OWNER'S MANUAL
Infinity Kappa Perfect PowerSports
AMPLIFIERS
1
THANK YOU FOR YOUR PURCHASE . . .
Your product has been designed to provide you the performance and ease of operation you
expect from Innity. Take time to read this manual before operating or installing your amplier.
This manual describes general installation guidelines and operation instructions. Please note that
proper installation of mobile audio components requires qualied experience with mechanical and
electrical procedures. If you do not have the knowledge and tools to perform this installation, we
strongly recommend consulting an authorized Innity dealer about your installation options.
INFINITY KAPPA
2
TABLE OF CONTENTS
THANK YOU FOR YOUR PURCHASE . . . 1
WHAT'S IN THE BOX 3
INSTALLATION AND WIRING 4
Mounting the Amplier 4
Wiring the Amplier 4
Power and Ground Connections – Direct Hardwire 5
Power/Protect indicators 6
Line-level Signal Input 6
Speaker-level Signal Input 7
Speaker-level Input – Direct Connection 8
INPUT LEVEL SELECTION 9
Speaker Output Connections 9
Speaker Output – Direct Connection 10
SETTING THE SOUND 15
Setting the input level 15
Crossover lters 15
SPECIFICATIONS 16
TROUBLESHOOTING 18
3
WHAT'S IN THE BOX
(KP3002)
1
2
3
5
4
67
8
(KP5004)
1amplier
2tie wraps
3spare fuse
4Stainless steel mounting hardware
5Black zip ties
6Innity stickers
7end panel covers
8owner’s manual
INFINITY KAPPA
4
INSTALLATION AND WIRING
IMPORTANT: Disconnect the vehicle’s negative (–) battery terminal before beginning the
installation.
Mounting the Amplier
• Wear protective eyewear when using tools.
• Choose a safe mounting location. Check clearances on both sides of the location. Be sure that
screws will not puncture brake or fuel lines or wiring harnesses, and that wire routing will not interfere
with vehicle operation. Use caution when drilling or cutting.
• When making electrical connections, make sure they are secure and properly insulated.
• Do not mount the amplier with the heat sink facing downward, as this interferes with cooling.
• Using the amplier as a template, mark the locations of the holes on the mounting surface.
• Drill pilot holes in the mounting surface.
• Attach the amplier to the mounting surface with sheet metal screws.
Wiring the Amplier
Kappa Perfect ampliers feature wire plugs that allow you to make all connections using optional
mating connectors (sold separately). You can also remove the plugs to make direct wiring
connections.
Power and Ground Connections Using an Optional Mating Connector
• First, prepare the mating connector (sold separately) in the vehicle. Strip a short length of the
jacket from the power, ground, and remote turn-on wires from the vehicle. Crimp the terminals
onto the ends of each wire. Insert each wire into the appropriate pin location in the mating
connector housing (see chart below). Push rmly to secure the wires in the housing, then snap
the back panel of the housing into place.
Remote turn-on
Power
Ground
P3 P2 P1
• When all connections are made, plug the connector from the amplier into the mating connector.
5
Mating power wire terminals part number: KP3002: HRB T9910PS-2
KP5004: HRB T9910PS-2A for remote turn-on,
T9910-2A for Power and Ground
Mating connector housing part number: HRB P9910-3-B-H-A/B
Mating connector housing HRB P9910-3-B-H-A/B wire conguration
Pin Wire Corresponding Amplifier Wire Color
1Remote turn-on Blue
2Power Red
3Ground Black
Power and Ground Connections – Direct Hardwire
• Use wire cutters to remove the connector from the amplier wiring harness. Then, strip a short
length of the jacket from each wire.
• Power: Connect the +12V power wire to the positive terminal of the vehicle’s battery. Make sure
the fuse and fuse holder are within 18" (457mm) of the battery.
INFINITY KAPPA
6
• Ground: Connect the GND wire to the negative terminal of the vehicle’s battery, or to the
vehicle’s chassis near the battery with a screw. NOTE: If possible, remove any paint from the
chassis for best contact. It’s recommended to use a star washer below the ring connector for a
secure connection.
• Remote: Connect the remote turn-on wire to the “Remote Out” lead of the source unit, if using
low-level signal inputs with an aftermarket stereo. NOTE: If you’re using high-level signal inputs
(your vehicle’s speaker wires), the Kappa Perfect amplier’s 12-volt DC oset feature will turn the
amplier on when it senses audio signal. In this case, you will not have to connect the remote
turn-on wire and can tape or cap it o to prevent the introduction of noise.
POWER
PROTECTION
Battery
Remote turn-on (to stereo)
Fuse holder
Chassis ground
（-）
Power/Protect indicators
The power light will illuminate in green when the amplier is getting power and playing. The light
will illuminate in red if the amp enters protect mode in the event of conditions such as over/under
voltage, short circuit, amplier output circuit failure, or excessive heat.
Line-level Signal Input
• If your source unit oers preamp outputs, connect to the amplier’s L and R preamp inputs using
RCA patch cables.
7
Speaker-level Signal Input
Speaker-level Input with Optional Mating Connectors
• If your audio system’s source unit does not have line-level outputs, connect the speaker-level
input wires from the amplier to the front and/or the rear speaker output wires of your source
unit.
• If using the amplier wiring plugs, rst, prepare the mating connector (sold separately) in the
vehicle. Strip a short length of the jacket from the speaker wires coming from the source unit in
the vehicle. Crimp the terminals onto the ends of each wire. Insert each wire into the appropriate
pin location in the mating connector housing (see chart below). Push rmly to secure the wires in
the housing.
Left -
Right - Right +
Left +
Rear view
3
42
1
• When all connections are made, plug the amplier connector into the mating connector.
Mating power wire terminals part number: Molex 039000039
Mating connector housing part number: Molex 039012040
INFINITY KAPPA
8
Mating connector housing 039012040 wire conguration for front channels (KP5004 and
KP3002)
Pin Wire Corresponding Amplifier Wire Color
1Front left + White
2Front right + Gray
3Front left - White/Black
4Front right - Gray/Black
Mating connector housing 039012040 wire conguration for rear channels (KP5004 only)
Pin Wire Corresponding Amplifier Wire Color
1Rear left + Green
2Rear right + Purple
3Rear left - Green/Black
4Rear right - Purple/Black
Speaker-level Input – Direct Connection
• Use wire cutters to remove the connector from the amplier wiring harness. Then, strip a short
length of the jacket from each wire.
• Splice the speaker-level input wires for the amplier to the speaker wires coming from the
source unit in the vehicle. Use solder, butt connectors, or your preferred splicing method. The
12-volt DC oset feature will turn the amplier on when it senses signal.
9
INPUT LEVEL SELECTION
If you’re sending signal to the amplier using low-level outputs from your source unit, slide
the input level selector to “LO.” If using high-level outputs from your source unit, slide the
selector to “HI.”
Speaker Output Connections
Speaker Output with Optional Mating Connectors
• If using the amplier wiring plugs, rst, prepare the mating connector (sold separately) in the
vehicle. Strip a short length of the jacket from the speaker wires going to the speakers in the
vehicle. Crimp the terminals onto the ends of each wire. Insert each wire into the appropriate pin
location in the mating connector housing (see chart below). Push rmly to secure the wires in the
housing.
3
42
1
Left -
Right - Right +
Left +
Rear view
• When all connections are made, plug the amplier connector into the mating connector.
Mating power wire terminals part number: Molex 039000077 (KP5004) or 039000039 (KP3002)
Mating connector housing part number: Molex 039039042
INPUT
LEVEL
HI LO
