Harbor Freight Tools 62575 Istruzioni per il montaggio
Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 21f
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2021 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
To ol s r eq ui r ed f o r as s em bl y a nd se rvice m ay not be in cluded.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 For technical questions, please call 1-888-866-5797. Item 62575
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
IMPORTANT SAFETY INFORMATION
Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
1. TO REDUCE THE RISK OF ELECTRIC
SHOCK – USE ONLY INDOORS.
2. RISK OF ELECTRIC SHOCK. USE
ONLY IN DRY LOCATION. Keep
remote and receivers dry, and do
not use them if they are wet.
3. Do not use to control equipment
that may be dangerous to turn
on remotely, such as power
tools or appliances with moving
or heating parts. Do not use to
control equipment that is not
within your line of sight.
4. When not in use, turn off equipment
connected to the Wireless Remote
System using the equipment’s switch
or unplug it from the Plug-In Receiver
to prevent accidental starting.
5. Inspect before every use; do not
use if parts loose or damaged.
6. Do not exceed rating.
7. Keep area near receiver clean.
Cluttered areas invite accidents.
8. Mount receivers out of children’s reach.
9. Remote contains button cell battery.
Keep remote out of reach of children.
Discard used batteries immediately.
10. Maintain products with care. Keep
the Wireless Remote System clean
for better and safer performance.
Inspect the components periodically.
If damaged, have it repaired
by a qualified technician.
Page 3For technical questions, please call 1-888-866-5797.Item 62575
11. The warnings, precautions, and
instructions discussed in this instruction
manual cannot cover all possible
conditions and situations that may
occur. It must be understood by the
operator that common sense and
caution are factors which cannot
be built into this product, but must
be supplied by the operator.
SAVE THESE INSTRUCTIONS.
Specifications
Electrical Rating 120 VAC / 15 A / 1875 W
Range 80 Feet
Battery Type CR2032 Lithium 3 V
Ultrasonic Frequency 315 mHz
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC ID – Transmitter: 2AAFT-KQ02TX-01
FCC ID – Receiver: 2AAFT-KUQ02RF-01
Page 4 For technical questions, please call 1-888-866-5797. Item 62575
Setup Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the
beginning of this document including all text under subheadings therein
before set up or use of this product.
Battery Setup
1. Slide out the Battery Cover on the
side of the Remote Control unit.
2. Carefully remove protective tape from
battery. Replace the Battery Cover.
Installing Plug-In Receivers
1. Plug light/appliance to be controlled
into the outlet on the Plug-In Receiver.
2. Plug the Receiver unit into any
standard indoor 120 VAC wall outlet.
3. Use only one Plug-In Receiver per
AC outlet. Maintain a minimum
distance of 24 inches between
individual Receiver units.
Note: Do not install Plug-In Receivers
where they are blocked by large metal
objects or metal doors. Such obstructions
may reduce the receiving range.
Page 5For technical questions, please call 1-888-866-5797.Item 62575
Components and Controls
Remote
Control
Plug-In Receiver
Control
Buttons
Battery Cover
(on side)
1
2
3
Page 6 For technical questions, please call 1-888-866-5797. Item 62575
Operation
Operation
1. The Remote Control has three buttons
numbered 1, 2, and 3 which control
the respective Plug-In Receivers
numbered 1, 2, and 3.
The Wireless Remote System is
operated by pressing the desired
button on the Remote Control to
turn the power ON or OFF at the
corresponding Plug-In Receiver.
2. Make sure the device to be controlled
has its switch turned on and is plugged
into the Plug-In Receiver, then press
the appropriate button on the Remote
Control to turn the device ON or OFF.
Note: Allow at least 3 seconds after
pressing any button on the Remote
Control for signal transmission to
finish before pressing it again.
3. If the Plug-In Receiver does not activate,
try relocating the Receiver or move the
Remote Control to another position.
Battery Replacement
1. Slide out the Battery Cover on the
side of the Remote Control unit.
2. Remove used battery and dispose
of according to all applicable
regulations. Contact your local
hazardous waste authority for proper
battery disposal guidelines.
3. Install a new CR2032
Lithium 3 V battery.
4. Replace the Battery Cover.
Page 7For technical questions, please call 1-888-866-5797.Item 62575
Record Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Replacement parts are not available.
Note: Reference UPC 792363625753.
Maintenance
Procedures not specifically explained in this manual must be performed
only by a qualified technician.
TO PREVENT SERIOUS INJURY FROM TOOL FAILURE:
Do not use damaged equipment. If abnormal noise or vibration
occurs, have the problem corrected before further use.
Cleaning, Maintenance, and Lubrication
1. BEFORE EACH USE, inspect the
general condition of the tool. Check for:
• leaking, swollen, or cracked battery
• loose hardware
• misalignment or binding of parts
• cracked or broken parts
• any other condition that may
affect its safe operation.
2. AFTER USE, wipe external surfaces
of the tool with clean cloth.
3. Replace the battery in the Remote
Control unit when necessary to
maintain proper performance.
WARNING! Discard used battery in a
trash receptacle out of reach of children.
4. Replacement parts are not available.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER
OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE
BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR
THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE
MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS
REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS,
AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF
HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO,
OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality
and durability standards, and warrants to the original purchaser that this product is free from
defects in materials and workmanship for the period of 90 days from the date of purchase.
This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence
or accidents, repairs or alterations outside our facilities, criminal activity, improper installation,
normal wear and tear, or to lack of maintenance. We shall in no event be liable for death,
injuries to persons or property, or for incidental, contingent, special or consequential damages
arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to you.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation
charges prepaid. Proof of purchase date and an explanation of the complaint must accompany
the merchandise. If our inspection verifies the defect, we will either repair or replace
the product at our election or we may elect to refund the purchase price if we cannot readily
and quickly provide you with a replacement. We will return repaired products at our expense,
but if we determine there is no defect, or that the defect resulted from causes not within
the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also
have other rights which vary from state to state.
26541 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
