Hoover CH81055 Manuale utente
ULTRA HIGH-SPEED BURNISHERS/ 1.5 HP, 1500 or 2000 RPM/ 21” Apron
™
PART# 961130008-10/10-REV1
SPECIFICATIONS
Machine Speed 1,500 RPM 2000 RPM
Model Size 21” 21”
Pad Size 20” 20”
Weight 84 lbs 86 lbs
Motor Type 1.5 HP DC Rectied Same
Amp Draw 13-15 amps Same
Chassis Polished Aluminum Same
Power Cord 50’ Safety Yellow, 14G Same
Wheels 5” non-marking operating Same
4” inch transport Same
Down Pressure Controller No Yes
Warranty 5-year motor & transmission Same
, ext.2554
69C Drive Belt- 2000 RM DB-1 1
70 Allen Head Set Screw for PD B-149 2
71C Pulley to Fit Motor-1500 RPM DC PM-3 1
71D Pulley to Fit Motor- 2000 RPM DC-PM 1
72 Cotter Pin Wheel Axle B-142 2
73 Spring Washer B-51 4
74 Wheel Axle B-16 2
75 6” Wheel M-250 2
76 Transport Wheel Axle Bolt B-26 2
77 Transport Wheel- 4” M-209 2
78 Lock Nut B-77 2
79 Front WheelAssy- 2000 RPM only PCA-1 1
Ultra High Speed Burnisher
1.5 HP / 1500 or 2000 RPM / 21”Apron
™
Ultra High Speed Burnisher
1.5 HP / 1500 or 2000 RPM / 21”Apron
™
