3800g

From the global leader in imaging technology comes the 3800g – the

newest member of the legendary 3800 family of linear imagers.

The ﬁrst in a new class of 3800 linear imagers, the 3800g was built

to deliver world-class performance for a broad range of market

applications.

Featuring an ideal balance of performance, durability, ergonomics,

and connectivity solutions, the 3800g delivers years of hassle-

free scanning for applications in retail, warehouse, manufacturing,

distribution – and all points in-between.

The ﬁrst linear imager to earn the Adaptus®Imaging Technology

brand, the new 3800g is powered by Adaptus 5.0, delivering

breakthrough linear imaging performance and versatility. Fast,

intuitive bar code reading across a range of high and low density

codes, the 3800g quickly reads even damaged and poorly printed

bar codes - all in a single device.

Sound, ergonomic design and class-leading durability, coupled

with aggressive reading performance, makes the new 3800g the

ideal choice for customers who appreciate best-in-class value in a

handheld linear reader.

Performance and Versatility Powered by Adaptus

Imaging Technology 5.0:

Excellent tolerance to lateral hand motion (4x faster)

makes 3800g easy to use.

270 scans per second makes bar code reading faster than

ever.

Improved depth of ﬁeld across a broad range of linear bar

codes.

Working range from .5 inches to 18 inches on 100% UPC/

EAN symbols.

Improved ability to read damaged or poorly printed bar

codes.

General Purpose Reader: Single device covering the

broadest range of customer applications.

Modern, Ergonomic Design: Sleek, modern industrial

design results in a smaller, lighter device for increased

operator comfort and productivity.

Durable: Built to last with no moving parts to wear out. Full

impact resistant bumpers and a 5 year warranty make the

3800g one of the toughest scanners on the market.

•

General Purpose Linear Imager

Connectivity: All popular interfaces are on board.

Includes Visual Express™ software for ease-of-

integration. Supports Uniﬁed POS standard and

Windows® Embedded for Point of Service, for retail

connectivity.

Common Cabling: Uses same cable solutions as our

linear, 2D, and Cordless imagers – for easy ordering and

efﬁcient spares pools.

Future Proof Symbology Support: GTIN compliant,

GS1 DataBar capable.

Intuitive Aiming Line: Thin, crisp aiming line for

ease-of-use in scanning bar coded menus and densely

populated documents.

Full Line of Accessories: Includes presentation

scanning, global power choice options, and purpose built

mounting solutions.

Intuitive User Feedback: Fully programmable options

for application-speciﬁc “good read” LED and beeper

settings.

•

Features

Automation and Control Solutions

Honeywell

Imaging and Mobility

700 Visions Drive

PO Box 208

Skaneateles Falls, NY 13153-0208

www.honeywell.com/aidc

3800g Speciﬁcations

Performance

Illumination: 630 NM Visible Red LED

Receiving Device: 3648 element linear imager

Reading Distance: From .5 in. (1.3 cm) to 18 in. (46 cm) on medium density bar codes

Reading Width: 7.5 mil code: 7 in. (18 cm) from nose, 3.5 in. (8.9 cm) wide

13 mil code: 12.5 in. (31.8 cm) from nose, 8.0 in. (20.3 cm) wide

Resolution: 3 mil. at 4 in. (10 cm) distance

Skew Angle: +65o

Pitch Angle: +65o

Horizontal Velocity: 20 in. (51 cm) per second

Minimum Symbol Contrast: 20%

Scan Rate: Up to 270 scans per second

Decode Rate: 270 decodes per second

Mechanical/Electrical

Length: 4.4 in. (11.2 cm)

Height: 5.9 in. (15.0 cm)

Width: 3.1 in. (7.9 cm)

Weight: 5.6 oz. (158.8 g)

Housing: UL 94V0 grade

Power Requirements: 3800GX5E: 4.5 - 12Vdc at scanner

3800GX4E: 4.5 - 5.5Vdc at scanner

Current Draw (Maximum): Input

5 V

12 V

Scanning

235mA

145mA

Idle

86mA

65mA

Power Supply

Noise Rejection: Maximum 100mV peak to peak, 10 to 100 kHz

Environmental

Operating Temperature: +32oF to +122oF (0oC to +50oC)

Storage Temperature: -40oF to 140oF (-40oC to +60oC)

Humidity: 0 to 95%, non-condensing

Mechanical Shock: Operational after 50 drops from 5 ft. (1.5 m) to concrete

Ambient Illumination: 0 - 70,000 lux

ESD Protection: Functional after 15kV discharge

Vibration: Withstands 5G peak from 22 to 300 Hz

Agency: International: CB scheme to IEC60950-1 & IEC60825-1 Class 1 LED. USA: FCC Part 15 subpart B Class B. UL listed to

60950-1. Canada: ICES-003 Class B. cUL listed to CSA C22.2 No. 60950-1-03. Europe: CE 2004/108/EC EMC Directive to

EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3. 2006/95/EC Low Voltage Directive. GS Mark: GS marked for I.T.E.

safety. Mexico: NOM-NYCE. Korea: MIC Class A. Taiwan: BSMI. Australia/NZ: C-Tick mark.

MTBF: per MIL-HDBK-217F Ground Benign exceeds 100,000 hours

Symbologies: Codabar, Code 3 of 9 including PARAF, Interleaved 2 of 5, Straight 2 of 5 Industrial, Matrix 2 of 5, Code 11, Code 93, Code 128,

UPC, EAN/JAN, China Postal Code, GS1 DataBar. 2005 Sunrise/GTIN compliant, and ISBT 128 Concatenation (requires a paid

license).

Interfaces: 3800GX5E: All popular PCs and terminals via keyboard wedge, keyboard replacement/direct connect, USB, TTL level RS-232,

IBM, 46XX retail terminals, and Retail USB.

3800GX4E: All popular PCs and terminals via keyboard wedge, keyboard replacement/direct connect, USB, and TTL level RS-232

Warranty: Five year factory warranty.

Typical Performance*

Narrow Width Depth of Field

5.0 mil 2.0 - 8 in. (5 - 20 cm)

7.5 mil 1.5 - 12 in. (4 - 30 cm)

10 mil (80% UPC) 1.0 - 15 in. (3 - 38 cm)

13 mil (100% UPC) .5 - 18 in. (1 - 46 cm)

15 mil 1.0 - 22 in. (3 - 56)

20 mil 1.0 - 26 in. (3 - 66 cm)

*may be impacted by bar code quality and

environmental conditions

3800G-SS Rev E 3/08
