Hohem ISTEADY X Manuale utente

V 2.1

Disclaimer and Warning

Congratulations on purchasing your new Hohem iSteady TM product.

By using this product, you hereby signify that you have read this disclaimer and warning carefully

and that you understand and agree to abide by the terms and conditions herein.

You agree that you are solely responsible for your own conduct while using this product, and for

any consequences thereof. You agree to use this product only for purposes that are proper and in

accordance with all applicable laws, rules, and regulations, and all terms, precautions, practices,

policies and guidelines Hohem iSteady has made and may make available.

Hohem iSteady accepts no liability for damage, injur y or any legal responsibility incurred directly or

indirectly from the use of this product. The user shall obser ve safe and lawful practices including,

but not limited to, those set forth in this document.

* When powering on iSteady X for the first time,

activation is required through Hohem Pro App.

The iSteady X will start to work after the activation be done.

* Mount your mobile phone before powering on iSteady X.

If not, you will hear beep as warning.

Download the App Hohem Pro

Scan the QR code or search for " Hohem Pro "

on the App Store or Google Play.

iSteady X Diagram

412

1. Phone Holder

2. Folding Lock

3. Pan Motor Lock

4. Batter y Indicator

5. Zoom Slider

6. Shutter

7. Tilt Motor

8. Roll Motor Lock

9. Tilt Motor Lock

10. Knob

11. Pan Motor

12. Bluetooth Light

13. Joystick

14. Power Button (ON/OFF)

15. Tilt Motor Lock

16. Type C

17. Reset

18. 1/4 inch Screw Por t

19. Roll Motor

20. Roll Motor Lock

21. Pan Motor Lock

22. Handle

（Batter y built-in）

23. Wrist Strap

How to mount and balance mobile

phone on the gimbal?

①Unfold the gimbal

② Screw up the knob

The gimbal would work improperly

if not screw the knob up.

③ Make the

“HOHEM”logo

upward.

④ Put your phone stuck

in the bottom of holder

and pull the head of holder

to mount your phone.

⑤ Slide the holder

to the middle of

phone to balance

the gimbal.

Clench the holder, ensuring that your phone is cling to the

rubber mat, ot her w is e the gimbal would

vibrate or turn off automatically.

For the first time, please turn on the stabilizer. Log into the Hohem Pro App to activate the stabilizer.

If the activation fails, it will not be enabled properly.

Booting up for the first time

Activate iSteady X & Bluetooth Connection

Long press the function

button. When it is turned

on for the first time, it will

enter a to-be-activated

state and the Bluetooth

indicator light will flash

“red and green” alternately.

Turn on the phone's

Bluetooth, open the

APP, and log into the

home page. Follow

the prompt at the top

and click “Connect”.

After the Bluetooth is connected,

an activation prompt box will pop

up. Click "Confirm" to complete

the activation. After that, you will

hear a prompt tone of ticking, which

means the stabilizer star ts to work.

① Startup ② Bluetooth connected

directly in the Hohem Pro

App.

③ Activate iSteady X

Controls and Operations

① · Press and hold to power on/ off.

· Single ap to switch between landscape and t

portrait mode.

· Press twice to recenter the gimbal.

② Joystick：Move ver tically to tilt the mobile phone.

Move horizontally to pan the mobile phone.

Control roll axis can be set in Hohem Pro.

④ · Press once to take photo or start video or end video.

· Press twice to switch photo mode or video mode.

· Press three times to switch between front and back

cameras.（Available in the App）

③ o Zo m

①

③

④

②

How to switch working mode via button?

Press and hold shutter button and tap power button:

Single Tap: Pan& Tilt Follow

Double Tap: Pan Follow

Triple Tap: All Lock

Quartic Tap: POV (All Follow)

*Release power button first, then release shutter button.

Why the Lights Flash?

Power Indicator Lights

* Staying on: fully charged or charging complete

* Single flashing: charging

* Flashing in turn: calibrating

Bluetooth Indicator Light

Blinks red and green alternatively : stabilizer

is to be activated (for the first time)

Color indicates the current status of Bluetooth:

Green: Bluetooth is connected

Yellow: Bluetooth is to be connected

Red: Warning of abnormal loads on the stabilizer or

firmware update failed

Blinking indicates the current status of working modes

Solid Light: Pan& Tilt Follow

Flash for twice: Pan Follow

Flash for triple: All Lock

Flash for four times: POV (All Follow)

Specifications

iSteady X

179 X 79 X 39 mm

259 g

Weight ：≤280g

Thickness：≤11 mm

Width：55mm~90mm

* Pan: 320°.

* Roll: 320°.

* Tilt: 320°

18650li-ion

2000 mAh/3.7V

Model

Folded Dimensions

Weight

Compatible Phones

Mechanical Range

Battery

Operating Time 8 hours

* Pan: 320°.

* Roll: 320°.

* Tilt: -30°~+30°

Controllable Range
