Halcro UTSR1 Manuale utente

Owner’s Manual

een

UTSR1

tat

Rev 1.1

820-6110-0008

Table of Contents

.................

Key Features.............................................................. 3

Optional Features ...................................................... 3

Specifications ............................................................. 5

Battery Installation and Charging...............................7

...............................

.......

Panel Calibration ........................................................ 8

Hot Keys..................................................................... 9

Hard Keys................................................................... 9

Key Tone .................................................................... 9

Backlight ....................................................................10

IR Codes Library........................................................10

Configuration/Setting Up the Unit ...........................10

...............................

.............

Edit .............................................................................13

Preference................................................................. 15

Remote Setting.........................................................15

Smart .........................................................................18

Clone......................................................................... 20

PC Link.......................................................................21

Interactive Help Screen ............................................21

...............................

..........

Key Features............................................................ 22

Specifications ........................................................... 22

Quick Charger Function .......................................... 24

Remote Advanced Editing via Computer.............. 24

Maintenance ............................................................ 25

...............................

.........

UTSR1........................................................................ 26

Docking Station........................................................ 27

...............................

........

Preamp..................................................................... 28

Surround Sound Processor .................................... 28

TV .............................................................................. 28

SAT/CBL ................................................................... 34

CD ............................................................................. 37

DVD ........................................................................... 38

...............................

....

Service Information.................................................. 40

Warranty Information................................................ 41

Warranty Registration Form.................................... 42

atur

•

Pre-Programmed with learning capability

•

9-in-1 remote (replace HALCRO dm 8/10, HALCRO

SSP, CD, TV, SAT TV, CBL TV, DVD, AUX 1 & AUX2)

•

Learn up to 240 commands

•

EL backlit touch screen panel with intelligent light

sensor for power saving

•

5 useful hard keys for direct access ( ,

H+

H-

L+

L-

)

•

3 touch screen shortcuts ( , , )

•

Set up by code entering, device brand name

search and library code search

•

10 programmable smarts, each with 32 steps in

maximum

•

Device name and function keys editing, moving,

deleting and restoring

•

Custom page for personal set up and frequently

used commands

•

Remote-to-remote copy function

•

Volume ‘punch through’control for TV, HALCRO

Pre-amplifier and HALCRO SSP

nteractive help screen

•

Security password lock

•

Real time clock

•

Battery level indicator

uto power off

C/DC power charger

atur

•

DockingStation for quickbatterycharging

•

Computer link (PC link) for special key layout and

function via USB connection to PC

•

Perform PC software upload and download

•

Remote Control

1. Infra-red Lens 6. Touch Screen Panel

2. Green LED Indicator 7. Short Cut Keys

3. Battery Level Meter 8. Hard Keys

4. Current Time 9. Connection Jack

5. Current Mode 10. Battery Compartment

Spe

cat

•

Operation System: Integrated preprogrammed

and learning infra-red

remote control system

•

Compatibility: Preprogrammed with code

library of HALCRO dm 8/10

(Preamplifier), HALCRO

SSP, Compact Disc Players

(CDs), Televisions (TVs),

Satellite/Digital Satellite

Receivers (SAT TVs), Cable

Converters (CBL TVs) and

Digital Video Disc Players

(DVDs)

•

Memory Capacity: 240 learning commands

•

Memory retention after battery disconnection:

Non-volatile and permanent

memory

•

Display Panel: Monochrome touch screen

LCD

•

Resolution: 320 x 80 pixels

•

EL Backlighting: Blue-Green EL backlighting

with light sensor

•

Operating Distance: 8 Meters (25 feet)

•

Power Requirement: 4 x AAA size NiMH

rechargeable batteries

•

Charging Time: Approximately 17 hours

•

Dimensions: 220 x 51 x 25 mm

•

Weight: 165g (without batteries),

215g (with batteries)

•

ncluded Accessories: AC/DC power adaptor

(DC9V, 400mA, 3.6VA) x 1,

Connector x 1 (for charging

purpose), 4 x AAA size

NiMH rechargeable

batteries

•

Optional Accessories: Halcro Logic Docking

Station –Quick charger, PC

Link software for MS

Windows 98SE, Windows

2000, Windows NT,

Windows XP and USB Cable

Remote Control

Note: Both the Halcro Logic UTSR1 and Docking

Station comply with limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference in a residential installation. This

equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in

accordance with the instruction, may cause harmful

interference to radio communications. However, this

is no guarantee that interference will not occur in a

particular installation.

If this equipment does cause harmful interference to

radio or television reception, which can be determined

by turning the equipment off and on, the user is

encouraged to try to correct the interference by one

or more of the following measures:

•

Reorient or relocate the receiving antenna

•

Increase the separation between the equipment

and receiver

•

Connect the equipment into an outlet on a circuit

different from that to which the receiver is

connected

•

Consult the dealer or an experienced radio/TV

technician for help

may void users authority to operate this device”

“Modifications not authorized by the manufacturer

att

har

Your Halcro Logic UTSR1 is supplied with 4 x AAA

NiMH rechargeable batteries, a connector and a

charging adaptor. We recommend you charge your

batteries over night (10 hours) before 1

time use.

The battery meter (top-left corner of LCD) will

empty to indicate when the batteries require

recharging.

To install the batteries, open the battery cover; follow

the polarity symbol shown in battery compartment,

place the batteries inside and then replace the cover.

To recharge batteries, put the power adaptor into AC

wall outlet, insert the DC jack to the connector, then

connect to the socket at the bottom of the remote. It

takes approximately 14 to 16 hours to fully charge the

batteries.

Note: The Battery icon is not shown when in

Menu mode.

The unit is designed for optimum operation with

original batteries.

Do NOT connect charging adaptor and connector

when using the non-original batteries.

To avoid data loss, Do NOT attempt remote setup

when batteries are weak.

Remote Control

After inserting the batteries, you will be prompted by

the main page, which shows all the devices and

functions for selection.

•

Tap H

at any time to jump to this page. If

remote is inactive for approximately 60 seconds, it

will go to sleep mode and shut down the display.

Simply touch the screen panel to activate the unit.

(Note: When in sleep mode, the hard key section is

still available for command)

•

Tap any device icon on screen to enter

corresponding device mode. The LCD shows a

remote key platform

•

Tap a key directly to send out corresponding infra-

red command

•

Tap P

AGE

at bottom of screen to change

command pages

•

Tap H

to return to main page

•

There will be no label or symbol for an empty key

(Note: these keys are available for learning, please

refer to learning section of this manual for details.)

•

Tap M

to set up the unit

Panel Calibration

Please follow the below instruction for calibration of

the Halcro Logic UTSR1. If you experience any

incorrect response from the touch screen, please re-

calibrate the unit.

•

Tap M

to set up the unit

•

Tap R

•

Tap C

ION

•

Follow the described procedure from the screen

display

•

Tap B

to go back to the H

page

Note: If your Halcro Logic UTSR1 does not respond,

you can reset the remote by pressing the

key

inside the battery compartment (see illustration). This

product may need to be manually reset under high

electrostatic discharge.

There are 3 Hot keys on the bottom of LCD display,

•

Jump to main page

•

Access main setup menu for

configuration/setting

•

Volume mute function

There are 5 hard keys that transmit IR command

corresponding to device selected.

•

Power ON/OFF

•

H+

Program up or Channel up

•

H-

Program down or Channel down

•

L+

Volume up

•

L-

Volume down

When you tap any key, there is a short audible beep.

User can enable/disable this function from main menu

setting (for details, please refer to R

ing

section in this manual.)

Remote Control

There are two separate EL backlights for LCD screen

and hard keys, and will be turned ON separately.

Backlight will be turned ON for 5 seconds (factory

default setting) after a key is pressed, and user can

disable this function. (For details, please refer to

ing

section in this manual.)

ode

rar

To setup a code, tap M

once then select a

device to setup, choose a setup method. User can

setup by learning key command from an original

remote control, entering a code number, browsing

through brand name list, or searching through the

whole library. Refer to separate Code List for IR code

number of different device.

ura

/Se

Tap M

, then choose any one of the following

items:

–

setup the pre-programmed code or learn key

command.

•

Tap S

frommainmenu

•

Select one of following setup methods

–learn or copy a key command from an

original remote control to Halcro Logic UTSR1

•

Tap L

ning

from Setup menu

•

Select a device where you would like to carry the

command keys (e.g. TV)

•

Tap a key to be learnt from the Halcro Logic UTSR1

•

im an original remote to the front of Halcro Logic

UTSR1. Press and hold the key until Halcro Logic

UTSR1 responds with a successful message

(approx. 5 seconds)

•

Edit the keyname or just tap OK

to confirm

•

Tap another key to continue learning of the rest of

the useful commands

•

Tap M

to return to main menu, or tap

OME

to return to main page

Dual

Signal

Learning

–If you find that a Learn

command only works occasionally for your audiovisual

equipment, your original remote control mayay contain

dual signals. Please follow the below steps to

reprogram these commands.

•

Tap L

ning

from Setup menu

•

Select a device which you would like to carry the

command keys (e.g. TV)

•

Tap a key to be learnt from the Halcro Logic UTSR1

•

the original remote to the front of the Halcro

Logic UTSR1. Press and hold the key until Halcro

Logic UTSR1 responds with a successful message

(approx. 5 seconds)

•

Edit the key name or just tap OK

to confirm

•

Tap the same key on the Halcro Logic UTSR1

Again aim the original remote to the front of the

Halcro Logic UTSR1. Press and hold the same key

until Halcro Logic UTSR1 responds with a

successful message

•

Edit the key name or just tap OK

to confirm

Note: The optimum receiving distance is 5 to 8cm for

remote learning. If you have any reported problem

during the learning process, adjust the distance and

try again.

Brand

Name

–setup pre-programmed code by

selecting a brand name.

•

Turn on your device you wish to install before start

this setup procedure. (e.g. TV)

•

Tap B

from Setup menu

•

Select a device (e.g. TV)

•

brand name list in alphabetical order will be

displayed. Tap or to browse the list, or tap a

character to access to a brand name. (e.g. ‘H’for

Halcro)

•

Tap a brand name from the list, it will be highlighted

(e.g. Halcro)

Aim

•

5-8 cm

Remote Control

•

Tap test keys on LCD screen or any of hard keys

to test the selected code

•

Tap to search next code, or command will be

sent at the same time

•

Tap to skip previous code

•

Tap Back

Back

to cancel and return to previous menu

page for selection of other brand name. (Follow

the above steps again)

•

Tap OK

to confirm and exit the setup

Note: If you have reached the end of code, you will be

prompted to continue for

For

details of Auto-Search setup, please refer to Auto-

Search Setup section in this manual.

ode

–setup pre-programmed code by

entering code number. (Halcro Logic UTSR1 is

preloaded with numerous control codes for most

popular AV equipment; you can refer to the enclosed

code list for your devices.)

•

Tap E

ode

from Setup menu

•

Select a device (e.g. TV)

•

Tap numeric digit to enter code number (check

your code from the code list, e.g. 0021)

•

Tap De

to delete the last entered digit (if you

have mistyped a number)

•

Tap Back

Back

to cancel and return to previous menu

page

•

Tap OK

to confirm the input

•

Tap T

on LCD screen or any of hard key to

test the corresponding function

•

Tap O

to confirm and exit the setup

- setup pre-programmed code by

searching through the library.

•

Turn on your device before starting this setup

procedure (e.g. TV)

•

Tap A

from Setup menu

•

Select a device (e.g. TV)

•

Tap once and then repeat until your device is

switched off. Then, press OK

to save the code. Or

you can tap the T

key to test the device during

setup

If you have missed the last code, tap once to

skip backward

•

Tap Back

Back

to cancel and return to previous menu

page

•

Tap OK

to confirm and exit the setup

Note: When a code is set to a device, the learned

command and key name of that device will be lost,

and restored to pre-programmed command.

Some codes do not have Power command. These

codes may not be detected by using Auto-Search.

User is advised to use

key to test other keys.

During auto-searching, user can access any of the

hard keys to test the command.

anc

This function allows you to rename, move or delete

key/device label.

Tap M

then tap E

and choose any one of

the following items:

- rename key label

•

Tap K

from Edit menu

•

Select a device

•

Select a key to be edited

•

Tap , , or for quick access to different

groups of keys (Character, Symbol or Graphic),

and tap or to access different pages of each

group of keys

•

Tap a character/symbol/graphic from the page

•

Tap D

to erase last entered

character/symbol/graphic

•

Tap B

to ignore and return to previous page

•

Tap OK

to confirm and exit editing

Note: The number of characters input depends on the

corresponding key size

•

ABC ?!À i

Remote Control

rename device label

•

Tap D

from Edit menu

•

Select a device

•

Tap , , or for quick access to different

groups of keys (Character, Symbol or Graphic),

and tap or to access different pages of each

group of keys

•

Tap a character/symbol/graphic from the page

•

Tap D

to erase last entered

character/symbo /graphic

•

Tap B

to ignore and return to previous page

•

Tap OK

to confirm and exit editing

Note: Maximum input of 7 characters

- move key location (exchange keys

position)

•

Tap M

from Edit menu

•

Select a device

•

Select a key to be moved, tap OK

to confirm

•

Select a destination, tap OK

to confirm. The

position of the 2 selected keys will then be

exchanged

•

Select a key to continue or tap M

to exit

Move Key mode and return to main menu

ice

–move device location

•

Tap M

from Edit menu

•

Select a device to move, tap OK

to confirm

•

Select a destination, tap OK

to confirm. The

position of the 2 selected devices will then be

exchanged

•

Select a device to continue or tap M

exit Move Device mode and return to main menu

–delete a key

•

Tap De

from Edit menu

•

Select a device

•

Select a key to be deleted, tap YES

YES

to confirm

•

Select a key to continue or tap M

to exit

Delete Key mode and return to main menu

ABC ?!À

Tap M

then tap P

and choose

any one of the following items:

–set up device punch through for

Volume Control, Volume + / - and Mute.

•

Tap P

from Preference menu

•

Select a source device (e.g. HALCRO dm 8/10)

•

Select a target device (e.g. DVD)

Note: For punch through, Vol +, Vol - and Mute will be

punched through to the selected device.

–

set up a user custom page

•

Tap C

AGE

from Preference menu

•

Select your keys from different devices for custom

page

•

Select a device where a key to be copied to

custom page (e.g. TV)

•

Select a key command to be copied to custom

page (e.g. )

•

Tap YES

YES

to confirm the selection

•

Tap to select other key to create new command

or tap M

to exit and return to main menu

Note: Custom Page is a group of keys that allow the

user to copy key commands from different devices,

access custom pages from the

page, view the

device attribute of a key (tap the header

AGE

once to toggle display device name and key

name) and if a key is deleted or re-named on original

device, it is also changed in Custom Page.

Tap M

then tap R

and

choose any one of the following items:

–adjust clock

•

–adjust current time

•

Tap Cl

from Remote Setting menu

•

Tap S

to adjust clock

•

Enter four digits, first two digits represent hour and

second two digits represent minutes (24 hour

format is used.)

•

Tap OK

to confirm and exit the setting

Remote Control

•

eek

–

adjust day of week

•

Tap Cl

from Remote Setting menu

•

Tap S

to adjust date

•

Tap or to select day of week

•

Tap OK

to confirm and exit the setting

–turn beep sound On/Off

•

Tap B

eep

und

from Remote Setting menu

•

Tap E

to turn on beep sound

•

Tap D

to turn off beep sound

–set up LCD related function

•

: select backlight auto turn off at 5

Sec, 10 Sec or 15 Sec

•

Bac

select an option of backlight

control method, By Sensor, Always On or Always

Off.

- create/enable or disable password

In order to keep your personal setting of the Halcro

Logic UTSR1 secure, you can activate the password

function for remote setting protection.

•

Enter password, max. 5 characters

•

Re-enter password for confirmation

•

Tap D

to delete last character

•

To disable password, give a blank input (no

characters) to password field

Note: Universal password is

AAAAA

–reset user setting to factory default.

Warning: Please make sure it is necessary to perform

this function. Your Halcro Logic UTSR1 will be reset to

factory pre-loaded setting and all the learned

signals/custom setting will be erased.

ning

–to clear learned command and

restore keys to default command.

One Key –to clear learned command and restore

keys to default command

•

Tap to select a device

•

Tap to select a key

•

Tap Y

to confirm or tap No

to abort

One Device –clear learned command of all keys of

a device.

•

Tap to select a device

•

Tap Y

to confirm or tap No

to abort

All Devices - clear all learned commands of all

devices.

•

Tap A

•

Tap Y

to confirm or tap No

to abort

–clear user renamed key label and

restore to factory default.

One Key –

single key.

•

Tap to select a device

•

Tap to select a key

•

Tap Y

to confirm or tap No

to abort

One Device –restore all user renamed key label of

a device.

•

Tap to select a device

•

Tap Y

to confirm or tap No

to abort

All Devices - restore all user renamed key label of

all devices.

•

Tap A

•

Tap Y

to confirm or tap No

to abort

–clear user renamed device label

and restore to factory default.

One Device - restore a single user renamed device

label and restore to factory default.

•

Tap to select a device

•

Tap Y

to confirm or tap No

to abort

All Devices - restore all user renamed device label

and restore to factory default.

•

Tap A

•

Tap Y

to confirm or tap No

to abort

–clear and restore user setting about key

movement.

One Device –clear the setting of key movement of

a device and restore to factory default.

•

Tap to select a device

restore user renamed key label of a

Remote Control

•

Tap Y

to confirm or tap No

to abort

All Devices - clear all settings of key movement of

all devices and restore to factory default.

•

Tap A

•

Tap Y

to confirm or tap No

to abort

- clear the setting of device movement

and restore to factory default.

•

Tap M

•

Tap Y

to confirm or tap No

to abort

–restore deleted keys.

One Key –restore a single deleted key

•

Tap to select a device

•

Tap to select a key

•

Tap Y

to confirm or tap No

to abort

One Device –restore all deleted keys of a device.

•

Tap to select a device

•

Tap Y

to confirm or tap No

to abort

All Devices –restore all deleted keys of all devices.

•

Tap A

•

Tap Y

to confirm or tap No

to abort

ult

–restore all user settings to factory

default.

•

Tap Y

to confirm or tap No

to abort

Note: All user settings will be lost (except clock and

password). Default function do not clear clock setting

and password.

–show information of the unit.

•

Display software version, code number of each

device and other useful information

•

Tap or for more information or tap Back

Back

return to R

ing

art

Halcro Logic UTSR1 comes with 10 editable S

programs each with a maximum 32 key steps. With

the help of S

, you can program a group of

commands and time delay to execute in a chain of IR

signals simply by the press of SMART button.

Tap M

, then tap S

and choose any one

of the following items:

–create a new smart command.

•

Select an empty smart key

•

Tap A

to select a device and a key to add it

into smart list

•

Tap A

to add a delay time between key

command (maximum delay is 20 seconds)

•

Select an item from the command list and tap

and M

to re-order the

sequence of that item, or tap D

to remove

that item from the list

•

Tap T

to test the function of Smart

•

Tap OK

to confirm

–edit an existing smart key

•

Select an existing smart

•

Tap A

to select a device and a key to add it

into smart list

•

Tap A

to add a delay time between key

command (maximum delay is 20 seconds)

•

Select an item from the command list and tap

and M

to re-order the

sequence of that item, or tap D

to remove

that item from the list

•

Tap T

to test the function of Smart

•

Tap OK

to confirm

–delete a smart key

•

Select an existing smart

•

Tap OK

to confirm

•

Tap B

to abort

- to rename label of a smart key

•

Select an existing smart

•

Tap a character from the touch screen

•

Tap D

to last entered character

•

Tap B

to ignore and return to previous page

•

Tap OK

to confirm

Note: When a S

is executed, press a hard key

(e.g. ,

) to stop the signal

transmission. User can set maximum 32 steps

(including delay) for each smart program. The

maximum delay time is 20 seconds.

Altri manuali per UTSR1

Indice

Altri manuali Halcro Telecomando

Halcro

Halcro UTSR1 Manuale utente

Manuali Telecomando popolari di altre marche

Panasonic

Panasonic EUR7622KB0 Manuale utente

Bang & Olufsen

Bang & Olufsen Beo4 Manuale utente

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuale utente

Multiplex

Multiplex PROFI TX 9 Manuale utente

One Remote

One Remote RMB4 Manuale utente

FUTABA

FUTABA 9ZAP - PART2 Manuale utente

HR Matic

HR Matic HR MULTI 3 Manuale utente

Yamaha

Yamaha ACC-GNRST-30-20 Manuale utente

EisSound

EisSound KBSOUND Manuale utente

Marantz

Marantz RC101 Manuale utente

Conrad

Conrad FS20 TC6 Manuale utente

Anritsu

Anritsu MP1777A Manuale utente

Niles

Niles WVC100 Guida alla risoluzione dei problemi

RCA

RCA RCU1300 Manuale utente

Bang & Olufsen

Bang & Olufsen BEO6 Manuale utente

GE 94901 Manuale utente

Onbon

Onbon YQ1-75 Manuale utente

FUTABA

FUTABA R7108SB Istruzioni per l'installazione
