Honeywell HS-6270 Manuale utente

User's Manual

Home System

for the safety and happiness of your home

To get the best use of the product, please

read the user's manual carefully before

using the product.

Keep the user's manual at an easily accessible

place and make it available to the next user.

HS-6270

The specification of product picture may vary the

model.

Accessing the fire/gas control test mode

※ Refer to page 16 for more details.

Press ,

Press , to shift to fire test mode.

Press , to shift to gas test mode.

Safety Precautions

Usage Suggestions

Contents

Parts of HS-6270

Function Setting

Adjusting the Volume of the Bell

Adjusting the Brightness of the Screen

Setting the Safety Zone

Setting, Changing, Deleting, and Checking

the Password

Phone Call Function

Telephone Function

Answering the Phone

Talking to Someone at the Door

Taking Calls from the Door

Monitoring the Door

Interphone Function

Answering the Interphone

Making a Call over the Interphone

Reaching the Guard Post

Taking Calls from the Guard Post

How to Reach the Guard Post

Talking to Someone at the Common Entrance

Taking Calls from the Common Entrance

Setting, Changing, and Checking the Exit/Entry

Delay 9

Security and Alarm Functions

Away Mode

Reporting an Emergency

Deactivating the Emergency Alarm

Testing the Alarm Sound

Sleep (stay) Mode 14

Room Mode (deactivating the away and sleep modes)

In Case of Emergency

In Case of Fire or Gas Leakage

In Case the Security Alarm is Activated

Using the Camera

Troubleshooting

Product Specifications

Product Warranty

Making a Phone Call 11

Adjusting the Volume of the Phone 7

HS-6270 User's Manual / 1

Electronic Bullet Board Function

Saving Image Function 18

2 / Honeywell Co., Ltd.

To prevent property damage, make sure you have read the "Safety Precautions"

before using your system.

The following symbols denote the degree of damage that may arise in case of failure to

follow the specified precautions.

Indicates the serious damage or

even loss of life that may result

from failure to follow instructions.

Refers to injury or property damage

that may result from failure to follow

instructions.

Warning Caution

The following symbols denote the points that should be followed by the user.

Warning

"Prohibitory", meaning the

action being referred to

should never be taken.

Warning

"Mandatory", meaning you

should follow the

instructions indicated.

Do not disassemble at

any time (may result in

property damage or loss

of life).

Do not touch (may result

in property damage or

loss of life).

Warning Warning

Safety precautions

Keep the product away from moisture

(contact with moisture or other liquids

may cause fire, electric shock, or

malfunction).

If the panel comes into contact with

water, unplug the cord immediately

to avoid electric shock or fire.

Keep the product away from sources

of heat to avoid fire or malfunction.

When the alarm sounds, take

appropriate measures immediately.

Intrusion, fire, or gas leak may lead to

hazardous situations.

Warning

Do not disassemble or modify the

product (may lead to electric shock,

fire, or malfunction).

Do not use the product in places

exposed to inflammable gases or

debris such as propane gas or

gasoline (may cause explosion or fire).

Check the gas sensor monthly.

Replace it after 4 years.

Malfunction may result in hazardous

situations.

Replace the fire sensor every 2 years.

Malfunction may result in hazardous

situations.

HS-6270 User's Manual / 3

Safety precautions

4 / Honeywell Co., Ltd.

Caution

Safety precautions

Do not use benzene or other volatile

substances (may damage the product).

Do not place the product near large

TV's or speakers that generate strong

magnetic forces

(may cause malfunction).

Do not install on an unstable location

(may get detached and result in

breakdown or injury).

Keep away from direct sunlight.

Do not store in high-temperature

areas (may cause product deformation

or malfunction).

Keep out of reach of children

(product may cause injury).

Child users should be instructed on

the product's proper use. Adult

supervision is recommended to

avoid injury.

Do not apply shock or impact to the

product (may cause breakdown).

When the gas leak alarm sounds, perform the following steps.

1) Close the gas valve immediately and open the windows and doors to secure ventilation.

2) Do not unplug or plug in electrical devices.

3) Do not open the refrigerator.

4) When the gas is completely removed, check the gas appliance.

Usage suggestions

To get the best use of the product, take note of the following.

HS-6270 User's Manual / 5

1. When using the gas alarm and/or fire sensor, follow the manufacturer's instructions.

2. Make sure that the product is impervious to volatile gases to avoid sounding the fire alarm by

mistake.

3. In case of product breakdown, do not disassemble the body or sensor. Contact the vendor.

4. In case the main panel goes out of order, contact the vendor.

5. Use the emergency button only when necessary.

6. The product does not function during blackout or in case the circuit breaker is shut down.

7. To clean the product, use a soft cloth.

Do not use volatile liquids (i.e. benzene, thinner) or wet cloth to clean the product.

Function Lamp

Indicates the function setting status.

Stay Lamp

Indicates the stay setting status.

6 / Honeywell Co., Ltd.

※ The location of the lamps and specifications may vary by model.

Emergency Button/Lamp

Used in case of

emergencies; indicates the

emergency status.

Talk Button/Lamp

Used when talking over the telephone

and interphone.

Guard Button/Lamp

Used when calling the guard post

and common entrance.

Door Button/Lamp

Used when talking to someone at the door.

Test/Function (open)

Opens the door to the

entrance or common

entrance.

Microphone

Parts of HS-6270

Parts of the control panel

Away Button/Lamp

Sets your home to away

mode and indicates that the

system is in away status.

Speaker

Power Lamp

Fire/Gas Lamp

Signals a fire/gas alarm.

LCD

Shows an image of the entrance.

10KEY, (stop), # (reset) button

Used when inputting numbers for

dialing/function setting/entering

the code.

Safety Zone Lamp

Indicates the Safety Zone and

Burglar Alarm states.

Function Lamp

Indicates the function setting status.

Function Setting

Adjusting the Volume of the Bell

Press the button.

Press .

Adjusting the Brightness of the Screen

Press (low), (medium), or (high) to adjust the volume level.

HS-6270 User's Manual / 7

Adjusting the Volume of the Phone

To end the function setting menu, press the button.

Press the button.

Press .

Press (dark), (medium), or (bright) to adjust the brightness level.

To go to another function setting menu, press .

To end the function setting menu, press the button.

Press the button.

Press .

Press (local), (door), (guard post), (common entrance), or (interphone).

The volume is set to medium level when released.

Press (small) ~ (large).

To end the function setting menu, press the button.

Function Setting

Setting the Safety Zone

※ When activating the security system, you can set the Safety Zone.

The zone setting is not affected, even though alarm function or away mode and/or

sleep mode is deactivated.

8 / Honeywell Co., Ltd.

Press the button.

Press .

Press (Safety Zone 1), (Safety Zone 2), (Safety Zone 3), or (Safety Zone 4),

then the corresponding safety zone lamp blinks. Press it again to turn off.

Pressing the corresponding safety zone button causes the safety zone to be set

(not monitored: safety zone lamp blinks; monitored: safety zone lamp goes out).

To go to another function setting menu, press .

To end the function setting menu, press the button.
