HIK VISION DS-2TD2466-9X Manuale utente
0
Explosion-Proof Thermal Network Bullet Camera
Quick Start Guide
Thermal Bullet Camera·Quick Start Guide
1
© 2021 Hangzhou Hikvision Digital Technology Co., Ltd. All rights
reserved.
About this Manual
The Manual includes instructions for using and managing the
Product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The information
contained in the Manual is subject to change, without notice, due to
firmware updates or other reasons. Please find the latest version of
this Manual at the Hikvision website (https://www.hikvision.com/).
Please use this Manual with the guidance and assistance of
professionals trained in supporting the Product.
Trademarks Acknowledgement
and other Hikvision’s trademarks and logos are the
properties of Hikvision in various jurisdictions.
Other trademarks and logos mentioned are the properties of their
respective owners.
LEGAL DISCLAIMER
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS
MANUAL AND THE PRODUCT DESCRIBED, WITH ITS HARDWARE,
SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND “WITH ALL
FAULTS AND ERRORS”. HIKVISION MAKES NO WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY,
SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE.
THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO
EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL,
CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING,
AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,
Thermal Bullet Camera·Quick Start Guide
2
BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF
SYSTEMS, OR LOSS OF DOCUMENTATION, WHETHER BASED ON
BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT
LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES
FOR INHERENT SECURITY RISKS, AND HIKVISION SHALL NOT TAKE
ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY
LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK,
HACKER ATTACK, VIRUS INFECTION, OR OTHER INTERNET SECURITY
RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL
SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL
APPLICABLE LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR
ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A
MANNER THAT DOES NOT INFRINGE ON THE RIGHTS OF THIRD
PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF PUBLICITY,
INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER
PRIVACY RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY
PROHIBITED END-USES, INCLUDING THE DEVELOPMENT OR
PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE
DEVELOPMENT OR PRODUCTION OF CHEMICAL OR BIOLOGICAL
WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED TO ANY
NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN
SUPPORT OF HUMAN RIGHTS ABUSES.
Thermal Bullet Camera·Quick Start Guide
3
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
Thermal Bullet Camera·Quick Start Guide
4
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to
comply with the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own
expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the EMC Directive 2014/30/EU, the LVD
Thermal Bullet Camera·Quick Start Guide
5
Directive 2014/35/EU, the RoHS Directive 2011/65/EU, the ATEX
Directive 2014/34/EU.
2012/19/EU (WEEE directive): Products marked with
this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info
2006/66/EC (battery directive): This product contains
a battery that cannot be disposed of as unsorted
municipal waste in the European Union. See the
product documentation for specific battery
information. The battery is marked with this symbol,
which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your supplier
or to a designated collection point. For more information
see:www.recyclethis.info
Intended use of the camera
ATEX: Exd IIC T6 Gb/Ex tD A21 T80℃
IECEx: Exd IIC T6 Gb/Ex tD A21 T80℃
Hazardous Area Classification: Zone 1, Zone 2, Zone 21, Zone 22.
IP Degree: IP68 (2 m, 2 h)
Ex Standards:
Thermal Bullet Camera·Quick Start Guide
6
IEC 60079-0: 2011
EN 60079-0: 2012
IEC 60079-1: 2014
EN 60079-1: 2014
IEC 60079-31: 2013
EN 60079-31: 2014
Nameplate:
WARNING:
DO NOT OPEN
WHEN ENERGIZED
CAUTION:
USE FASTENERS
WITH YIELD
STRESS≥450MPa
Protection Level: IP68
Product Model：
EnvironmentTemperature：40℃~﹢60℃
Working Voltage：
Rated Power：≤15W
Product No.：
Date of Production：
Explosion-Proof Thermal
Network Bullet Camera
WARNING:
DO NOT TAKE
APART THE
FASTENERS OF
GERMANIUM
GLASS RING,OR
THE CEMENTED
JOINTS MAY BE
DAMAGED
Special Conditions for Safe Use:
1. Ambient Temperature: - 40 °C to + 60 °C.
2. DO NOT OPEN WHEN ENERGIZED.
3. POTENTIAL ELECTROSTATIC CHARGING HAZARD – SEE
INSTRUCTIONS.
Thermal Bullet Camera·Quick Start Guide
7
4. When assembly, operation and maintenance, the operator must
follow the requirements of the IEC 60079-14: latest version
Explosive atmosphere- Part 14: Electrical installation design,
selection and erection, beside of the manufacturer’s operation
instruction or its National equivalent.
5. Repair and overhaul shall comply with IEC 60079-19: latest version
or its National equivalent.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards
requirements.
Warning:
This is a class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to
take adequate measures.
이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를
받은 기기로서 가정용 환경에서 사용하는 경우 전파간섭의
우려가 있습니다.
Symbol Conventions
The symbols that may be found in this document are defined as
follows.
Symbol
Description
Danger
Indicates a hazardous situation which, if not avoided,
will or could result in death or serious injury.
Thermal Bullet Camera·Quick Start Guide
8
Symbol
Description
Caution
Indicates a potentially hazardous situation which, if not
avoided, could result in equipment damage, data loss,
performance degradation, or unexpected results.
Note
Provides additional information to emphasize or
supplement important points of the main text.
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
Laws and Regulations
●In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region.
Transportation
●Keep the device in original or similar packaging while
transporting it.
●Keep all wrappers after unpacking them for future use. In case of
any failure occurred, you need to return the device to the factory
with the original wrapper. Transportation without the original
wrapper may result in damage on the device and the company
shall not take any responsibilities.
●DO NOT drop the product or subject it to physical shock. Keep
the device away from magnetic interference.
Thermal Bullet Camera·Quick Start Guide
9
Power Supply
●Please purchase the charger by yourself. Input voltage should
meet the Limited Power Source (100-240 VAC) according to the
IEC62368 standard. Please refer to technical specifications for
detailed information.
●Make sure the plug is properly connected to the power socket.
●The socket-outlet shall be installed near the equipment and shall
be easily accessible.
●DO NOT connect multiple devices to one power adapter, to avoid
over-heating or fire hazards caused by overload.
●DO NOT touch the bare metal contacts of the inlets after the
circuit breaker is turned off. Electricity still exists.
●+ identifies the positive terminal(s) of equipment which is used
with, or generates direct current. - identifies the negative
terminal(s) of equipment which is used with, or generates direct
current.
●The equipment must be connected to an earthed mains socket-
outlet.
●A readily accessible disconnect device shall be incorporated
external to the equipment.
●An all-pole mains switch shall be incorporated in the electrical
installation of the building.
●Ensure correct wiring of the terminals for connection to an AC
mains supply.
●The equipment has been designed, when required, modified for
connection to an IT power distribution system.
