Hearing Help Express HHE-6205 Manuale utente

an IntriCon company

My eartip style & size:

My tubing size:

My battery size: 312 (brown tab)

PROVEN QUALITY

AMERICAN-MADE

TECHNOLOGY

HHE-6205

Digital Hearing Ampli er

User Guide

1-800-221-2099

•Feedback Management •Noise Reduction

•Directional Microphones •Telephone Setting

•Rocker Style Volume Control

21-800-221-2099 • HearingHelp.com

Where relationships begin with Value & Service

and thrive on Quality and Trust.

an IntriCon company

Welcome to Hearing Help Express and congratulations on your choice

of the HHE-6205 Hearing Amplifier! Rest assured that you’re receiving

a high-quality hearing amplifier. The computer chip found inside your

HHE-6205 was manufactured by our parent company, IntriCon, a Class

III medical device manufacturer right here in the USA. With their

help, we’re able to bring you high-quality devices and keep prices low,

passing the savings on to you.

I’m confident you’ll enjoy all the benefits the HHE-6205 has to offer,

especially knowing how little you paid for your HHE-6205 Hearing Amplifier.

So, put yourHHE-6205to the test and find out if it’s right for you.We only askthat

you read these instructions to make the most of your 30 day home trial.

For your better hearing.

Remember, our licensed hearing professionals and hearing advocates are

always here to help.

Call toll-free: 1-800-221-2099 (Monday - Friday • 7:30 am - 5 pm CST)

Chat with us online: HearingHelp.com

or email us at: [email protected]om

Jim Houlihan

President

Jim

A+

RATING

Introduction

Table of contents

Parts identified

Intended use and technical data

How to insert battery

Slim-tubing choices

Which is left and right

Removing & attaching slim-tube

Eartip choices

Inserting & removing HHE-6205

Volume control / Program settings

Care and cleaning

Troubleshooting/Service

Service Plans

Additional Info

Accessories

Helpful tips

Warranty

13-14

Table of Contents

Get to know your HHE-6205 hearing ampli er

Parts Identified

1-800-221-2099 • HearingHelp.com

1. Program button

2. Volume control (rocker)

3. Battery door

4. Slim-tubing

5. Eartip

6. Sure-lock

Serial number is located on the

outer casing of hearing amplier

On With a battery installed,

close the battery door to

turn the HHE-6205 on.

Open the battery door to

turn the HHE-6205 off.

Battery Size: 312

(brown tab)

IMPORTANT NOTICE:Do not mark on or damage the amplier during your

30-day trial (damage fees may apply). If you need help identifying the left amplier

from the right amplier see page 5 or give us at call 1-800-221-2099.

Off

Battery type and current

Battery life

Dimensions

size 312 (Brown), .9 mA

approx. 200 hours

1.25 x .5 x .29 inch

Technical Data

Intended Use:Personal Sound Amplifiers (PSAPs) are intended to

amplify environmental sound for non-hearing impaired consumers. They

are intended to accentuate sounds in specific listening environments, rather

than for everyday use in multiple listening situations. They are not intended

to compensate for hearing impairment or to address listening situations

that are typically associated with and indicative of hearing loss. Examples of

situations in which PSAPs typically are used include hunting (listening for

prey), bird watching, listening to lectures with a distant speaker, and listening

to soft sounds that would be difficult for normal hearing individuals to hear.

41-800-221-2099 • HearingHelp.com

Inserting the Battery

1. Remove the brown colored tab from the flat, (+)

positive side of the size 312 battery. Wait one minute

for battery to reach full power before using (or

testing) battery.

2. Open battery holder gently, using your fingernail or

thumbnail. Pull out on the small lip of the battery

holder located on the lower part of the HHE-6205.

3. Locate the + symbol on the inside top rim of the

battery holder. This indicates that the flat, positive

side of the battery should face up in the same

direction as the + symbol.

4. Place the battery in the battery holder –

NOT directly inside the HHE-6205.

Fit the battery in the holder with the

flat, positive (+) side facing up.

5. Close the battery holder.

NEVER force the battery holder closed.If the holder does not close easily

then the battery is probably upside down.

LOW BATTERY INDICATOR: When the battery is no longer strong enough to

power your HHE-6205, you will hear 2 beeps then a pause then 2 beeps again.

This will repeat until you replace the battery.

✓Best battery value

✓Home delivery

✓Fresh! Fresh! Fresh!

✓FREE shipping

You always get:

Eco-Gold MAX

LONG-LASTING!

Premium batteries for less!

Your HHE-6205 uses a size 312

(brown tab) zinc-air battery.

Try using the battery magnet located

on the end of the enclosed cleaning tool.

1-800-221-2099 • HearingHelp.com

There are four sizes of slim-tubing available for the right

and left ear. Attached to your HHE-6205 is the size we

feel works best for most people. We have also included an

additional size slim-tubing for you to try if needed.

Additional sizes are available by calling 1-800-221-2099.

Right slim-tubing: 0R, 1R, 2R, 3R

Left slim-tubing: 0L, 1L, 2L, 3L

Which is left and right: Your HHE-6205 can be

used in either ear by selecting a right slim-tubing

or a left slim-tubing. Each slim-tubing is preformed

to “point” into either the right or left ear.

Right slim-tubing has red lettering

Left slim-tubing has blue lettering.

It’s important for the slim-tubing to fit correctly: slim-tubing should

fit snugly against your ear once the HHE-6205 and eartip are in place. If not,

the slim-tubing may be too short or too long. Try a different slim-tubing length.

If you need a different size slim-tube simply call 1-800-221-2099.

Picturing Left ear slim-tubing

Slim-tube Choices

Removing & Attaching Slim-tube

REMOVING slim-tubing from the HHE-6205:

Grasp the thicker base of

the slim-tubing near the

top of the HHE-6205.

Twist the tubing 90

to the le or right.

Pull the thicker base

of the tubing away

from the HHE-6205.

ATTACHING slim-tubing to the HHE-6205:

Line up the top of the HHE-6205 and the thicker tubing base and

gently push the end of the slim-tube onto the HHE-6205 until

it snaps into position.

Attention: Please make sure eartips and slim-tubing are securely

attached before using so they do not come off in your ear.

3L 2L 1L 0L

Set for left ear. Set for right ear.

61-800-221-2099 • HearingHelp.com

Eartip choices

We offer a variety of eartip options. We have attached the eartip style that we feel

works best for most. Also included are several other eartip options.

If you have trouble with the fit of the eartip or if you experience feedback (squeal),

give the other eartips a try.

How to Attach Dome Eartips:

1. Line up the narrow tubing nozzle with the opening on the

inside of the eartip.

2. Push together firmly until the eartip is securely attached.

Wiggle the eartip to be certain it stays in place.

How to Remove Dome Eartips:

1. Hold the eartip tightly and grasp the tubing directly behind the eartip. Pull firmly.

(Replace eartips as needed.)

Vent

How to Remove the ZipTip:

1. Hold the ZipTip tightly and grasp the tubing directly behind the ZipTip.

2. Pull firmly. (Replace ZipTips as needed, if damaged or worn.)

NOTE: There is a small sleeve inside the ZipTip that may remain on the end of the tubing when removing.

If this happens, simply re-attach the ZipTip, grasp that area of the ZipTip tightly and pull away from the tubing.

How to Attach the ZipTip:

1. Line up the narrow tubing nozzle with the opening on the inside of the

ZipTip (the hole that goes through the longest portion of the ZipTip).

2. Push together firmly until the ZipTip is securely attached. Wiggle the ZipTip to be certain it stays in place.

Tulip dome eartip: Designed to help reduce feedback. Provides a great

fit for a wide variety of ear canal shapes and sizes. Available in one size.

Open dome eartips: Helpful for those using their amplifier on a very low

volume setting. Available in sizes small, medium and large.

Closed dome eartip: Designed to reduce feedback (squeal) for those

using their amplifier on a medium volume setting.

Available in sizes small, medium and large.

Double dome eartips: Designed for those that struggle with feedback

(squeal) due to using the amplifier on a higher volume level.

Available in sizes small, medium and large.

ZipTip eartips: The ZipTip eartips can be helpful if you experience a

stuffed up feeling or it sounds like you are talking in a barrel. Available in

sizes small and medium and both are available with a small or large vent.

1-800-221-2099 • HearingHelp.com

How to insert the HHE-6205:

1. Grasp the slim-tubing behind the eartip and

gently push the eartip into your ear canal.

2. Place your HHE-6205 over the

top of your ear.

3. The slim-tubing will probably bulge slightly near

the ear canal. Point at the bend in the tubing and

push gently. The eartip should slip a little further

into the ear canal for proper placement. The

tubing should fit snugly against your ear.

Note: If pushing on the slim-tubing causes discomfort, STOP.

Call for assistance. 1-800-221-2099

4. Place the sure-lock into the bowl of

your ear. The sure-lock is the thin

filament attached to the tubing. Use

your finger to secure the sure-lock into

the most comfortable position.

Inserting & removing your HHE-6205

To Remove HHE-6205:

1. Grasp hold of the slim-tubing against your ear and gently pull.

The eartip will slip out of your ear.

2. Remove the HHE-6205 from behind your ear.

NOTE: Tubing should not bulge away from the ear or

pull the HHE-6205 down or the eartip out of the ear.

If this occurs, try a different length tubing. See picture

to the right.

ATTENTION: Confirm the eartip is attached to the slim-tubing each time you

remove it from your ear. If the eartip remains in your ear, seek medical assistance.

81-800-221-2099 • HearingHelp.com

Volume Control:

Your HHE-6205 is equipped with a rocker style volume

control that allows you to select from 10 volume levels.

Increasing the volume: Each time you push the top end of

the rocker control, you’ll increase one volume level.

Decreasing the volume: Each time you push the bottom

end of the rocker control, you’ll decrease one volume level.

Adjusting the Volume Control

Program Control:

Press and hold the program button for about 2 seconds to

select your preferred program setting.

Program 1: Normal setting – You will hear 1 beep.

Use in most listening situations.

Program 2: Noise setting – You will hear 2 beeps.

Reduces the amount of low frequency amplification. Often helpful

in noisy situations.

Program 3: Whistle reduction – You will hear 3 beeps.

Use if your HHE-6205 whistles or if sounds seem too sharp or tinny.

Program 4: Telephone setting – You will hear 4 beeps.

Use when talking on the telephone or with a loop system. Hold the

telephone receiver near the hearing amplifier a little above your ear.

You will only hear sounds from the telephone or loop system.

Choosing your Program Setting

Top

Bottom

– You will hear 1 beep.

1-800-221-2099 • HearingHelp.com 9

We’ve done what we can to protect your HHE-6205 from moisture and

earwax but a little regular cleaning by you will go a long way towards

trouble-free use. Without regular cleaning, wax and moisture can build up

and prevent your HHE-6205 from working properly. We suggest cleaning

your HHE-6205 in the morning before you use it and storing it overnight

in a DryAid Dehumidifier (call to order). It does not take much dirt or wax

to clog the super-thin tubing and the tiny openings. Many customers find

cleaning the tubing weekly is sufficient.

Cleaning your HHE-6205:

1. Wipe off the outside of the HHE-6205 hearing amplifier and eartip

with a soft cloth or cleaning wipes (call to order).

2. Use the included cleaning brush and tube cleaning tool to gently

remove wax and dirt from the amplifiers sound openings.

How to clean your HHE-6205 slim-tubing:

1. REMOVE THE SLIMTUBING from the HHE-6205 (see pg. 5).

There is no need to remove the eartip from the tubing.

2. Insert the cleaning tool into the triangular base at the end of the

slim-tubing.

3. Thread the cleaning tool all the way through the slim-tubing and out

of the end of the eartip.

4. Wipe off any debris on the end of the cleaning tool before pulling it

back through the eartip and slim-tubing.

Purchase replacement slim-tubing

cleaning tools by calling 1-800-221-2099.

Care and cleaning

Purchase replacement slim-tubing

cleaning tools by calling 1-800-221-2099.

10 1-800-221-2099 • HearingHelp.com

If your HHE-6205 is: WHISTLING (FEEDBACK)

1. Turn the volume down, it may be set

too high (pg. 8).

2. Use program setting #3 (pg. 8).

3. Check that your eartip is inserted

correctly (pg. 7).

4. Try a different size eartip

(pg. 6).

5. Verify the tubing is attached correctly.

Slim-tubing should be in good

condition. If the tubing has hardened

or is damaged, it should be replaced

(pg. 5).

6. Your HHE-6205 may briefly whistle

when a hand, hat or other object is

near it or when you are inserting and

removing the amplifier.

1. Check that the battery is inserted

correctly (pg. 4).

2. Try a fresh battery.

3. Clean your HHE-6205, microphone

ports, and eartip (pg. 9).

4. If your HHE-6205 goes dead

periodically, but comes on after

several hours of rest, the problem

may be a build-up of humidity. Try

storing it in a DryAid dehumidifier

when not in use (pg. 14).

If your HHE-6205 Hearing Amplifier requires service, send it to:

Hearing Help Express

1714 Sycamore Rd • PO Box 586 • DeKalb, IL 60115-0586

If your HHE-6205 is: WEAK, DISTORTED, DEAD

1.Call 1-800-221-2099 for

authorization before returning

your amplifier(s) for repair.

2.Enclose a note with your name,

address, phone number and a

description of what is wrong with

your device.

3.Pack your device securely in a

sturdy box. (Do not mail your

amplifier(s) in an envelope,

they could be destroyed during

shipment). We recommend

insured mail or UPS for your

protection.

Troubleshooting your HHE-6205

Service

Indice

Altri manuali Hearing Help Express Apparecchio acustico

Hearing Help Express

Hearing Help Express EarMate-4330 Diamond Manuale utente

Hearing Help Express

Hearing Help Express Hansaton Style Pro Manuale utente

Hearing Help Express

Hearing Help Express Felix-8740 Accu-Fit Manuale utente

Hearing Help Express

Hearing Help Express Apollo-E600 Manuale utente

Hearing Help Express

Hearing Help Express EarMate-4210 CLEAR Manuale utente

Hearing Help Express

Hearing Help Express Apollo-6210 Eagle Manuale utente

Hearing Help Express

Hearing Help Express EarMate-4220 Manuale utente

Hearing Help Express

Hearing Help Express EarMate-4330 Diamond Manuale utente

Hearing Help Express

Hearing Help Express Apollo-6205 Falcon Manuale utente

Hearing Help Express

Hearing Help Express Apollo-E600 Manuale utente

Hearing Help Express

Hearing Help Express Apollo-6310 Puma Manuale utente

Hearing Help Express

Hearing Help Express APOLLO-6670 Manuale utente

Hearing Help Express

Hearing Help Express RANGER-8720 Manuale utente

Hearing Help Express

Hearing Help Express Ranger-7600 Manuale utente

Manuali Apparecchio acustico popolari di altre marche

Sonic

Sonic Bliss miniBTE Manuale utente

Lexie

Lexie B1 Manuale elenco delle parti

Widex

Widex FM+DEX Manuale utente

Siemens

Siemens Triano Manuale utente

Camplicomms

Camplicomms HC-200 Manuale utente

Widex

Widex SUPER 220 S2-VSD Manuale utente

Phonak

Phonak Q90 Manuale utente

Williams Sound

Williams Sound SoundPlus WIR 237 Guida

Oticon Medical

Oticon Medical Ponto SoundConnector Manuale utente

Siemens

Siemens Life micon Manuale utente

Starkey

Starkey Destiny Manuale utente

Audicus

Audicus The Icon Manuale utente

Advanced Bionics

Advanced Bionics Slim HP Standard Manuale utente

Widex

Widex DREAM440 THE DREAM SERIES Manuale utente

Phonak

Phonak myPilot Manuale utente

NIKEN

NIKEN NK-401 Manuale utente

ON Semiconductor

ON Semiconductor Ezairo 7111 Pre Suite Manuale utente

Sonetik

Sonetik GOHEAR Manuale utente
