1) Install a 1/4 in. npt male coupler, that is compatible with
the quick disconnect of your air supply line, into the air
supply port of the filter/regulator located on the right rear
leg [see fig. 9].
2) Connect air line with at least 75 psi to the coupler.
Filter/regulator is preset. Do not adjust.
Operation
Filling the Gun Washer with Fluid Placing Equipment in the Gun Washer
1) Close ball valve located on the bottom of the tank. To clean guns not mentioned here, use the long or short
stem supports as needed [see Fig. 10]. For questions or
2) Unit is designed to clean EITHER solvent or waterborne adapter kits, contact your paint gun washer distributor.
EXCLUSIVELY. Pour five gallons (18.9 liters) of high quality
cleaning solution into the tub. Siphon Feed Guns
Place the gun siphon tube on the short stem support.
Preparing the Equipment to be washed Gravity Feed Guns (HVLP)
Place long stem support over one of the short stem
1) Remove paint cup, or paint line, and the air line from the supports. Place paint inlet of gun on long stem support.
paint gun. Place the air cap assembly over the air inlet of the gun to
keep out cleaning solution.
2) Drain excess paint from cup and gun. Pressure Feed Guns
3) Remove all gauges and regulators. Place long stem support over one of the shorter stem
supports. Place paint inlet of gun on long stem support.
4) Screw on Air Cap Assembly to end of gun [see fig. 10]. Pots and Cups
5) Lock the gun trigger in the open position by placing the Place pots and/or cups on divider platform over front
trigger lock around the gun handle and trigger [see fig. 10]. spray nozzles.
