HIK VISION AE-VC154T-IT Manuale utente

DBA Vehicle-Mounted Camera

User Manual

UD13292B

User Manual

About this Manual

This manual applies to DBA Vehicle-Mounted Camera.

This Manual is subject to domestic and international

Technology Co., Ltd. (“Hikvision”) reserves all rights to

this manual. This manual cannot be reproduced, changed,

translated, or distributed, partially or wholly, by any

means, without the prior written permission of Hikvision.

Trademarks

and other Hikvision marks are the

property of Hikvision and are registered trademarks or the

subject of applications for the same by Hikvision and/or its

affiliates. Other trademarks mentioned in this manual are

the properties of their respective owners. No right of

license is given to use such trademarks without express

permission.

Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE

LAW, HIKVISION MAKES NO WARRANTIES, EXPRESS OR

IMPLIED, INCLUDING WITHOUT LIMITATION THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE, REGARDING THIS MANUAL.

HIKVISION DOES NOT WARRANT, GUARANTEE, OR MAKE

ANY REPRESENTATIONS REGARDING THE USE OF THE

MANUAL, OR THE CORRECTNESS, ACCURACY, OR

RELIABILITY OF INFORMATION CONTAINED HEREIN. YOUR

USE OF THIS MANUAL AND ANY RELIANCE ON THIS

MANUAL SHALL BE WHOLLY AT YOUR OWN RISK AND

RESPONSIBILITY.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE

LAW, IN NO EVENT WILL HIKVISION, ITS DIRECTORS,

OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU

FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR

INDIRECT DAMAGES, INCLUDING, AMONG OTHERS,

DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS

INTERRUPTION, SECURITY BREACHES, OR LOSS OF DATA

OR DOCUMENTATION, IN CONNECTION WITH THE USE OF

OR RELIANCE ON THIS MANUAL, EVEN IF HIKVISION HAS

BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR

LIMITATION OF LIABILITY OR CERTAIN DAMAGES, SO

SOME OR ALL OF THE ABOVE EXCLUSIONS OR

LIMITATIONS MAY NOT APPLY TO YOU.

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and

found to comply with the limits for a digital device,

pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference when the equipment is operated in

a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction

manual, may cause harmful interference to radio

communications. Operation of this equipment in a

residential area is likely to cause harmful interference in

which case the user will be required to correct the

interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCCRules.

Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received,

including interference that may cause undesired

operation

EU Conformity Statement

This product and - if applicable - the

supplied accessories too are marked with

"CE" and comply therefore with the

applicable harmonized European standards listed under

the Low Voltage Directive 2014/35/EC, the EMC Directive

2014/30/EC.

2012/19/EU (WEEE directive): Products

marked with this symbol cannot be

disposed of as unsorted municipal waste in

the European Union. For proper recycling,

return this product to your local supplier

upon the purchase of equivalent new equipment, or

dispose of it at designated collection points. For more

information see: www.recyclethis.info.

2006/66/EC (battery directive): This

product contains a battery that cannot be

disposed of as unsorted municipal waste in

the European Union. See the product

documentation for specific battery information. The

battery is marked with this symbol, which may include

lettering to indicate cadmium (Cd), lead (Pb), or mercury

(Hg). For proper recycling, return the battery to your

supplier or to a designated collection point. For more

information see: www.recyclethis.info.

Industry Canada ICES-003 Compliance

This device meets the CAN ICES-3 (A)/NMB-3(A)

standards requirements.

iii

Safety Instruction

These instructions are intended to ensure that user can

use the product correctly to avoid danger or property

loss.

The precaution measure is divided into “Warnings” and

“Cautions”

Warnings: Serious injury or death may occur if any of the

warnings are neglected.

Cautions: Injury or equipment damage may occur if any

of the cautions are neglected.

�In the use of the product, you must be in strict

compliance with the electrical safety regulations of

the nation and region.

�Refer to technical specifications for detailed

information.

�Input voltage should meet both the SELV (Safety Extra

Low Voltage) and the Limited Power Source with AC

24V or DC 12V according to the IEC60950-1 standard.

Refer to technical specifications for detailed

information.

�Do not connect several devices to one power adapter

as adapter overload may cause over-heating or a fire

hazard.

�Make sure that the plug is firmly connected to the

power socket.

�When the product is mounted on wall or ceiling, the

device shall be firmly fixed.

�If smoke, odor or noise rise from the device, turn off

the power at once and unplug the power cable, and

then please contact the service center.

�If the product does not work properly, contact your

dealer or the nearest service center. Never attempt to

disassemble the camera by yourself. (We shall not

assume any responsibility for problems caused by

unauthorized repair or maintenance.)

�Make sure the power supply voltage is correct before

using the camera.

�Do not drop the camera or subject it to physical shock.

�Do not touch senor modules with fingers. If cleaning is

necessary, use clean cloth with a bit of ethanol and

wipe it gently. If the camera will not be used for an

extended period, replace the lens cap to protect the

sensor from dirt.

�Do not aim the camera at the sun or extra bright

places. Blooming or smearing may occur otherwise

(which is not a malfunction), and affect the endurance

of sensor at the same time.

�The sensor may be burned out by a laser beam, so

when any laser equipment is in using, make sure that

the surface of sensor will not be exposed to the laser

beam.

�Do not place the camera in extremely hot, cold, dusty

or damp locations, and do not expose it to high

electromagnetic radiation.

�To avoid heat accumulation, good ventilation is

required for operating environment.

�Keep the camera away from liquid while in use.

�While in delivery, the camera shall be packed in its

original packing, or packing of the same texture.

Symbol Conventions

The symbols that may be found in this document are

defined as follows.

Symbol Description

Provides additional information to

emphasize or supplement important

points of the main text.

Indicates a potentially hazardous

situation, which if not avoided, could

result in equipment damage, data

loss, performance degradation, or

unexpected results.

Indicates a hazard with a high level of

risk, which if not avoided, will result in

death or serious injury.

1 Introduction

1.1 Product Features

This series of camera adopts new generation sensor with

high sensitivity and advanced circuit design technology. It

features high resolution, low image distortion and low

noise, etc., which makes it suitable for monitoring system

and image processing system.

The main features are as follows:

�High performance CMOS sensor

�High resolution image

�Low illumination, 0.1 lux @ (F1.2, AGC ON)

�Supports auto electronic day & night switch

�Supports auto gain control

1.2 Overview

1.2.1 Overview of DBA Vehicle-Mounted Camera

The overview of the camera is shown below.

Overview

1.2.2 Cable Description

The device supports two types of cable. Connect the

device with matched cable. The cable descriptions as

below:

Aviation Plug Interface

Interfaces of Aviation Plug

4-Pin Din Connetor Interface

Interfaces of 4-Pin Din Connector

The power supply for the camera is 6 VDC to 16 VDC.

2 Installation

Before you start:

�Please make sure that the device in the package is in

good condition and all the assembly parts are

included.

�Make sure that all the related equipment is power-off

during the installation.

�Check the specification of the products for the

installation environment.

�Check whether the power supply is matched with your

power output to avoid damage.

�Be sure that there is enough space to install the

camera and accessories.

�Make sure the part, which is used to install the camera,

is strong enough to withstand four times the weight of

the camera and the mounting.

�If the product does not function properly, please

contact your dealer or the nearest service center. Do

not disassemble the camera for repair or maintenance

by yourself.

�Do not pull and drag the camera cables hard.

Steps:

1. Clean the mounting surface with a mixture of

isopropyl and water.

Choose a mounting position that camera can aim at

the driver.

2. Peal the paster of the mounting base.

Peal the Paster

3. Paste the camera onto mounting position.

Paste the Camera

4. Fix the mounting base with two screws as the

picture shown below.

Fix the Mounting Base

5. Adjust the camera angle accordingly, and lock

the shooting angle with two lock screws.

Lock the Shooting Angle
