HAMPTON BAY Bryant Manuale utente

Bryant

in Ceiling Fan

Owner’s Manual

Bryant

Ventilador de Techo de 1.17m

Manual del Propietario

823 338

Lifetime Limited Warranty

Hampton Bay Lifetime Limited Warranty

Date purchased

Store Purchased

UL Model No. CF546KR

Serial No.

Vendor No. 82598

UPC 845952000032

The retailer warrants the fan motor to be free from defects in workmanship and

material present at time of shipment from the factory for a lifetime after the date

of purchase by the original purchaser. The retailer also warrants that all other fan

parts, excluding any glass or plexiglass blades, to be free from defects in

workmanship and material at the time of shipment from the factory for a period

of one year after the date of purchase by the original purchaser. We agree to

correct such defects without charge or at our option replace with a comparable or

superior model if the product is returned to the retailer. To obtain warranty

service, you must present a copy of the receipt as proof of purchase. All costs of

removing and reinstalling the product are your responsibility. Damage to any

part such as by accident or misuse or improper installation or by affixing any

accessories, is not covered by this warranty. Because of varying climatic

conditions in the United States this warranty does not cover any changes in brass

finish, including rusting, pitting, corroding, tarnishing or peeling. Brass

finishes of this type give their longest useful life when protected from varying

weather conditions. A certain amount of wobble is normal and should not be

considered a defect. Servicing performed by unauthorized persons shall render

the warranty invalid. There is no other express warranty. The retailer hereby

disclaims any and all warranties, including but not limited to. Those of

merchantability and fitness for a particular purpose to the extent permitted

by law. The duration of any implied warranty which cannot be disclaimed is

limited to the time period as specified in the express warranty. Some states do

not allow limitation on how long an implied warranty lasts, so the above

limitation may not apply to you. The retailer shall not be liable for incidental,

consequential, or special damages arising out of or in connection with

product use or performance except as may otherwise be accorded by law.

Some states do not allow the exclusion of incidental or consequential damages,

so the above exclusion or limitation may not apply to you. This warranty gives

specific legal rights, and you may also have other rights which vary from state to

state. This warranty supersedes all prior warranties.

Table of Contents

Safety Rules

Unpacking Your Fan

Installing Your Fan

Hanging Your Fan

Making the Electrical Connections

Finishing the Installation

Attching the Fan Blades

Installing the Light Kit

Installing without the Light Kit

Operating Your Transmitter

Care of Your Fan

Troubleshooting

Specifications

Safety Rules 1.

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL

INJURY, MOUNT FAN TO OUTLET BOX MARKED ACCEPTABLE FOR

FAN SUPPORT.

1 . To reduce the risk of electric shock, ensure electricity has been turned off

at the circuit breaker or fuse box before beginning.

2. All wiring must be in accordance with the National Electrical Code and

local electrical codes. Electrical installation should be performed by a

qualified licensed electrician.

3. WARNING: To reduce the risk of electrical shock and fire, do not use

this fan with any solid-state fan speed control device.

4. WARNING: To reduce the risk of personal injury, use only the two steel

screws (and lock washers) provided with the outlet box for mounting

the outle t box . Most outlet boxe s commonly used fo r the support of

lighting fixtures are not acceptable for fan support and may need to be

replaced, consult a qualified electrician if in doubt.

5. The outlet box and support structure must be securely mounted and capable

o f reliably supporting a minimum of 35 pounds. Use only UL Listed outlet

boxes marked FOR FAN SUPPORT.

6. The fan must be mounted with a minimum of 7 feet clearance from

the trailing edge of the blades to the floor.

7. Do not operate reversing switch while fan blades are in motion. Fan

must be turned off and blades stopped before reversing blade

direction.

8. Avoid placing objects in the path of the blades.

9. To avoid personal injury or damage to the fan and other items, be

cautious when working around or cleaning the fan.

10. Do not use water or detergents when cleaning the fan or fan blades. A

dry dust cloth or lightly dampened cloth will be suitable for most

cleaning.

11. After marking electrical connections, spliced conductors should be

turned upward and pushed carefully up into outlet box. The wires

should be spread apart with the grounded conductor and the

equipment-grounding conductor on one side of the outlet box.

12. Electrical diagrams are reference only. Light kits that are not packed

with the fan must be UL Listed and marked suitable for use with the

model fan you are installing. Switches must be UL General Use

Switches. Refer to the Instructions packaged with the light kits and

switches for proper assembly.

NOTE

READ AND SAVE ALL INSTRUCTIONS!

WARNING

TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE

BLADE BRACKETS (ALSO REFERRED TO AS FLANGES) DURING

ASSEMBLY OR AFTER INSTALLATION. DO NOT INSERT OBJECTS IN

THE PATH OF THE BLADES.

2. Unpacking Your fan

12 15

14A

9. Switch cup (1)

10. Light kit (1)

11. 50 Walt E11 bulb (1)

12. Glass shade (1)

13. Receiver (1)

14. Transmitter (1)

14A.Mounting plate with 2 mounting screws

for Remove Control

15. Balancing kit (1)

2. Hanger bracket (1)

3. Canopy (1)

4. Canopy cover (1)

5. Ball/downrod assembly (1)

6. Collar cover (1)

7. Fan motor assembly ( 1 )

8. Set of blades brackets (5)

Set of blades (5) (MDF blades)

WARNING

DO NOT INSTALL OR USE FAN

IF ANY PART IS DAMAGED OR MISSING.

CALL TOLL FREE 888-886-1579

16. Loose parts bag containing:

a . Blade attachment hardware (16 screws

and paper washers)

b. Mounting hardware (3 plastic wire

connectors)

c. Set of blade bracket hardware (11 screws)

Unpack your fan and check the contents. You should have the following items:

Tools Required

P h i l l i p s s c r e w d r i v e r , s t r a i g h t s l o t

screwdriver, adjustable wrench, step ladder,

and wire cutters.

Mounting options

If there isn't an existing UL listed mounting

box, then read the following instructions.

Disconnect the power by removing fuses or

turning off circuit breakers.

Secure the outlet box directly to the building

structure. Use appropriate fasteners and

building materials. The outlet box and its

support must be able to fully support the

moving weight of the fan (at least 40 lbs). Do

not use plastic outlet boxes.

Figures 1, 2 and 3 are examples of different

ways to mount the outlet box.

Installing Your Fan 3.

Note: You may need a longer downrod to

m a i n ta i n p r o p er b l ad e c le a r a nc e wh e n

installing on a steep, sloped ceiling.

To hang your fan where there is an existing

fixture but no ceiling joist, you may need an

installation hanger bar as shown in Figure 4

(available at your Hampton Bay Retailer).

Outl et bo x

Figure 2

Outlet box

Figure 1

Provi de st rong

sup por t

Reces sed

out let box

Moun ting brac ke t

ope ning must be

towar d the top

Figure 3

Angled ceiling

maximum

15°angle

Outlet box

Figure 4

Hanging the Fan

REMEMBER to turn off the power. Follow the steps

below to hang your fan properly:

Step 1. Pass the 120-volt supply wires through the

center hole in the ceiling hanger bracket ( Figure 5)

Step 2. Secure the hanger bracket to the ceiling outlet

box with the screws and washers provided with your

outlet box.

Step 3 . Remove the pivot pin, lock pin and set screws

from the downrod assembly.

Step 4. Route wires exiting from the top of the fan

motor through the collar cover, canopy cover, ball,

downrod and ball cover. (Figure 6)

Step 5. Align the holes at the bottom of the downrod

with the holes in the collar on top of the motor

housing (Figure 6). Carefully insert the pivot pin

through the holes in the collar and downrod. Be

careful not to jam the pin against the wiring inside the

downrod. Insert the split pin through the hole near the

end of the pivot pin until it snaps into its locked

position, as noted in the circle inset of Figure 6A.

Step 6. Tighten two set screws on top of the fan

motor firmly. (Figure 6)

Step 7. Place the downrod ball into the hanger bracket

socket.

IF YOU WANT TO CHANGE THE DOWNROD

NOTE: Your fan comes with a 4.5" downrod attached to

the hanger ball. (Longer downrods are available at

Hamton Bay Retailer)

Step 1. Remove the hanger ball from the 4.5" downrod

by loosening the set screw at the top of the downrod

which holds the hanger ball to the downrod.

Step 2. Slide the hanger ball down the downrod and

removet he support pin.

Step 3. Insert the support pin in the holes at the top of

the 66" downrod and slide the hanger ball up the 6"

downrod. M ake sure the support pin is properly seated

in the grooves in the top of the hanger ball.

Step 4. T ighten the set screw firmly.

Please refer to Figure 6A and .Figure 6

WARNING

FAILURE TO PROPERLY INSTALL LOCKING

PIN AS NOTED IN STEP 7 COULD RESULT

IN FAN LOOSENING AND POSSIBLY

FALLING.

4. Hanging Your Fan

Mounting

screws

(supplied with

electrical box)

Hook

Ceiling

mounting

plate

UL Listed

electrical

box

Figure 5 120V Wires

Washers

Split Pin

Collar Cover

Pivot Pin

Motor Collar

Figure 6

Lead Wires

Ball/Downrod

Assembly

Canopy

Pin in

locked

position

Figure 6A

Making the Electrical Connections 5.

Figure 8

Receiver

Mounting

bracket

Figure 7

Code switch

Rubber

cover

Making the Electrical

Connections

WARNING: To avoid possible electrical

shock, be sure electricity is turned off at the

main fuse box before wiring.

NOTE: This remote control unit is equipped

with 16 code combinations to prevent possible

interference from or to other remote units.

The frequency switches on your receiver and

transmitter have been preset at the factory.

Please recheck to make sure the switches on

transmitter and receiver are set to the same

position, any combination of settings will

operate the fan as long as the transmitter and

receiver are set to the same position. (Figure

Step 1. Insert the receiver into the mounting

bracket with the flat side of the receiver

facing the ceiling. (Figure 8)

S t e p 2 . M o t o r t o R e c e i v e r E l e c t r i c a l

Connections: Connect the black wire from

the fan to black wire marked "TO MOTOR L".

Connect the white wire from the fan to

thewhite wire marked "TO MOTOR N" from

the receiver. Connect the blue wire from the

fan to the blue wire marked "For Light" from

the receiver. Secure the wire connections with

the plastic wire nuts provided. (Figure 9)

Step 3. Receiver to House Supply Wires

Electrical Connections: Connect the black

(hot) wire from the ceiling to the black wire

marked "AC in L" from the receiver.

Connect the white (neutral) wire from the

ceiling to the white wire marked "AC in N"

f r o m t h e R e c e i v e r . S e c u r e t h e w i r e

connections with th e pla stic wire nuts

provided. (Figure 9)

S t e p 4 . If your outlet box has a ground wire

( g r e e n o r b a r e c o p p e r ) c o n n e c t i t

to the fan ground wires; otherwise connect

the hanging bracket ground wire to the

m o u n t i n g b r a c k e t . S e c u r e d t h e w i r e

connection with a plastic nut provided. After

connecting the wires spread them apart so

that the green and white wires are on one side

of the outlet box and black and blue wires are

on the other side. Carefully tuck the wire

connections up into the outlet box. (Figure 9)

Figure 10

Outlet box

Mounting

bracket

Canopy

Screw

Finishing the Installation

Step 1. Tuck connections neatly into ceiling outlet box.

Step 2. Remove one screw from the hanger bracket

and loosen the other screw approximately 1/4″.

Step 3. Align the canopy up to ceiling and over the

loosened screw. Place the canopy into key hole and

rotate canopy clockwise. (Figure 10)

Step 4. Secure the canopy by using previous

removed screw.

Step 5. Place the canopy over the canopy and

rotate canopy cover clockwise until locked

into right position.(Figure 10)

6. Finishing the Installation

WARNING

MAKE SURE TAB AT BOTTOM OF HANGER

BRACKET IS HANGER PROPERLY SEATED IN

GROOVE OF HANGER BALL BEFORE

ATTACHING CANOPY TO BRACKET. FAILURE TO

PROPERLY SEAT TAB IN GROOVE COULD CAUSE

DAMAGE TO ELECTRICAL WIRING.

SUPPLY CIRCUIT

Ground

Conductor

Outlet Box

Green

Ground

Lead

Ground to

Downrod

BLACK

WHITE

BLACK

BLUE

GREEN

Figure 9

Canopy Cover

Altri manuali per Bryant

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali HAMPTON BAY Fan

HAMPTON BAY

HAMPTON BAY 7136-01 Manuale utente

HAMPTON BAY

HAMPTON BAY CARROLTON II Manuale utente

HAMPTON BAY

HAMPTON BAY Farmington Manuale utente

HAMPTON BAY

HAMPTON BAY AG524-ORB Manuale utente

HAMPTON BAY

HAMPTON BAY Asbury Plus Manuale utente

HAMPTON BAY

HAMPTON BAY AL958B-BN Manuale utente

HAMPTON BAY

HAMPTON BAY 46-NS Manuale utente

HAMPTON BAY

HAMPTON BAY 290-286 Manuale utente

HAMPTON BAY

HAMPTON BAY ST. DAVID 91344 Manuale utente

HAMPTON BAY

HAMPTON BAY Tripoli II Manuale utente

HAMPTON BAY

HAMPTON BAY BROOKHURST YG268-WH Manuale utente

HAMPTON BAY

HAMPTON BAY BPT18-34A-1 Manuale utente

HAMPTON BAY

HAMPTON BAY MONTGOMERY RDB91-WH Manuale utente

HAMPTON BAY

HAMPTON BAY FB50-16H Manuale utente

HAMPTON BAY

HAMPTON BAY PALM BEACH III 48-PBH Manuale utente

HAMPTON BAY

HAMPTON BAY PT13-13D-1 Manuale utente

HAMPTON BAY

HAMPTON BAY MORESCO 14411 Manuale utente

HAMPTON BAY

HAMPTON BAY SINCLAIR 798-072 Manuale utente

HAMPTON BAY

HAMPTON BAY Clarkston Manuale utente

HAMPTON BAY

HAMPTON BAY Bryant Manuale utente

HAMPTON BAY

HAMPTON BAY WELLTON AM588-BN Manuale utente

HAMPTON BAY

HAMPTON BAY WILLIAMSON 37302 Manuale utente

HAMPTON BAY

HAMPTON BAY HAWKINS II Series Manuale utente

HAMPTON BAY

HAMPTON BAY BAYFIELD Manuale utente

Manuali Fan popolari di altre marche

ELTA FANS

ELTA FANS H03VV-F Manuale utente

Hunter

Hunter 20714 Manuale di istruzioni

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manuale utente

Hunter

Hunter Caraway Manuale di istruzioni

Panasonic

Panasonic FV-15NLFS1 Manuale utente

Kompernass

Kompernass KH 1150 Manuale utente

VES

VES FALA100/12V/TR Manuale utente

Vertiv

Vertiv Liebert DCD Manuale utente

Westinghouse

Westinghouse GFP Series Manuale utente

Venmar

Venmar KUBIX HRV PLUS Series Manuale utente

Maico

Maico ECR 31 Manuale utente

Sonnenkonig

Sonnenkonig Dinky Manuale utente

S&P

S&P ECOWATT HXBR Manuale utente

Wider

Wider IMP03369BH Manuale utente

Panasonic

Panasonic F-60DHN Manuale utente

Hinkley

Hinkley HIGHLAND Manuale utente

Broan

Broan 766BN Manuale utente

Premium

Premium PFS16022 Istruzioni per il montaggio
