
handling.
J
18 ENGLISH
OVERVIEW__________________________________________
See the illustrations on page 2.
Controls
Professional cutting head
made from industrial ceramic
(width 25 mm).
On/off switch.
Charging display (LED). Lights
up red when charging and
green when it is fully charged.
Socket for plugging into the
charging unit or connecting the
power supply unit.
Charging unit.
Turbo speed switch on the
back of the appliance.
Accessories
Trimming attachment for fine
lines (width 14 mm).
G
F
E
D
C
B
A
Extendable plug-in comb
system suitable for both cutting
widths, with precise trimming
grade display for beard lengths
of 2, 4, 6, 8 and 10 mm.
Shaving attachment with single
blade foil for a smooth shave.
Power supply unit.
Other accessories
1 x moustache comb.
1 x thinning comb.
1 x cleaning brush.
1 x oil for cutting head.
J
I
H
ENGLISH 19
POWER SUPPLY ___________________________________
Operation with
rechargeable batteries
When operating the appliance with
the built-in nickel metal hydride
battery, only use the power unit
supplied for charging.
1Plug the power cord into the
appliance socket and the
power supply unit into the wall
socket.
Notes
7Charge up the batteries completely
before you use them for the first
time or if you have not used them
for a long time.
– The charging display lights
up red when charging and
changes to green when it is
fully charged.
7When switched off, the charging
time is about 8-10 hours. If you
switch on the appliance while it is
charging, charging will stop.
– The charging display
disappears.
C
C
D
7The ambient temperature should
be between 5 °C and 40 °C.
7When fully charged, the appliance
works for around 40 minutes.
It is not advisable to charge the
batteries after every use, especially
if you do not use the appliance for
the full 40 minutes. Only charge
the batteries when they are
completely discharged. This
increases their service life. Do not
charge it every day.
Using the charging unit
1Put socket of the appliance
into the charging unit.
2Plug the power cord into the
socket on the charging unit.
3Plug the power supply unit into
the wall socket.
D
20 ENGLISH
POWER SUPPLY ___________________________________
Mains operation
(with the power supply
unit)
Check if the mains voltage on the
type plate of the power supply unit
supplied corresponds to your local
mains supply.
The only way to disconnect the
device from the mains is to unplug
the power supply unit.
1Plug the power supply unit into
the socket on the appliance.
2Plug the power supply unit into
the wall socket.
Caution
7When in the bathroom or beside
a water connection, only use the
appliance in battery mode; never
run it from the mains.
D
ENGLISH 21
OPERATION ________________________________________
Special features
This appliance has four separate
functions:
– Function 1: for precise and
smooth beard trimming at a width
of 25 mm.
– Function 2: for cutting fine lines at
a width of 14 mm.
– Function 3: for beard trimming
with various cutting lengths (2, 4,
6, 8, 10 mm) at widths of 25 mm
or 14 mm.
– Function 4: for close shaving.
Switching on/off
1Press the button to switch on
the appliance.
2If you want to switch to turbo
speed, press and hold down .
3Press the button to switch off
the appliance.
B
F
B
Function 1
Beard trimming
Using the ceramic cutting head
(width 25 mm).
1If required, remove the attach-
ment by pressing down both
thumbs on the front of the
attachment and pushing back.
2Insert the ceramic cutting head
at the back with the guide tab
and press it down with your
thumbs until it clicks into place.
3Place a towel around your neck
and shoulders.
A
A
22 ENGLISH
OPERATION ________________________________________
4Loosen the beard hair by
combing the beard in the
direction the hair grows.
Note
7Press and hold down switch to
use the turbo speed for removing
any unwanted hair before you
begin styling.
F
Function 2
Cutting fine lines
Using the trimming attachment
(width 14 mm).
1If required, remove the attach-
ment by pressing down both
thumbs on the front of the
attachment and pushing back.
2Insert the trimming attachment
at the back with the guide tab
and press it down with your
thumbs until it clicks into place.
G
G
ENGLISH 23
3Pull the extendable attachment
from behind, with the combs
over the cutting head and let it
click into the locking tab.
4Adjust the cutting length (2, 4,
6, 8 or 10 mm) by pressing on
the lock under the cutting length
display and then move the
comb to the setting you want.
H
OPERATION ________________________________________
Function 3
Trimming beards at
certain cutting lengths
Using the extendable attachment .
1If required, remove the attach-
ment by pressing down both
thumbs on the front of the
attachment and pushing back.
2Insert the (width 25 mm) or
(width 14 mm) attachment at
the back with the guide tab and
press it down with your thumbs
until it clicks into place.
G
A
H
