Hanna Instruments HI 149-00 Manuale utente

InstructionManual

HI 149-00 • HI 149-01

RemoteProbeThermometer

www.hannainst.com

Foodcare

ACCESSORIES

PROBE EPW: probe with

sharp tip for penetration

PROBE ELW: probe for gen-

eral use and liquids

PROBE ECW: probe for air

and gas

PROBE EMW: surface

probe

90mm

3.5" 195mm

7.7"

90mm

3.5" 235mm

9.3"

90mm

3.5" 240mm

9.4"

90mm

3.5" 270mm

10.6"

SUGGESTIONS FOR USERS

Before using this product, make sure that it is entirely suitable for the environment in which it is

used. Operation of this instrument in residential area could cause unacceptable interferences to

radio and TV equipments, requiring the operator to take all necessary steps to correct interferences.

Any variation introduced by the user to the supplied equipment may degrade the instrument's EMC

performance. To avoid electrical shock, do not use this instrument when voltages at the measurement

surface exceed 24 Vac or 60 Vdc. To avoid damages or burns, do not perform any measurement in

microwave ovens.

WARRANTY

These meters are warranted for two years against defects in workmanship and materials when

used for their intended purpose and maintained according to instructions. The probes are war-

ranted for a period of six months. This warranty is limited to repair or replacement free of

charge. Damages due to accident, misuse, tampering or lack of prescribed maintenance are not

covered. If service is required, contact the dealer from whom you purchased the instrument. If

under warranty, report the model number, date of purchase, serial number and the nature of the

failure. If the repair is not covered by the warranty, you will be notified of the charges incurred. If

the instrument is to be returned to Hanna Instruments, first obtain a Returned Goods Authoriza-

tion Number from the Customer Service department and then send it with shipment costs prepaid.

When shipping any instrument, make sure it is properly packaged for complete protection.

IST149R2 06/05

HI 149 is a portable K-type thermocouple thermometer for

routine checks in the food industry.

Thanks to the user-replaceable probe, HI 149 can be

used in a wide range of applications.

You have a choice of four probes, specifically manufac-

tured to measure the temperature of liquids, air, surface,

solids and semi-solids.

Two models are available for measurement in degrees

Celsius (HI 149-00) and Fahrenheit (HI 149-01).

OPERATION

• Connect one of the four probes (see

accessories) by opening the rear

cover and inserting the 3-pin con-

nector.

• To switch the HI 149 on, open the

front cover as indicated in the pic-

ture, and slide the ON/OFF switch

to the “ON” position.

• The temperature will be displayed

in either °C or °F, depending on

model.

SLIDE

DOWN

°c

OFF

°c

Foodcare

020

Foodcare

BATTERY REPLACEMENT

When the HI149 can not be

switched on or the display fades,

pull out the rear cover, remove

the battery cover and replace all

three batteries, while paying at-

tention to their polarity.

Batteries should only be replaced in a safe area and

using the battery type specified in this instruction manual.

REAR

COVER

PULL

FROM

TOP

BATTERIES

BATTERY

HOUSING

BATTERY

COVER

REAR

COVER

SPECIFICATIONS

HI 149-00 (°C) HI 149-01 (°F)

Range -40 to 300°C -40 to 572°F

Resolution 1°C 1°F

Accuracy ±2°C ±4°F

Typical EMC Dev. ±2°C ±4°F

Probe Interchangeable, stainless steel,

with 1 m (3.3’) cable

Battery Type 3 x 1.5V

Battery Life Approx. 700 hours of continuous use

Environment 0 to 50°C (32 to 122°F); RH max 95%

Dimensions 106 x 68 x 21 mm (4.2x2.7x0.8”)

Weight 80 g (2.8 oz.)

BACK

POCKET

CLIP

TEMPERATURE

PROBE

HOLDERS

TEMPERATURE

PROBE

CABLE

REAR

COVER

FRONT

COVER

FRONT

LIQUID

CRYSTAL

DISPLAY

°c

020

Foodcare

REAR

COVER

REAR

COVER

PULL

FROM

TOP

3-PIN

PROBE

CONNECTOR

• To change the probe, open the rear cover of the unit

and release the probe connector prior to inserting the

new probe.

• When not in use, switch the HI 149 off.

• Variations in readings or fading display can indicate

weak batteries.
