HIK VISION DS-8600 Series Manuale utente

User Manual of DS-9600/8600/7700/7600 Series NVR

Network Video Recorder

User Manual (V2.3.3)

UD.6L0202D1062A01

User Manual of DS-9600/8600/7700/7600 Series NVR

Hikvision® Network Digital Video Recorder User Manual

This manual, as well as the software described in it, is furnished under license and may be used or copied only in

accordance with the terms of such license. The content of this manual is furnished for informational use only, is

subject to change without notice, and should not be construed as a commitment by Hikvision Digital Technology

Co., Ltd. (Hikvision). Hikvision assumes no responsibility or liability for any errors or inaccuracies that may

appear in the book.

Except as permitted by such license, no part of this publication may be reproduced, stored in a retrieval system, or

transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior written

permission of Hikvision.

HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION

THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,

REGARDING THE HIKVISION SOFTWARE. HIKVISION DOES NOT WARRANT, GUARANTEE, OR

MAKE ANY REPRESENTATIONS REGARDING THE USE OR THE RESULTS OF THE USE OF THE

HIKVISION SOFTWARE IN TERMS OF ITS CORRECTNESS, ACCURACY, RELIABILITY,

CURRENTNESS, OR OTHERWISE. THE ENTIRE RISK AS TO THE RESULTS AND PERFORMANCE OF

THE HIKVISION SOFTWARE IS ASSUMED BY YOU. THE EXCLUSION OF IMPLIED WARRANTIES IS

NOT PERMITTED BY SOME STATES. THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.

IN NO EVENT WILL HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE

TO YOU FOR ANY CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES (INCLUDING

DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS

INFORMATION, AND THE LIKE) ARISING OUT OF THE USE OR INABILITY TO USE THE HIKVISION

SOFTWARE EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR

CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.

User Manual of DS-9600/8600/7700/7600 Series NVR

Regulatory information

FCC information

FCC compliance : This equipment has been tested and found to comply with the limits for a digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be required to correct the interference at his own expense.

FCC conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the

applicable harmonized European standards listed under the Low Voltage Directive 2006/95/EC, the EMC

Directive 2004/108/EC.

2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal

waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of

equivalent new equipment, or dispose of it at designated collection points. For more information see:

www.recyclethis.info.

2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal

waste in the European Union. See the product documentation for specific battery information. The battery is

marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For

proper recycling, return the battery to your supplier or to a designated collection point. For more information see:

www.recyclethis.info.

User Manual of DS-9600/8600/7700/7600 Series NVR

Preventive and Cautionary Tips

Before connecting and operating your device, please be advised of the following tips:

•Ensure unit is installed in a well-ventilated, dust-free environment.

•Unit is designed for indoor use only.

•Keep all liquids away from the device.

•Ensure environmental conditions meet factory specifications.

•Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of dropping it

may cause damage to the sensitive electronics within the unit.

•Use the device in conjunction with an UPS if possible.

•Power down the unit before connecting and disconnecting accessories and peripherals.

•A factory recommended HDD should be used for this device.

•Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or

equivalent type only. Dispose of used batteries according to the instructions provided by the battery

manufacturer.

User Manual of DS-9600/8600/7700/7600 Series NVR

Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer.

This manual is applicable to the models listed in the following table.

Series

Model

Type

9600NI-ST

DS-9608NI-ST

DS-9616NI-ST

DS-9632NI-ST

DS-9664NI-ST

Network Video Recorder

9600NI-RT

DS-9608NI-RT

DS-9616NI-RT

DS-9632NI-RT

DS-9664NI-RT

Network Video Recorder

9600NI-XT

DS-9616NI-XT

DS-9632NI-XT

DS-9664NI-XT

Network Video Recorder

8600NI-ST

DS-8608NI-ST

DS-8616NI-ST

DS-8632NI-ST

DS-8664NI-ST

Network Video Recorder

7700NI-ST

DS-7708NI-ST

DS-7716NI-ST

DS-7732NI-ST

DS-7764NI-ST

Network Video Recorder

7700NI-SP

DS-7708NI-SP

DS-7716NI-SP

DS-7732NI-SP

Network Video Recorder

7600NI-ST

DS-7608NI-ST

DS-7616NI-ST

DS-7632NI-ST

Network Video Recorder

7600NI-SP

DS-7608NI-SP

DS-7616NI-SP

DS-7632NI-SP

Network Video Recorder

User Manual of DS-9600/8600/7700/7600 Series NVR

Product Key Features

General

Connectable to network cameras, network dome and encoders.

Connectable to the third-party network cameras like ACTI, Arecont, AXIS, Bosch, Brickcom, Canon,

PANASONIC, Pelco, SAMSUNG, SANYO, SONY, Vivotek and ZAVIO, and cameras that adopt

ONVIF or PSIA protocol.

PAL/NTSC adaptive video inputs.

Each channel supports dual-stream.

Up to 64 network cameras can be connected for DS-9600/8600NI and DS-7700NI-ST series NVR,

and 32 network cameras for DS-7600NI and DS-7700NI-SP series.

Independent configuration for each channel, including resolution, frame rate, bit rate, image quality,

etc.

The quality of the input and output record is configurable.

Local Monitoring

Simultaneous HDMI, VGA and CVBS outputs.

HDMI output and VGAoutput at up to 1920×1080 resolution.

Multiple screen display in live view is supported, and the display sequence of channels is adjustable.

Live view screen can be switched in group, and manual switch and automatic cycle live view are also

provided, and the interval of automatic cycle can be adjusted.

Quick setting menu is provided for live view.

Motion detection, tamper-proof, video exception alert and video loss alert functions.

Privacy mask.

Multiple PTZ protocols supported; PTZ preset, patrol and pattern.

Zooming in by clicking the mouse and PTZ tracing by dragging mouse.

HDD Management

For 9600NI-XT series, up to 16 SATA hard disks and 2 eSATA disks can be connected. For

7600NI-ST/SP series, 2 SATA hard disks and 1 eSATA disks can be connected. For 7700NI-ST/SP

series, 4 SATA hard disks and 1 eSATA disk can be connected. And up to 8 SATA hard disks and 1

eSATA disk can be connected for other models. (Each disk with a maximum of 4TB storage

capacity.)

8 network disks (8 NAS disks, or 7 NAS disks+1 IP SAN disk) can be connected.

Support eSATAdisks for recording or backup.

Support S.M.A.R.T. and bad sector detection. (Not supported with DS-9600NI-RT series NVR.)

HDD group management.

Support HDD standby function.

HDD property: redundancy, read-only, read/write (R/W).

HDD quota management; different capacity can be assigned to different channel.

Support RAID0, RAID1, RAID5, RAID10 storage scheme. And 8 virtual disks can be configured.

(Only for the DS-9600NI-RT series NVR.)

Recording, Capture and Playback

Holiday recording schedule configuration.

Continuous and event video recording parameters.

Multiple recording types: manual, continuous, alarm, motion, motion | alarm, motion & alarm.

User Manual of DS-9600/8600/7700/7600 Series NVR

8 recording time periods with separated recording types.

Pre-record and post-record for alarm, motion detection for recording, and pre-record time for

schedule and manual recording.

Searching record files and captured pictures by events (alarm input/motion detection).

Tag adding for record files, searching and playing back by tags.

Locking and unlocking record files.

Local redundant recording and capture.

Provide new playback interface with easy and flexible operation.

Searching and playing back record files by channel number, recording type, start time, end time, etc.

Smart search for the selected area in the video.

Zooming in when playback.

Reverse playback of multi-channel.

Supports pause, play reverse, speed up, speed down, skip forward, and skip backward when playback,

and locating by dragging the mouse.

Up to 16-ch synchronous playback at 4CIF real time.

Manual capture, continuous capture of video images and playback of captured pictures.

Backup

Export video data by USB, SATA or eSATA device.

Export video clips when playback.

Management and maintenance of backup devices.

Alarm and Exception

Configurable arming time of alarm input/output.

Alarm for video loss, motion detection, tampering, abnormal signal, video input/output standard

mismatch, illegal login, network disconnected, IP confliction, abnormal record/capture, HDD error,

and HDD full, etc.

Alarm triggers full screen monitoring, audio alarm, notifying surveillance center, sending email and

alarm output.

Automatic restore when system is abnormal.

Other Local Functions

Operable by front panel, mouse, remote control, and control keyboard.

Three-level user management; admin user is allowed to create many operating accounts and define

their operating permission, which includes the limit to access any channel.

Operation, alarm, exceptions and log recording and searching.

Manually triggering and clearing alarms.

Import and export of device configuration information.

Network Functions

2 self-adaptive 10M/100M/1000M network interfaces, and various working modes are configurable:

multi-address, load balance, network fault tolerance, etc. (Two NIC are only for the

DS-9600NI-ST/RT/XT and DS-8600NI-ST series NVR.)

8 independent PoE network interfaces are provided for DS-7700/7600NI-SP series.

IPv6 is supported.

TCP/IP protocol, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, and iSCSI are

supported.

TCP, UDP and RTP for unicast.

Auto/Manual port mapping by UPnP.

User Manual of DS-9600/8600/7700/7600 Series NVR

Remote web browser access by HTTPS ensures high security.

Remote reverse playback via RTSP.

Support accessing by the platform via ONVIF.

Remote search, playback, download, locking and unlocking of the record files, and support

downloading files broken transfer resume.

Remote parameters setup; remote import/export of device parameters.

Remote viewing of the device status, system logs and alarm status.

Remote keyboard operation.

Remote locking and unlocking of control panel and mouse.

Remote HDD formatting and program upgrading.

Remote system restart and shutdown.

RS-232, RS-485 transparent channel transmission.

Alarm and exception information can be sent to the remote host

Remotely start/stop recording.

Remotely start/stop alarm output.

Remote PTZ control.

Remote JPEG capture.

Two-way audio and voice broadcasting.

Embedded WEB server.

Development Scalability:

SDK for Windows and Linux system.

Source code of application software for demo.

Development support and training for application system.

User Manual of DS-9600/8600/7700/7600 Series NVR

TABLE OF CONTENTS

Product Key Features ..............................................................................................................................6

Chapter 1 Introduction ................................................................................................................................13

1.1 Front Panel ....................................................................................................................................14

1.2 IR Remote Control Operations......................................................................................................21

1.3 USB Mouse Operation ..................................................................................................................23

1.4 Input Method Description..............................................................................................................24

1.5 Rear Panel .....................................................................................................................................25

Chapter 2 Getting Started............................................................................................................................29

2.1 Starting Up and Shutting Down the NVR......................................................................................30

2.2 Using the Wizard for basic configuration......................................................................................32

2.3 Adding and Connecting the IP Cameras........................................................................................37

2.3.1 Adding the online IP Cameras.....................................................................................37

2.3.2 Editing the connected IP cameras and Configuring Customized Protocols.................38

2.3.3 Editing IP cameras connected to the PoE interfaces (Only for DS-7600/7700NI-SP series

NVR) ....................................................................................................................................41

Chapter 3 Live View.....................................................................................................................................43

3.1 Introduction of Live View .............................................................................................................44

3.2 Operations in Live View Mode......................................................................................................45

3.2.1 Front Panel Operation on Live View...........................................................................45

3.2.2 Using the Mouse in Live View....................................................................................46

3.2.3 Using an Auxiliary Monitor ........................................................................................46

3.2.4 Quick Setting Toolbar in Live View Mode..................................................................47

3.3 Adjusting Live View Settings........................................................................................................50

3.4 Channel-zero Encoding .................................................................................................................52

3.5 User Logout...................................................................................................................................53

Chapter 4 PTZ Controls...............................................................................................................................54

4.1 Configuring PTZ Settings..............................................................................................................55

4.2 Setting PTZ Presets, Patrols & Patterns.........................................................................................56

4.2.1 Customizing Presets....................................................................................................56

4.2.2 Calling Presets ............................................................................................................57

4.2.3 Customizing Patrols....................................................................................................58

4.2.4 Calling Patrols.............................................................................................................59

4.2.5 Customizing Patterns ..................................................................................................60

4.2.6 Calling Patterns...........................................................................................................61

4.3 PTZ Control Panel.........................................................................................................................63

Chapter 5 Record and Capture Settings.....................................................................................................64

5.1 Configuring Parameters.................................................................................................................65

5.2 Configuring Record/Capture Schedule..........................................................................................67

5.3 Configuring Motion Detection Record and Capture......................................................................70

5.4 Configuring Alarm Triggered Record and Capture........................................................................72

5.5 Manual Record and Continuous Capture.......................................................................................74

User Manual of DS-9600/8600/7700/7600 Series NVR

5.6 Configuring Holiday Record and Capture.....................................................................................75

5.7 Configuring Redundant Recording and Capture............................................................................77

5.8 Configuring HDD Group for Recording and Capture....................................................................79

5.9 Files Protection..............................................................................................................................80

Chapter 6 Playback......................................................................................................................................82

6.1 Playing Back Record Files ............................................................................................................83

6.1.1 Playing Back by Channel............................................................................................83

6.1.2 Playing Back by Time.................................................................................................85

6.1.3 Playing Back by Event Search ....................................................................................86

6.1.4 Playing Back by Tag ...................................................................................................89

6.1.5 Playing Back by System Logs.....................................................................................92

6.1.6 Playing Back External File..........................................................................................93

6.2 Auxiliary Functions of Playback ...................................................................................................95

6.2.1 Playing Back Frame by Frame....................................................................................95

6.2.2 Smart Search...............................................................................................................95

6.2.3 Digital Zoom...............................................................................................................98

6.2.4 Reverse Playback of Multi-channel ............................................................................98

6.3 Picture Playback..........................................................................................................................100

Chapter 7 Backup.......................................................................................................................................102

7.1 Backing up Record Files .............................................................................................................103

7.1.1 Quick Export.............................................................................................................103

7.1.2 Backing up by Normal Video Search........................................................................104

7.1.3 Backing up by Event Search ..................................................................................... 111

7.1.4 Backing up Video Clips ............................................................................................ 113

7.2 Backing up Pictures..................................................................................................................... 116

7.3 Managing Backup Devices.......................................................................................................... 118

Chapter 8 Alarm Settings ...........................................................................................................121

8.1 Setting Motion Detection Alarm..................................................................................................122

8.2 Setting Sensor Alarms .................................................................................................................124

8.3 Detecting Video Loss Alarm........................................................................................................127

8.4 Detecting Video Tampering Alarm..............................................................................................129

8.5 Handling Exceptions Alarm.........................................................................................................131

8.6 Setting Alarm Response Actions .................................................................................................132

8.7 Triggering or Clearing Alarm Output Manually..........................................................................134

Chapter 9 Network Settings.......................................................................................................................135

9.1 Configuring General Settings......................................................................................................136

9.2 Configuring Advanced Settings...................................................................................................138

9.2.1 Configuring PPPoE Settings .....................................................................................138

9.2.2 Configuring DDNS...................................................................................................138

9.2.3 Configuring NTP Server ...........................................................................................142

9.2.4 Configuring SNMP...................................................................................................142

9.2.5 Configuring Remote Alarm Host ..............................................................................143

9.2.6 Configuring Multicast...............................................................................................143

9.2.7 Configuring RTSP.....................................................................................................144

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali HIK VISION Hardware di rete

HIK VISION

HIK VISION DS-M5504HNI Series Manuale utente

HIK VISION

HIK VISION iDS-9600NXI-I16/4F Series Manuale utente

HIK VISION

HIK VISION DS-3WF0AC-2NT Manuale utente

HIK VISION

HIK VISION DS-7600NI-I2 Series Manuale utente

HIK VISION

HIK VISION BCS-V-NVRXX02-4K Series Manuale utente

HIK VISION

HIK VISION DS-9600NXI-I8/S Series Manuale utente

HIK VISION

HIK VISION DS-96000NI-M8 Series Manuale utente

HIK VISION

HIK VISION DS-7100NI-K1 Series Manuale utente

HIK VISION

HIK VISION DS-7100NI-K1/W/M Series Manuale utente

HIK VISION

HIK VISION HWN-2100H Series Manuale utente

HIK VISION

HIK VISION DS-MP3516-RS Manuale utente

HIK VISION

HIK VISION DS-9600 Series Guida utente

HIK VISION

HIK VISION DS-3WF Series Manuale utente

HIK VISION

HIK VISION DS-9632NI-I8 Manuale utente

HIK VISION

HIK VISION HiWatch Series Manuale utente

HIK VISION

HIK VISION DS-9608NI-ST Series Manuale utente

HIK VISION

HIK VISION DS-7608NI-M2 Series Manuale utente

HIK VISION

HIK VISION Ds-7604ni-e1, ds-7608ni-e1 Manuale utente

HIK VISION

HIK VISION 1200KI Manuale utente

HIK VISION

HIK VISION DS-7100NI-K1/W/M Series Manuale utente

HIK VISION

HIK VISION HWN-4116MH Manuale utente

HIK VISION

HIK VISION DS-96128NI-E16 Manuale utente

HIK VISION

HIK VISION DS-7600NI-E1/A Manuale utente

HIK VISION

HIK VISION DS-KH6320-TE1 Manuale utente

Manuali Hardware di rete popolari di altre marche

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuale utente

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuale utente

Yudor

Yudor YDS-16 Manuale utente

D-Link

D-Link ShareCenter DNS-320L Manuale utente

Samsung

Samsung ES1642dc Istruzioni per l’uso

Honeywell Home

Honeywell Home LTEM-PV Istruzioni per il montaggio

evertz

evertz 7700 Series Manuale utente

D-Link

D-Link ShareCenter DNS-343 Manuale utente

Asante

Asante AsanteBridge 1012 Manuale utente

FireBrick

FireBrick FB2700 Manuale utente

Audiovox Electronics

Audiovox Electronics ARWH2T Manuale utente

ADC

ADC DSX-1 Manuale

NetComm

NetComm NF2 Manuale utente

Alcatel-Lucent

Alcatel-Lucent 5620 Manuale utente

Dell EMC

Dell EMC XC6420 Series Manuale utente

Lanner

Lanner NCA-1020A Manuale utente

Allied Telesis

Allied Telesis AT-TN121-A Manuale utente

Arista

Arista CCA-ETM-Q12 Manuale utente
