Hitachi C42 Manuale utente
C42 Probe
INSTRUCTION MANUAL
Tokyo , Japan
Q1E-EP1359-6
© Hitachi, Ltd. 2013,2017. All rights reserved.
Notes for operators and responsible maintenance personnel
★Please read through this Instruction Manual carefully prior to use.
★Keep this Instruction Manual together with the system with care to make it
available anytime.
0123
(1) Q1E-EP1359
Manufacturer: Hitachi, Ltd.
2-16-1, Higashi-Ueno, Taito-ku, Tokyo,110-0015,
Japan
+81-3-6284-3668
http://www.hitachi.com/businesses/healthcare/in
dex.html
European
Representative: Hitachi Medical Systems GmbH
Otto-von-Guericke-Ring 3 D-65205 Wiesbaden,
Germany
EU Importer: Hitachi Medical Systems Europe Holding AG
Address: Sumpfstrasse 13 CH-6300 Zug, Switzerland
Local Distributor:
(2) Q1E-EP1359
About this manual
This instruction manual shall provide instructions for using, cleaning,
disinfecting and/or sterilizing the HITACHI ultrasound probes.
It also describes safety considerations, maintenance.
For instructions for operating the ultrasound diagnostic scanner, refer
to the operation manual for it.
Before using the probe, thoroughly read this manual and keep this book
for future reference.
If you have any questions concerning the manual, please contact a service
support.
The following conventions are used throughout the manual to denote
information of special emphasis:
WARNING: “Warning” is used to indicate the presence of a hazard which
can cause severe personal injury, death, or substantial
property damage if the warning is ignored.
CAUTION: “Caution” is used to indicate the presence of a hazard which
will or can cause minor personal injury or property damage
if the caution is ignored.
NOTICE: “Notice” is used to notify people of installation, operation,
or maintenance information which is important, but not hazard
related.
(3) Q1E-EP1359
Graphical Symbols for Use in Labeling of Hitachi Ultrasound Probes
Some graphical symbols that are used in labeling of Hitachi Ultrasound Probes are
compliant with EN980:2008 standard. Refer to the following table about the meanings of
them.
Explanation of Symbol Symbol Descriptive Content
Manufacturer Company
Name and Address
Hitachi, Ltd.
2-16-1, Higashi-Ueno, Taito-ku,
Tokyo, 110-0015, Japan
+81-3-6284-3668
http://www.hitachi.com/businesses/
healthcare/index.html
Authorized
Representative
in The European
Community
Hitachi Medical Systems GmbH
Otto-von-Guericke-Ring 3 D-65205
Wiesbaden, Germany
Keep away
from Sunlight
Store the probe in a cool, dustproof and dry
environment to avoid high temperature,
humidity and direct sunlight.
(4) Q1E-EP1359
Definition of symbol
The following symbol is also used for HITACHI Ultrasound Probes.
Location Symbol Definition
Probe connector
This instrument complies with Directive
93/42/EEC relating to Medical Device
and Directive 2011/65/EU relating to
RoHS
Probe connector IPX7 IPX7 mark
See section 1.6.
Probe connector Type BF APPLIED PART
Probe connector General warning sign
Probe connector Warning; dangerous voltage
Probe connector Caution; Biohazard
Probe connector
Follow the instruction manual to
operate this instrument. If not
avoided, may result in injury, property
damage, or the equipment trouble.
Probe connector
STERRAD sterilization compatibility
mark
Probe connector Do not waste the instrument as general
waste. Comply with a local regulation.
Probe connector Rx Only
By prescription only. U.S. Federal Law
restricts this device to sale on order
of a physician only.
(5) Q1E-EP1359
CONTENTS
Page
1.General ........................................................ 1
1.1General .............................................................1
1.2Principles of operation .............................................1
1.3Intended Use ........................................................2
1.4Components ..........................................................2
1.5Option ..............................................................2
1.6External View .......................................................4
2.Inspection before Use .......................................... 5
2.1Inspection for Appropriate Connection ...............................5
2.2Inspection for Material Surface .....................................5
3.Operation Procedure ............................................ 6
4.Option of C42 Probe ............................................ 8
4.1Magnetic sensor .....................................................8
5.Reprocessing Procedure ........................................ 13
5.1Point of use (Pre-cleaning) ........................................16
5.2Containment and transportation .....................................16
5.3Manual Cleaning and disinfection ...................................16
5.4Drying .............................................................20
5.5Inspection .........................................................20
5.6Packaging ..........................................................20
5.7Sterilization ......................................................20
5.8Storage ............................................................22
6.Maintenance and Safety Inspection ............................. 23
7.Safety Precautions ............................................ 24
8.Specifications ................................................ 25
8.1Probe ..............................................................25
8.2Suppliers List .....................................................26
9.Disposal of the probe ......................................... 27
-1- Q1E-EP1359
1. General
1.1 General
C42 Probe is a Convex Array Probe.
The acoustic output of C42 Probe was measured according to the
IEC60601-2-37 standard and the measurement was conducted by
operating with the Hitachi ultrasound diagnostic scanner.
The measured acoustic output is listed in the instruction manual
of the Hitachi ultrasound diagnostic scanner.
C42 Probe is categorized in class Ⅱa according to Directive
93/42/EEC and classified as type BF according to IEC60601-1.
Never use the probe for following applications.
Direct contact to the heart
Biopsy to the heart
Direct contact to the eye
Never use the probe with (HF) surgical equipment.
1.2 Principles of operation
This probe and the ultrasound diagnostic scanner enable image
diagnosis using ultrasonic waves. This system operates under the
principles described below.
1) When an electric pulse signal is applied from the transmitter
to the transducer of the probe, the transducer converts electric
signals into mechanical vibration energy for emitting
pulse-shaped ultrasonic waves into the body part, liquid or
other medium contacting the transducer.
2) The emitted ultrasonic waves are reflected by boundaries with
different acoustic characteristics (acoustic impedance)
within the body.
3) The transducer is also used to receive reflected ultrasonic
waves. The transducer vibrates mechanically due to the received
ultrasonic waves and converts mechanical vibrations into
electric energy. Electric signals are converted to shades of
brightness by brightness modulation to obtain an image.
WARNIN
G
WARNIN
G
-2- Q1E-EP1359
1.3 Intended Use
C42 Probe is designed for observation and diagnosis mainly of the
following regions by connecting with the Hitachi ultrasound
diagnostic scanner.
Neonatal
Pediatrics
Intra-operative
1.4 Components
The components of C42 Probe are given below:
1) Probe .................................. 1 piece
2) Instruction manual ..................... 1 copy
Sterilization has not been made to the probe, shipped from the
factory. Prior to use of the probe, be sure to clean, disinfect
and sterilize the probe.
1.5 Option
1.5.1 Needle Guide Bracket EZU-PA532
1) Needle guide bracket············· 1 piece
2) Brush···························· 1 piece
3) Instruction manual··············· 1 copy
Please refer to the instruction manual of needle guide bracket
EZU-PA532 about the method of handling, cleaning, disinfecting
and sterilizing the needle guide bracket EZU-PA532.
1.5.2 Magnetic Sensor Attachment
Magnetic Sensor Attachment Part number
For using without Biopsy Guide Bracket 7349816A
For using with Biopsy Guide Bracket 7349817A
Sterilization has not been made to the Magnetic sensor attachment
and the EZU-PA532 shipped from the factory.
Prior to use of them, be sure to clean, disinfectt and
sterilize them.
C
A
U
TI
O
N
C
A
U
TI
O
N
-3- Q1E-EP1359
(1) A biopsy should be performed only by a well-trained
physician.
(2) Use only the authorized needle guide bracket for performing
a biopsy.
(3) Confirm that the name of the needle guide bracket to be
attached to the probe corresponds to the name of the bracket
displayed on the monitor. Otherwise there is a risk of injury
due to biopsy failure caused by the use of the wrong type
of needle guide bracket.
(4) “Puncture Adapter Select” window appears on the first use,
and the selected bracket is automatically selected after the
first use. If the bracket is changed to the other bracket,
please change the name of the bracket displayed on the monitor
to the name of the other bracket. Otherwise there is a risk
of injury due to biopsy failure caused by the use of the wrong
type of needle guide bracket.
(5) Before performing a biopsy, display the needle echo in
sterile water, and confirm that the needle echo at each angle
overlaps with the correspondent needle guideline. For the
confirmation procedure in detail, refer to the instruction
manual of EZU-PA532.
CAUTION
CAUTION
-4- Q1E-EP1359
1.6 External View
The external view of C42 Probe is shown in Fig. 1.
Connector
C
able
Un-immersible part
Immersible part:
This part can be immersed in disinfectant solution and also can
be cleaned by water.
Un-immersible part:
This part should not be immersed in disinfectant solution and
also can not be cleaned by water.
Fig. 1 External view
Applied part
Immersible part (IPX7)
Head
Magnetic sensor
attachment (Option)
Magnetic sensor attachment
(with needle guide bracket)
(Option)
