Hoover CH83005 Manuale utente
General-Duty Floor Machines 175 RPM / 1.5 HP / 17”
© 2010 Copy Rights Reserved Hoover, Inc.
Hoover, Inc.
7005 Cochran Road
Glenwillow, Ohio 44139
(888) 321-1134
For Service,Ask for Tech. Service Dept., ext. 2554
www.hoover.com
© 2010 Copy Rights Reserved Hoover, Inc.
Hoover Inc.
New Equipment Warranty
Limited Warranty
Hoover Inc. warrants new equipment against defects in material and workmanship under normal
use and service to the original purchaser. Any statutory implied warranties, including any warranty
of merchantability or tness for a particular purpose, are expressly limited to the duration of this
written warranty. Hoover Inc. will not be liable for any other damages, including but not limited
to indirect or special consequential damages arising out of or in connection with the furnishing,
performance, use or inability to use the machine. This remedy shall be the exclusive remedy of the
purchaser. The warranty period is subject to the conditions stated below.
1 Year - Motor and Gearbox, 1 Year - Service Labor
Hoover, Inc, warrants electric motors and transmission gearboxes on all Hoover oor machines
to be free from defects in material and workmanship, under normal use and service for one (1)
year to the original purchaser. Parts replaced or repaired under this warranty are warranted for the
remainder of the original warranty period. Service labor charges are covered for one (1) year from
the date of purchase, when performed by a Hoover-authorized service provider. Freight charges to
and from this service provider will be covered for 90 days from the purchase date. After this 90 day
period, these freight charges will be paid by the equipment owner. Travel expenses are not covered.
Wear Items on all Machines
Critical Wear Items - bearings, capacitors, clutches, pulleys, rectiers, relays, switches, wheels,
tires and casters are warranted for manufacturing defects for one (1) years from the purchase date.
Normal Wear Items - belts, brushes, bumpers carbon brushes, cords, nishes, squeegees, actuating
cables and gaskets are warranted for manufacturing defects for ninety (90) days from the purchase
date.
All warranties of motors and associated components will be voided; if the machine is used as a
oor sander, if the machines is serviced by anyone other than a Hoover-authorized service provider;
if the machine is mechanically modied; or if the machine is misused or abused.
The warranty starts on the purchase date by the original purchaser from an authorised Hoover
Inc. distributor, subject to proof of purchase. The machine registration card must be completed
and returned immediately at the time of purchase. If proof of purchase cannot be identied, the
warranty start date is 90 days after the date of sale to an authorized Hoover, Inc. distributor.
Design and Engineering
Powered by a general-duty, 1.5 HPA/C dual• capacitor, 10.9 amp, 66-frame, 110V motor for
convenient operation.
The dual capacitor gear drive is reliable and safe• to use.
The steel chassis and apron has an attractive• HDPE plastic shroud. HDPE surfaces are easy
to clean.
17” size. Scrub with a 16” rotary brush or a 17”• pad and pad driver. Easy brush mounting with a
“B” / “92” style brush drive plug.
Includes a 4 gallon molded plastic solution tank• with chain valve release. Convenient dispensing
ofoorcarechemicalstotheworkingarea.
Dual thumb-operated safety-enhanced interlock• switch on the handle leaves both hands in
convenient control.
Safety-enhanced, non-conductive dual triggers• on the handle eliminate shock potential.
48” tall handle is fully adjustable to be• comfortable for all operators.
Includes a 50-foot power cord. The motor plugs• into cable at the base of the handle for easy
maintenance.
The non-marring bumper protects walls and• baseboards.
Non-marring 4” wheels make transport easy.• 1-year warranty on motor, transmission and• chassis.
Includes (1) 17” Pad Driver, (2) 16” Brushes and• (1) 16” White Cleaning Pad.
Preferred for Light Commercial,
Hospitality, Health Service and
Food Service Scrubbing and Bufng
Specications
Machine Size 17”
Motor Type 1.5 HPA/C - 2 capacitors, 10.9 amps
Brush Size 16”
Pad Driver Size 17”
Brush Drive “92” style / “B” style drive plug and clutch plate
Shipping Weight 107 lbs.
Brush Speed 175 RPM
Power Cord 50 foot
Warranty 1 years motor and gearbox
™
Part# 961130003- 9/10- REV1
1.0 Safe Operating Conditions
READ THIS MANUAL BEFORE USING FLOOR MACHINE. KNOW THE
PROPER OPERATION, CORRECT APPLICATIONS AND THE LIMITATIONS OF
THIS EQUIPMENT BEFORE USE.
Reduce the Risk of Fire, Electric Shock or
Injury:
This• oor machine is designed for indoor use only. Do
not use outdoors. Do not expose to rain.
Do not wash the motor with owing water. If the motor • gets wet, seek authorized service.
Keep the vents on this air-cooled motor free from debris.•
Do not operate with the motor covered or with vents
blocked. Do not use this machine as a oor sander.
Never operate this oor machine near ammable dusts, •
liquids or vapors. Never use ammable solvents as a
cleaning agent. Engine sparks and operating heat can
cause re.
Never handle electrical equipment with wet hands. Never•
operate this oor machine with bare feet.
Unplug the oor machine when not in use and when • servicing the equipment. To unplug, grasp the plug not
the cord.
Do not operate a oor machine with damaged handle • controls, cord or plug. If the equipment is not performing
properly, seek repair from a qualied service supplier.
This oor machine is constructed with electrical • grounding at the plug. Operate only when connected to a
properly grounded outlet. See section 1.2 for grounding
details.
Prevent electrical cord abuse. Do not close a door •
upon the cord, drive equipment over it, or run the oor
machine over it. Do not expose the cord to hot surfaces.
Do not lift, pull or carry this oor machine by the cord.
Never operate the oor machine over sharp objects that • can be thrown out and harm the operator and damage
the oor. Sweep hard oors before scrubbing or bufng.
Vacuum clean carpets before shampooing or bonnet
cleaning.
Train your staff in proper use of this oor machine.•
1.1 Electrical Power
This oor machine operates on a 15 amp nominal 115V, 60 Hz, A.C. power circuit. The,
amp, hertz and voltage ratings are listed on the motor spec label found on each oor
machine. Using voltages above or below those indicated on the spec label will damage
the motor. Always check your local voltage requirements.
1.3 Extension Cords are Not Recommended
The oor machine is built with a 50 foot (15 M) safety cord which plugs directly into an
approved outlet. Use of any extension cords is NEVER RECOMMENDED.
1.2 Grounding Instruction
This oor machine must be grounded while in
use to protect the operator from electrical shock.
This machine is built with a 3-wire cord and a
3-prong grounding-type plug (Figure 1) to t a
properly grounded receptacle.
Before using this oor machine, make sure a
properly grounded, 3-hole electrical outlet is
available. If not available, as in some older
facilities, use an adapter for connecting a
3-prong plug to a 2-prong receptacle (Figure 2)
to ground the outlet chassis.
IMPORTANT!! This adaptor may not be used
in Canada.
IMPORTANT!! Never cut off the grounding
prong for use in a 2-prong outlet. By doing so,
you have cut off your protection from electrical
shock.
Never assume that all 3-hole outlets are
properly grounded. Check before use.
Never assume that an adaptor connection
(as in Figure 2) is properly grounded. Check
the outlet with a ground fault interrupter
device which quickly indicated if a ground is
connected. Correct a faulty grounding before
proceeding.
(2) (3)
(5) (4)
3.0 Operating Tips
For indoor use only. Sweep abrasive soils before• scrubbing.
While the brush or pad driver is spinning, keep the oor •
machine moving to avoid “donut” burns on the oor.
To Start Operation:
Unlock the handle by raising the locking lever.• Lower the handle to a comfortable position, typically• waist height.
Relock the handle by pushing the lever down. NEVER •
OPERATE THE MACHINE WITH THE HANDLE
UNLOCKED.
This oor machine is a high torque motor. Hold the •
machine rmly with both hands when starting up.
Push the red safety interlock switch forward to unlock• the dual triggers.
Squeeze the dual triggers to release power to the motor.• Once power is on, either trigger will keep power to the
motor.
To stop the oor machine release both triggers.•
The spinning brush helps move the oor machine. (Lift • the handle slightly to work to the right. Push the handle
down slightly to work to the left.)
3.1 To Store your Machine
Lock the handle in the “up” position. Tilt the machine• back and remove the pad driver or brush.
Wind the cord around the handles and the bottom cord• hook.
Wash brushes or pads and hang to dry. Never store• machine standing on the brush.
Inspect and maintain equipment on a regular schedule• for best results.
Check and clean pads after each operation. Remove soil• and chemical buildup. Replace worn or damaged pads.
Check the triggers and switches for proper operation.• Repair or replace damaged skirts and dumpers.• Use air pressure or vacuum to remove dust and debris• from the motor vents.
Report problems and repair promptly.•
2.1 Attach the Power Cord
The triple-wire grounded power cord has been factory-
installedintothehandletube.Aexiblerubbercable
connector (11) is used to secure the plug-in connections.
Theoormachineshipswiththisconnectormountedonthe
cord coming out of the handle (10). Stretch the connector
and slip the male connector (9) (coming out of the motor
housing) through the connector hole and then into the
female connector.
Now, plug the end of the 50 foot cord into a grounded power
outlet. Squeeze the triggers on the handle and check for
power to the motor.
2.2 Install Brush / Pad Driver
Abrushorpaddrivermountsontoyouroor
machine with a “B” style universal clutch plate.
UNPLUG BEFORE INSTALLATION
Lock the machine handle in the “up” position and
tiptheoormachinebackfully.
Slide the brush or pad driver clutch plate
(11) over the drive plug (12).
Give the brush a quick counter clockwise
spin to lock the brush onto the drive plug.
Now, lower the machine back onto the brush.
The installation of the brush and pad driver is now
complete and the machine may be operated.
(7) (6)
4.0 Troubleshooting
Never operate this oor machine when the equipment is not performing as expected
or when any parts is visibly damaged. The cause and solution for some basic problems
are described below. When repair is needed, take the equipment to an authorized repair
service center.
4.1 The Floor Machine will not Run
Circuit breakers are tripped in the building.• Check and reset.
Equipment is unplugged.• Check plug wall and at machine base. Plug in.
Power cord failure.• Test with a working power cord. Lock the handle up and tip the
motor back. Unplug the cord at the motor and plug the motor into your working
power cord.
IMPORTANT! THIS IS JUST FOR TESTING. When you do this, you have• removed the safety handle controls from the circuit and you are sending power
directly to the motor. If the motor now spins, the problem is in the cord of the
handle assembly. Seek authorized repair services.
If the motor still does not spin, the problem is either in the male connection at the• motor base or in the motor. Seek authorized repair service.
Motor sparks or smokes.• Seek authorized repair service.
4.2 Electrical Shock to Operator
Equipment wiring failure or electrical short in the machine.• Seek authorized service.
Poor grounding or no grounding.• Test the outlet with a ground fault interrupter.
Retaincertiedelectriciantoinspectandrepairgrounding.NEVERclipoffthe
ground plug on your cord.
Repeated circuit breaking.• High amp draw and circuit breaking can be an electrical
or mechanical problem. Seek authorized repair service.
4.3 High Vibration
Pads are not centered on the pad driver.• Tip machine back and re-center the pad.
Uneven wear or warp of pads, pad drivers or brushes.• Replace.
Machine chassis is damaged by dropping.• Replace.
3.2 Transport
To transport this oor machine from the janitor’s closet
to the work area:
Lock the handle in the “up” position. Wid the cord• around the handles and the bottom cord hook.
Tip the machine back onto the transport wheels.• Push or pull the machine by the handle, not by
the cord or any other part of the machine. Travel
carefully.
(8) (9)
General-Duty Floor Machines 175 RPM / 1.5 HP / 17” General-Duty Floor Machines 175 RPM / 1.5 HP / 17”
™
™
Indice
Altri manuali Hoover Macchina per pavimenti
Hoover
Hoover CH83000 Manuale utente
Hoover
Hoover CH81015 Manuale utente
Hoover
Hoover Carpet Cleaner Manuale utente
Hoover
Hoover FloorMate SpinScrub Cleaner Manuale utente
Hoover
Hoover Ground Command Manuale utente
Hoover
Hoover FloorMate SpinScrub H3040RM Manuale utente
Hoover
Hoover FloorMAX Hard Floor Machine Manuale utente
Hoover
Hoover CH83 Guida
Hoover
Hoover Floor-A-Matic Manuale utente
Hoover
Hoover Dual Power Max Manuale utente
