2. Always securely hold onto the model when connecting the
battery. Holding the model and expecting the propeller
to turn will prevent an accident or injury.
Each time you connect the battery to the aircraft, the ESC
will send electrical pulses to the motor causing it to chime
three times (“1 2 3”) followed by a single, longer beep
(“beeep”), followed by either one or two more short beeps
depending on whether the brake is On or Off (more on the
motor brake below). Now the model is ready to y and the
propeller will turn when the throttle is advanced.
Turn on Tx
& Connect
the Battery
Chime
“1 2 3”
Long
Beep
“beeep”
One or Two
Short Beeps
“beep” or
“beep beep”
Motor
is
Armed
If the transmitter is not turned On before the battery and
ESC are connected (so the receiver is not receiving a signal)
the motor will still chime three times (“1 2 3”), but then will
sound consecutive beeps (“beep,” “beep,” “beep,”….) until
the transmitter is turned On, at which time it will resume the
starting sequence of the single, long beep (“beeep”) and
one or two short beeps.
If the throttle stick is not all the way down when the battery is
connected to the ESC, the motor will beep rapidly (“beep, beep,
beep, beep, beep…”) until either the battery is disconnected
or the throttle stick is returned to the Off position. Then the
normal beep sequence will resume.
If the chime sounds followed by continuous, slow beeps
(“beep…beep…beep…beep…”), then the receiver is not
receiving a signal from the transmitter. You may need to
link the receiver to the transmitter, or check the connection
between the ESC and the receiver.
THROTTLE CALIBRATION
If you connect the battery to the ESC and hear the three
chimes (“1 2 3”), but then the motor beeps rapidly (beep,
beep, beep, beep, beep, beep….) and does not run when
you move the throttle stick, the ESC is not detecting the
end points of the throttle stick and requires calibration.
Recalibration may also be required if you ever switch to
a different transmitter, or if you adjust the throttle trim or
throttle end points in your transmitter:
1. Remove the propeller.
2. Turn on the transmitter and advance the throttle to the
“up” position.
3. Connect the battery to the ESC and hear the chime
followed by two long beeps (“beeep, beeep”) indicating
that the ESC has read the top of the throttle range.
4. Move the throttle stick to the low position and again hear
a single long beep (“beeep”) (signaling that the ESC has
read the bottom end of the throttle range) followed by
one or two short beeps signaling the completion of the
procedure. Now the throttle has been calibrated.
1 or 2
Short
Beeps
“beep” or
“beep beep”
Chime
“1 2 3”
Two Long
Beeps
“beeep
beeep”
(Lower
the throttle
stick)
Motor
is
Armed
Single
Long
Beep
“beeep”
Note: If this recalibration does not work, increase or decrease
the throttle trim or end point for low throttle on your transmitter
and repeat the procedure.
BRAKE SETTING
The ESC is preset from the factory with the motor brake off,
but if you inadvertently turn on the brake, or if the ESC was
not set correctly, follow these instructions to turn On or Off
the brake:
1. Remove the propeller.
2. Turn on the transmitter and move the throttle stick all the
way up.
3. Connect a battery to the ESC to power up the ESC
and radio.
A. Hear the chimes (“1 2 3”) followed by two long
beeps (“beeep, beeep”) followed by a pause, a short
beep (“beep”), another pause, then two more short
beeps (“beep, beep”).
B. If you do nothing, the brake will not be changed.
Disconnect the battery from the ESC.
C. To change the brake setting (on or off) reconnect the
battery to the ESC with the transmitter on and the
throttle stick all the way up. Lower the throttle stick
after the single short beep to turn the brake off; or
lower the throttle stick after the two short beeps to
turn the brake on:
Chime
“1 2 3”
Two Long
Beeps
“beeep
beeep”
2 Short
Beeps
“beep beep”
Lower
the
throttle
stick
(Brake On)
Motor
is
Armed
Lower
the
throttle
stick
(Brake Off)
Short
Beep
“beep”
– OR –
D. After the throttle stick is lowered to turn the brake
on or off, the single, long beep will sound (“beeep”)
followed by a single short beep (brake off) or two
short beeps (brake on) depending on how you just
programmed the brake.
