General Description
The H50226/7 is a 10/100/1000Mbps Desktop Ethernet unmanaged switch designed
to enhance network performance in a compact form factor.It can also be mounted
vertically using the stand provided along with the switch.The switch comes with 5/8x
10/100/1000Mbps ports, offering solutions for accelerating bandwidth needs of small
Ethernet workgroups. The switch uses store and forward packet-switching technology
which offers reliable data transfer and supports automatic MDI/MDI-X detection & auto
crossover for uplink ports which eliminates the need for cross over cables or dedicated
uplink ports. Any port can simply plug to a server or a switch, using the usual straight
throughtwisted pair cable. This switch is ideal for network connectivity for the SOHO
environment.
Product Features
5/8 RJ-45 Ports for 10BaseT, 100BaseTX & 1000BaseT connectivity
Complies with IEEE802.3, IEEE802.3u, IEEE802.3ab standards
Supports IEEE802.3 Nway auto-negotiation protocol
Supports IEEE 802.3x Full-duplex Flow Control
Supports IEEE802.1p priority tag based QoS
Supports MDI/MDI-X auto crossover for each port
Supports wire speed packet filtering and forwarding rate
Supports store-and-forward switching architecture
Link & activity indicators for each port
Energy Efficient
FCC Class B, CE
External Power Adapter
* If any of the items is damaged or missing, please contact your retailer immediately
.
Package Contents
H50226/7 5/8 port 10/100/1000Mbps Desktop Ethernet Switch
5V DC, 1A Switching power adapter
Quick installation guide
Rear View
Front View
After installing the switch, you can check its status from the LED indicators on the front
panel shown below. .
LED Color Status
Power (P) Blue On
Off
Link / ACT Blue On
Blinking
Indication
The switch is power on
The switch is power off
A link is established
A link is established and Data
is being transmitted and received
Plug the circle end of the power adapter firmly into the power port on the switch rear panel,
and the other end into an electric service outlet, then the device is ready to use.
Power Connection
Ports 1 - 5/8 :The switch has five/eight10/100/1000Mbps RJ-45 ports where you can
connectcomputers or network devices to the switch.
DC-IN : This port connects to the power adapter.
.
The switch features auto-MDI/MDIX crossover detection function and provides plug-and-
play capability. Users can immediately use any of the features of this product simply by
plugging the network cables (RJ-45) into the computers and the switch.
Connecting Computers to the Switch
(Ports 1-8)
12345678
