REMOTE CONTROLLER
GRC-1201
USER MANUAL
GW INSTEK PART NO. 82RC-12010MA1
ISO-9001 CERTIFIED MANUFACTURER
TABLE OF CONTENTS
This manual contains proprietary information, which is
protected by copyright. All rights are reserved. No part of this
manual may be photocopied, reproduced or translated to
another language without prior written consent of Good Will
Corporation.
The information in this manual was correct at the time of
printing. However, Good Will continues to improve its products
and therefore reserves the right to change the specifications,
equipment, and maintenance procedures at any time without
notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng City, Taipei County 236, Taiwan.
TABLE OF CONTENTS
5
Table of Contents
INTRODUCTION .......................................... 6
SPECIFICATIONS .......................................... 7
FRONT PANEL DESCRIPTION ..................... 9
CONNECTION METHOD ........................... 12
OPERATON METHOD ................................ 12
GDS-1000 Series User Manual
6
INTRODUCTION
The GRC-1201 is a special remote controller for the standard signal
generator GSG-family.
The main purpose of the GRC-1201 is to read the information stored in
the memory of GSG-family. Before the remote controller is used, such
information as the carrier frequency , output level, modulation factor,
and modulation mode must be written into the memory from the front
panel of the signal generator.
The values of the carrier frequency, output level, modulation factor, and
memory address can be changed by cursor keys and rotary knob.
GRC-1201 User Manual
7
SPECIFICATIONS
Setting functions
Higher digit and keys and lower digit and
keys in MEMORY block.
MOD and PILOT keys in MOD block.
Rotary knob to modify the value at cursor position.
and key to move cursor within a block.
and keys to move cursor between a blocks.
(The result of modification is displayed on the signal generator)
LOCK key to fix the function of rotary knob.
and keys in LEVEL block.
GRC-1201 User Manual
8
Display functions
2-digit 7-segment LED in MEMORY block.
MOD ,PILOT indicator in MOD block.
LOCK indicator in CURSOR block.
External dimensions
189 (W) x 38 (H) x 97 (D) mm (case size)
Cable length = 1.9 m approx.
Operating temperature range:
0˚to 40˚
GRC-1201 User Manual
9
FRONT PANEL
DESCRIPTION
(1) PILOT key : Select pilot signal to deliver or not.
When LED indicator is light, the
pilot signal to deliver. (GSG-122
only)
GRC-1201 User Manual
10
FRONT PANEL
(2) MOD key : Turns modulation ON or OFF.
When LED indicator is light, the
modulation is ON
(3) Address display : Indicates current address, are
arranged in a matrix with a line-
column display 00-99.
(4) Single step
key
: Use to increase or decrease address.
(5) Rotary knob : Modify the value at cursor position.
(6) and keys : Shifts the cursor to modulation,
memory or frequency display.
and keys : Shifts the cursor to right or left in
the blocks.
(7) LOCK key : Fix the function of rotary knob.
When LED indicator is light, the
function of rotary knob to the fixed.
(8) Output level : Use to increase or decrease the
output levels.
GRC-1201 User Manual
11
GRC-1201 User Manual
12
CONNECTION METHOD
Turn off the POWER SW of the signal generator , set the connector at
the tip of the GRC1201 cable to the REMOTE connector on the rear
panel of the signal generator , and turn on the POWER SW.
If information is not displayed correctly , turn off the POWER SW and
turn it on again.
OPERATON METHOD
(A) Each time the higher digit or key or lower digit
or key in MEMORY block is pressed, the value of the
relevant digit of memory address increases or decreases by 1.
(B) The lower digit and keys in MEMORY block and
MOD, PILOT keys in MOD block have the same functions as those
keys on the signal generator front panel.
(C) The same memory address is displayed on the GRC1201 and on the
signal generator and the PILOT , MOD indicator in the MOD block
of GRC1201 shows the same status as that on the signal generator.
(D) Data must be written into memory in advance by use of keys on
signal generator. (See section 4-5(2) of GSG120/122 Operation
Manual.)
(E) Before using the rotary knob . move the cursor to the item to be
modified by use of the , , and key(s).
(F) If the LOCK key is pressed. the data value cannot be changed by
turning the rotary knob; that is . the data is fixed at the value
specified immediately before the LOCK key was pressed.
(G) The and KEYS in LEVEL block use to increase or
decrease the output levels (continuity).
GRC-1201 User Manual
13
NOTE:
(1) When the value of higher digit in MEMORY block is “9” , pressing of
the key is ignored. In the same way , pressing of the
key is ignored when the value of the higher digit is “0”.
(2) PILOT key for the use of GSG-122 only; If used with GSG-120 , the
LED indicator always light.
