H3C S3100-52P Manuale utente

H3C S3100-52P Ethernet Switch

Operation Manual

Hangzhou H3C Technologies Co., Ltd.

http://www.h3c.com

Manual Version: 20071123-C-1.02

Product Version: Release 1500

No part of this manual may be reproduced or transmitted in any form or by any means

without prior written consent of Hangzhou H3C Technologies Co., Ltd.

Trademarks

H3C, , Aolynk, , H3Care,

, TOP G, , IRF, NetPilot,

Neocean, NeoVTL, SecPro, SecPoint, SecEngine, SecPath, Comware, Secware,

Storware, NQA, VVG, V2G, VnG, PSPT, XGbus, N-Bus, TiGem, InnoVision and

HUASAN are trademarks of Hangzhou H3C Technologies Co., Ltd.

All other trademarks that may be mentioned in this manual are the property of their

respective owners.

Notice

The information in this document is subject to change without notice. Every effort has

been made in the preparation of this document to ensure accuracy of the contents, but

all statements, information, and recommendations in this document do not constitute

the warranty of any kind, express or implied.

To obtain the latest information, please access:

http://www. h3c.com

Technical Support

customer_service@h3c.com

http://www. h3c.com

About This Manual

Related Documentation

In addition to this manual, each H3C S3100-52P Ethernet Switch documentation set

includes the following:

Manual Description

H3C S3100-52P Ethernet Switch

Installation Manual It provides information for the system

installation and setup.

H3C S3100-52P Ethernet Switch

Command Manual-Release 1500 It is used for assisting the users in using

various commands.

Organization

H3C S3100-52P Ethernet Switch Operation Manual is organized as follows:

Part Contents

0 Overview Introduces the characteristics, services,

and network implementations of

S3100-52P Ethernet Switches.

1 CLI Introduces the command hierarchy,

command view, and CLI features of the

Ethernet switch.

2 Login Introduces the ways to log into the

Ethernet switch.

3 Configuration File Management Introduces configuration file and the

related configuration.

4 VLAN Introduces VLAN and the related

configuration.

5 IP Address and Performance

Configuration Introduces IP address, IP performance,

and the related configuration.

6 GVRP Introduces GVRP and the related

configuration.

7 Port Basic Configuration Introduces basic port configuration.

8 Link Aggregation Introduces link aggregation and the

related configuration.

9 Port Isolation Introduces port isolation and the related

configuration.

Part Contents

10 DLDP Introduces DLDP and the related

configuration.

11 MAC Address Table Introduces MAC address forwarding

table management.

12 MSTP Introduces STP and the related

configuration.

13 Multicast

Introduces IGMP Snooping, multicast

MAC address, unknown multicast

packet dropping, and the related

configuration.

14 Routing Protocol Introduces static route configuration.

15 802.1x Introduces 802.1x and the related

configuration.

16 AAA-RADIUS-HWTACACS Introduces AAA, RADIUS, HWTACACS,

and the related configuration.

17 Centralized MAC Address

Authentication

Introduces centralized MAC address

authentication and the related

configuration.

18 DHCP Introduces DHCP-Snooping and the

related configuration.

19 ARP Introduces ARP and the related

configuration.

20 ACL Introduces ACL and the related

configuration.

21 QoS Introduces QoS and the related

configuration.

22 Mirroring Introduces port mirroring and the related

configuration.

23 Cluster Introduces the configuration for cluster

management implemented through

HGMPv2.

24 SNMP and RMON Introduces the configuration for network

device management implemented

through SNMP-RMON.

25 NTP Introduces NTP and the related

configuration.

26 SSH Terminal Service Introduces SSH2.0 and the related

configuration.

27 File System Management Introduces basic configuration for file

system management.

28 FTP and TFTP Introduces basic configuration for FTP

and TFTP, and the applications.

Part Contents

29 Information Center Introduces the configuration for

analyzing/diagnosing a network through

information center.

30 System Maintenance and Debugging Introduces daily system maintenance

and debugging.

31 VLAN VPN Introduces VLAN VPN and the related

configuration.

32 HWPing Introduces HWPing and the related

configuration.

33 DNS Introduces domain name resolution and

the related configuration.

34 Appendix Lists the acronyms used in this manual.

Conventions

The manual uses the following conventions:

I. Command conventions

Convention Description

Boldface The keywords of a command line are in Boldface.

italic Command arguments are in italic.

[ ] Items (keywords or arguments) in square brackets [ ] are

optional.

{ x | y | ... }

Alternative items are grouped in braces and separated by

vertical bars. One is selected.

[ x | y | ... ]

Optional alternative items are grouped in square brackets

and separated by vertical bars. One or none is selected.

{ x | y | ... } *

Alternative items are grouped in braces and separated by

vertical bars. A minimum of one or a maximum of all can be

selected.

[ x | y | ... ] *

Optional alternative items are grouped in square brackets

and separated by vertical bars. Many or none can be

selected.

# A line starting with the # sign is comments.

II. GUI conventions

Convention Description

< > Button names are inside angle brackets. For example, click

<OK>.

[ ] Window names, menu items, data table and field names

are inside square brackets. For example, pop up the [New

User] window.

/ Multi-level menus are separated by forward slashes. For

example, [File/Create/Folder].

III. Symbols

Convention Description

Warning Means reader be extremely careful. Improper operation

may cause bodily injury.

Caution Means reader be careful. Improper operation may cause

data loss or damage to equipment.

Note Means a complementary description.
