INSTRUCTION OF

HOUSEHOLD REFRIGERATOR

HRF-155/185

●Please read the instruction carefully before operation.

●Please preserve it well for future use.

CONTENTS

BEFORE USING

Designations of the parts

Safety precautions

Setting environment

Preparation for running

Operation

Instruction for the refrigerating compartment

Instruction for the freezing compartment

Cleaning,Stopping

Troubleshooting

Inside the front cover

○○○○○○○○○○

○○○○○○○○○

○○○○○○○○○○○○○

○○○

○○○○

○○○○○○○

○○○○○○○○

5-8

9-10

Designations of the parts

The appliance available may differ from the one described and illustrated in the manual

due to continuing improvement. Hence we apologize for it.

Fruit box

Trays/Shelves

Freezer section

Food shelf

Temperature selector

Food shelf

Door rack

Bottle rack

Discharge opening

Safety Precautions

In case inflammable gas leaks,

*Shut off the valve of the container.

*Open the exhaust.

*Do not pull out or insert the power plug.

Do not splash water over it.

*Wipe the water and dirt

away with a piece of cloth.

To avoid the door tilting , do not

allow children to hang

themselves on it.

Do not spray inflammable agent

near the refrigerator.

Use a separated socket

* Reliable earth connection.

*AC 220V,50Hz

If the power supply does not agree with

220V,50Hz, an automatic

voltage stabilizer over 500W must

be installed.

Any inflammable, explosive materials and corrosive

alkali should never be stored in the refrigerator.

Preparation for operation

*Remove all the packing materials

Including the foam pat.

*Check the accessories and data sheets

supplied with the refrigerator.

Check the items against the packing

list. If something is missing, contact your vendor.

*It is advisable to clean the refrigerator

before using it

(for details, see“Cleaning” at page 11).

*Standstill

To ensure trouble free operation, do not put the plug

into the power supply socket until 30 minutes after

setting-up and cleaning.

*Install the refrigerator on a proper place

(see “Setting environment” at page 3).

Setting environment

*The refrigerator should be placed on a flat and firm floor. Do not use the foaming packing

pat under it as a cushion.

*The refrigerator should be set in a place where

air circulates well. Leave enough space

around it.

*Keep it away from heat sources and

direct sunlight.

*Do not place it in a place where it is cold

enough to freeze.

*Do not expose it to high moisture and

splashes.

More than 10cm More than 10cm

Starting

Start the refrigerator

Do not put food into the refrigerator at once. after the power is on,

Normally, let it run without load for 2-3 hours. (Longer in summer).

After it is cooled down inside, food can be placed in.

For the first operation, the compressor may run in a long time. It is

no fault.

Adjust the temperature inside the refrigerator

Normally, turn the knob for temperature adjustment in the refrigerator

compartment to “mean” position. In this case, the temperature is

about -18℃in the freezing compartment, and 3-6℃ in the

refrigerating compartment.

The refrigerating compartment.

If the knob points to “1” , the temperature inside is about 3℃

higher than at the “4-5” position. If it points to “7” , the

temperature is about 3℃ lower. Please adjust it to meet your

requirement.

The above temperatures are average temperatures at the centers of

the refrigerating compartment and the freezing compartment without

food in it, with the door closed and when the environment temperature

is about 30℃.

Adjustment can be conducted according to the environment temperature, operation condition and the table

below when it is necessary.

Phenomena Adjustment

When the knob is at the “1” position for a long

period and the food in the freezing compartment is

frozen too slowly.

Turn the knob to “7” position

When the ambient temperature is too high in

summer (over 32℃)

Turn the knob to the position between “1” and

“4-5”

TEMPERATURE

ADJUSTMENT

Food for short-term storage and everyday used

vegetables can be put into this compartment.

The temperature in this compartment is about 0-10℃.

Though multiplication of bacteria can be limited, it is

impossible to control it completely. So, it is not suitable to

store food for a long time in it.

Instruction for the Refrigerating Compartment

Notice for the food storage

*Before putting hot food into the refrigerator, cool it to the room

temperature.

*Food should be cleaned and wiped water off before storage.

*It is better to seal food in a container before storage.

It not only can prevent food from drying, but also can prevent

odor penetration. For example, fish and meat must have

bacteria on them. So, it is necessary to pack them in order to

avoid contacting other food.

123

7 6 5 4

Food arrangement

Temperatures differ in different parts of the inner compartment and

foods can be stored accordingly. The part 6 is the coldest zone of

the fridge section.

1. Wheaten food, can, diary product and bean curd, etc.

2. Butter and cheese, etc.

3. Cans and seasonings, etc.

4. Beverages and bottled foods.

5. Delicatessen and sausages.

6. Fruits, vegetables and salad, etc.

*It is not suitable to put too much or too heavy food

on the supporting tray. It may damage the tray.

*Please classify the food before storage.

Put the food used every day in frond of the shelves to

prevent opening the door in longer time.

*Never fill food fully in the refrigerator.

Food should be separated from one another leaving

passage for air circulation.

Lamp and replacement

Data for the lamp: 220V 10W

Lamp holder: E12(never use bulb over 10W)

When you change the bulb, take off the plug to cut off

power, turn the bulb anticlockwise as shown in the fig;

then fix the new bulb and insert the plug.

How to adjust the height of the tray

You may adjust the height of the tray at your will. When

you want to take it out or put in , please use two hands

with care.

Making full use of the refrigerating compartment

When storing vegetables, do not place them in their

growing direction. It can be kept longer in this way.

Place mushrooms upsides down. Leaves of turnips

should be cut off before storage.

When putting bottles in the bottle holder inside the

door , put some napkin paper at the bottom of the

holder it makes it easy to clean the door.

When thawing frozen food, put it in the refrigerating

compartment. It can cool the compartment. Energy

can be saved.

The following food is not necessary to be stored in

the refrigerator.

Food not suitable to be stored in it:

pumpkins, muskmelons, Chinese flowering quinces,

and pineapples. They may undergo a process of

metabolism in the refrigerator. If they are not ripe,

they can be stored in it for a period.
