Haier PRCS25E Series Guida all'installazione
HAIER
PRCS25EXXX
Side by Side
25 cu ft
Refrigerator
Freezer
with
Convertible
Drawer
This training also covers
models
PRCS25PXXX and
RRCS25XXXX
HAIER
PRCS25XXXX
Side by Side
Convertible
Service Training
Programs include:
Operation
Door Components
Machine Compartment
Fresh Food and Freezer
Compartments
Control Module Components
HAIER
Model Designations
Side by Side Convertible
25 cu ft Refrigerator / Freezer
P R C S 25 E D A W
W: White S: Stainless B: Black V: Virtual Stainless
A: Production Series
D: Dispenser
E: Elite S: Supreme T: Plus
25: Capacity
S: Spill-proof shelving
C: Convertible Drawer
R: Refrigerator
P: Phoenix series R: Standard series
MODEL FEATURES
PRCS25E***
EXPRESS FREEZE
EXPRESS CHILL
WATER FILTER
EXTRA ICE
CUBE DISPENSER
CRUSHED ICE DISPENSER
MODEL FEATURES
PRCS25S***
WATER FILTER
CUBE DISPENSER
CRUSHED ICE DISPENSER
MODEL FEATURES
RRCS25****
WATER FILTER
CUBE DISPENSER
CONTROLS
Freezer – Fresh Food Compartments
FREEZER – 7 temperature settings. –6° ~+ 8° F
More bars indicate colder temperatures. Press <-> to adjust.
EXPRESS FREEZE* – Increases evaporator fan speed by approximately 10%.
Will reset to normal operation after 4 hours. Temperature cannot be changed
when EXPRESS FREEZE is activated.
Temperature will not drop below set temperature.
FAHRENHEIT / CELSIUS - F° / C° setting*
On dispenser control panel, in locked mode, press both WARMER and COLDER
keys at the same time for 3 seconds. Chime will sound indicating mode change.
*Not applicable to all models
CONTROLS
Freezer – Fresh Food Compartments
REFRIGERATOR – 7 Temperature settings. 34°~ 46° F
More bars indicate colder temperatures. Press < - > to adjust.
EXPRESS CHILL* - Increases evaporator fan speed by approximately 10%. Will
reset to normal operation after 4 hours. Temperature cannot be changed when
EXPRESS CHILL is activated. Temperature will not drop below set temperature.
FILTER RESET – FILTER CHANGE – filter change indicator will activate on 6
months intervals as a reminder to change filter. After changing filter, press and
hold FILTER RESET for 3 seconds to reset.
The icemaker and water dispenser will not function if no filter is in place.
REFRIGERATOR ON / OFF - In the nonlocked mode, press and hold the
refrigerator temperature regulator keys <and > for 3 seconds. The refrigerator
temperature display is off and the refrigerator section is turned off. Reset using
the same procedure. A chime will sound.
*Not applicable to all models
CONTROLS
Convertible Drawer
LIGHT – activates dispenser light. Automatically turns off after 4 hours
LOCK – locks all dispenser functions from activation when the door paddle is depressed
WATER – water will be dispensed when the door paddle is depressed
CUBE - Ice cubes will be dispensed when the door paddle is depressed
CRUSH – crushed ice will be dispensed when the door paddle is depressed
EXTRA ICE* – increases evaporator fan motor speed by approximately 10% to increase ice
production. Cycle will reset to normal operation after 4 hours
*Not applicable to all models
CONTROLS
Convertible Drawer
WARM (gold – left side) Indicates drawer is in REFRIGERATOR mode. Adjustable from 34° ~ 46° F
COLD (blue – right side) Indicates drawer is in FREEZER mode. 2 differing temperature settings
Soft Freeze - Adjustable from 19° F ~ 30° F
Hard Freeze – Indicated by SC (Super Cold) in right indicator box. (non adjustable – approx 5° F)
*Not applicable to all models
