Helo 1601-12 Manuale utente
User Guide
Digital control panel Digi II
Model 1601-12
User Guide for the following
models of contactor boxes
WE3 2005-3
WE4 2005-4
WE5 2005-5
2
ControlpanelDigiII
Thank you for choosing quality
products from Saunatec
Pentti Piisku, President, Saunatec Group OY
UserGuideDigitalcontrolpanelDigiII
Copyright©2004.SaunatecGroup OY.Allrights reserved
We think that our products will live up to your expectations and give you many hours of
enjoyment in your sauna. We want you, your family and your friends to have many
comfortable sauna baths and at the same time find new ways to enjoy sauna bathing. We
have taken today’s demands on sauna bathing into consideration and equipped the sauna
heater with many usable and unique functions. Among other things, the control panel has
four memory buttons, which can be pre-programmed to your personal favorite sauna bath.
Read this manual carefully. The manual is divided into two separate sections. The first is for
you as a user and the second is for the installer.
Saunatec is the world-leading producer of products for saunas and steam saunas. We
develop, produce and market products for saunas and steam saunas in the whole world.
Saunatec has the largest factories of sauna products in the world (Finland, Germany and
USA) and a well-developed net of retailers, both nationally and internationally. Our product
range consists of sauna- and steam rooms, electric and wood heaters, control panels and
sauna accessories.
3
ControlpanelDigiII
Information to the user
This user guide helps you to understand and use your new sauna products. We hope that
you read this manual carefully and that you respect the warning texts.
The user guide is divided into two sections: Information to the user and Information to
the installer. You, as a user, receive a thorough description of the workings of a sauna
heater, how to use the control panel and what you should keep in mind regarding
maintenance.
If you have questions or if you need help with the products, please turn to your local retailer.
Certain portions of the user guide are more important than others. At these portions we use
the following symbols:
The control panel and included parts ........................4
Functions of the control panel
- Set the time and chose the language ...................6
- Set the start time ...................................................7
- Set the temperature...............................................8
- Set the duration .....................................................8
- Program and activate the memory buttons ...........9
- Change the settings during the sauna bath........10
- Calibrate the temperature .................................... 11
- Activate Smartsauna ........................................... 11
- Lock the control panel .........................................12
- Lock fan or lighting ..............................................12
Alarm ........................................................................13
Connect the electricity..............................................14
Mount and program the control panel ......................15
Table of contents for the user
!
Warning Observe Tips and advice
4
ControlpanelDigiII
The control panel and included
parts
88O C
13:28
04:51
*The control panel gives you the
opportunity to set four separate
sauna baths. We recommend
that you utilize the useful
function of the memory buttons.
Read more on page 9.
Observe Tips and advice
Activate function (OK)
Page upwards in the menu
Page downwards in the menu
The button prog ok The display
Temperature
Start time
Duration
On/Off
Temperature
Start time
Duration
*Lighting
*Ventilation
Display
Memory button 1
Memory button 2
Memory button 3
Memory button 4
Iflightingandventilationhavebeen
connected to the control panel,
you can activate them with the
appropriatebuttons. If they are not
connected, contact your retailer
or a certified electrician.
You access the settings of the
controlpanel(clockand language)
by pushing the button prog ok
for three seconds when the panel
is not on.
5
ControlpanelDigiII
Functions of the control panel
With the control panel, you set the time for the heater to start, for how long it will work and
the temperature in the sauna. It is also possible to program four memory buttons for special
sauna baths. This means that you only need to push one button to start the heater.
To start the sauna heater, you need to adjust the following parameters:
1. Start time – when the heater is to start.
2. Temperature – the temperature in the sauna.
3. Duration – the length of time the heater is to be on
.
Memory buttons:
We recommend that you take advantage of the memory buttons when using your sauna.
You can easily enter your preferences on separate buttons. When it is time to take a sauna
bath you activate them with a single push. Each memory button has preset values when
the control panel is delivered from the factory. Read more about memory buttons on page 9.
Basic settings:
Before you use the sauna, you need to set the basic settings on the control panel. These
basic settings are setting the time and choosing the language. Read more about basic
settings on page 6.
You easily set the
temperature with the
digital control panel.
MENU 1
CLOCK:
Youset thetimebyprogrammingin themenu-
mode.See moreinformationon page6.
12:00
6
ControlpanelDigiII
1. Push the button
prog ok for three
seconds
The display shows:
2. Set the time with the
arrow buttons
3. Approve the new
time with the button
prog ok
Set the time and chose the
language
The control panel returns automatically to the off-mode from the menu-mode if you do not push
a button within three seconds. If a change is done it must be approved with the prog ok button
before the control panel resumes off-mode, otherwise the change is not saved.
Observe
If there is a power failure of more than 20 minutes, the time is deleted from the
control panel. Then you have to reprogram the setting.
The control panel has five languages to chose from: Finnish, English, Swedish,
German and Dutch.
Set the time
MENU 1
CLOCK: 12:08
Make sure that the control panel
is in off-mode before you set the
time
Chose language
Make sure that the control panel
is in off-mode before you chose
language.
1. Push the button
prog ok for three
seconds
2. Page to Menu 2 by pushing
the button prog ok
The display shows:
3. Chose the new
language with the
arrow buttons
4Approve the new
language with the
button prog ok
MENU 2
LANGUAGE: ENGLISH
7
ControlpanelDigiII
Set start time, temperature and
duration
Set the start time
The start time is the time that the
heater turns on, for example 18:30.
1. Start the panel with the
On/Off button
The background lighting
is lighted
2. Push the button
prog ok
The display shows earlier chosen
settings, for example:
3. Push the button for
start time
The display shows:
4. Set start time, for example
18:30, with the arrow
buttons
5. Approve the start time
with the button prog ok
The display shows:
6. Start the heater by
pushing prog ok for
three seconds.
1
By holding the arrow button
depressed the values are
paged up or down fast.
Tips and advice
70OC
14:00
01:30
START TIME:
14:00
70OC
18:30
01:30
8
ControlpanelDigiII
Set the tempera-
ture
The temperature is the tempera-
ture that the heater produces in the
sauna, for example 80° C.
1. Push the button for
the temperature
The display shows:
2. Set the temperature
with the arrow buttons,
for example 80° C
3. Approve the tempera-
ture with the button
prog ok
The display shows:
4. Start the heater by
pushing prog ok for
three seconds.
2
TEMPERATURE:
70OC
Set the duration
Duration is the time that the heater
will operate. Maximum duration is
six hours.
1. Push the button for
start time
The display shows:
2. Enter duration with
the arrow buttons,
for example 30 minutes
3. Approve the duration
with the button
prog ok
The display shows:
4. Start the heater by
pushing prog ok for
three seconds.
3
ON-TIME:
01:30
80O C
18:30
01:30
Turn on the
lightning
1. Push the button for lighting
The display shows:
Activate ventilation
1. Push the button for
ventilation
The display shows:
80O
C
18:30
01:30
9
ControlpanelDigiII
Program and activate the
memory buttons
The digital control panel has four
memory buttons. As a user you have
the opportunity to set four separate
sauna bath programs. Each program
has its owns adjustments, and you
activate them with just a push of a
button.
When the control panel is delivered
from the factory the memory buttons
are pre-set. It is a good idea, however,
to change the settings so that you get
the sauna bath of your choice. Set the
temperature and duration of the sauna
heater according to earlier instructions
(see page 10).
The preset values of the memory
buttons are:
Duration: Two hours
Temperature: Button 1: 60OC
Button 2: 70OC
Button 3: 80OC
Button 4: 90OC
Program a
memory button
1. Enter a duration on the control
panel
2. Enter a temperature on the
control panel
3. Push one of the memory
buttons
4. Push the button prog ok
Activate a memory
button
1. Start the control panel with the
On/Off button
2. Push one of the memory buttons
Check a memory
button
1. Make sure that the control panel
is in Off-mode. The display is
not lighted.
2. Push a memory button and read
the settings. The display is
lighted.
Memory
buttons
10
ControlpanelDigiII
Change the settings during the
sauna bath
14:00
To change the settings during the
sauna bath does not change the
values in the memory buttons.
The change only affects the
ongoing sauna bath.
The instructions below show how to change the settings during the sauna bath. You may
want to lower the temperature or shorten the duration.
Observe
1. Push the button for
temperature
2. Set the new temperature
with the arrow buttons
3. Approve the new
temperature with the
button prog ok
Change the
temperature 1. Push the On/Off button
The display shows:
Turn off the sauna
1. Push the button for
duration
2. Set the new duration
with the arrow buttons
3. Approve the new
duration with the
button prog ok
Change the
duration
