ASSEMBLY INSTRUCTION

824-026V70

READ AND SAVE THIS INSTRUCTION FOR FUTURE USE

824-026V70 220-240V~,50HZ

INcjh013V01_UK

Important Safe Guards

When using an electrical appliance, basic safety precautions must always

be observed, including the following:

Read all Instructions before Using

WARNING:Toreducetheriskoffire,electricalshock, andinjury toperson,the

followingmust beadheredto:

1. This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of experience

and knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for their safety.

2. Children should be supervised to ensure that they do not play with the

appliance.

3. The product is for household use only.

4. Connect the appliance to a single-phase AC supply voltage, specified on

the rating plate.

5. Never leave the fan un-attended while it is in use. Always turn the fan to

the “OFF” position, and unplug the fan from the electrical outlet socket,

when not in use.

6. Extreme caution is necessary when any fan is used by or near children,

invalids or elderly persons, and whenever the fan is left operating

un-attended.

7. The fan cord must not be placed under carpets, or covered with throw

rugs, runners or similar. Arrange the cord away from the traffic area, and

where it will not be tripped over.

8. Do not operate the fan with a damaged cord or plug, or after the fan

malfunctions, or has been dropped, or damaged in any manner.

9. If the supply cord is damaged, either the manufacturer, or the service

agent, or a similarly qualified person, must replace it, to avoid a hazard.

10. Use the fan in a well ventilated area. While in use, ensure that the

airtakes or exhaust openings are not blocked un-expectedly, and the fan

distance from the wall or corner must be no less than 20cm. The fan

should not be placed below or besides any curtains or similar

11. To avoid mechanical danger when in use, do not insert, or allow fingers,

or any other objects into the grill. Do not block the air-intakes or the

exhaust openings in any manner.

12. The fan must only be placed, and used on a flat dry floor.

For household use only

Structure and parts

1. handle

2. back grill

3. head

4. front grill

5. wheel seat

6. tube

7. base

8. indicated light

9. off button

10. on/speed button

Operating Instructions and Function

Remote control Control panel

On/speed

Press on the control panel or press on the remote control to

start the fan, means low speed, means medium speed, means

high speed.

OFF

Press on the control panel or press on the remote control to turn

off the fan.

Oscillation

Press on the control panel or remote control to start oscillate, this

model will oscillate as below:

off

means right and left oscillate

means up and down oscillate

means right left and up down oscillate

Timer

Press on the control panel or press on the remote control to

choose the duration of time. The timer is 7 hours. To cancel the set timer,

press the “Timer” button again and press the “Timer” button to set as 00 Hr.

Mode

Press on the control panel or remote control to choose the mode you like.

the default mode is Normal, the LED screen will indicate

This fan have three mode: Normal/ Natural/ Sleeping

means Normal, means Natural, means sleeping

Cleaning / Maintenance Instructions

To safely take care of your fan, please remember to follow these

instructions below:

1. Always remove the plug from the socket-outlet, and allow the fan to stop

completely before cleaning the fan.

2. Do not allow water to drip on, or enter into the fan housing.

3. Always use a soft cloth, moistened with a mild soap solution.

4. Do not use any of the following agents as a cleaner: Gasoline, Thinners,

or Benzene.

5. In case of malfunction or doubt, do not try to repair the fan yourself, it

may result in a fire hazard or electric shock.

FAN Cleaning

Clean the fan grill, housing and base with a soft damp cloth. Do not attempt

to remove the fan blades. Please use caution around the motor housing

area. Do not allow the motor, or other electrical components to be exposed

to water.

FAN Storage

When storing your fan in the off-season, it is important to keep it in a safe

dry location. It is important to protect the fan head from any dust. We

strongly recommend using the original box, when storing the fan away.

Waste disposal

The symbol indicates that this product is not to be disposed of together

with household waste. This product must be delivered to a recycling

service or container for electrical appliances and electronic equipment.

This is done to avoid health risks and prevent harm to the environment.

Local businesses (or the environmental station in your neighborhood) are

required by law to accept and recycle such products, as a means of

environmentally sound disposal.
