Hoshizaki IM-500SAA Manuale

AM SERVICE TRAINING

Featuring the

IM-500SAA

80047 9/10/13

1) Dilute approximately 7.2 fl. oz. (214

ml) of recommended cleaner Hoshizaki

“Scale Away” with 0.8 gal. (3.0 lit.) of

water.

2) Turn off the power supply.

3) Remove all ice from the storage bin.

4) Remove the front panel.

5) Remove the screw, and then move the

water tank drain pipe to the drain

position. See Fig. 5. Use the screw to

secure the water tank drain pipe in the

drain position.

6) Make sure the control switch is in the

“ICE” position, and then replace the

front panel.

7) Close the icemaker water supply line

shutoff valve.

8) Turn on the power supply for 3

minutes. The water tank drains and cubes

are removed from the evaporator.

9) Turn off the power supply.

10) Remove the front panel and top

panel.

11) Move the control switch to the

“WASH“ position.

12) Slowly pour the cleaning solution

over the top of the evaporator and into

the water tank. Do not splash or spill the

solution onto other parts.

13) Replace the front panel and top panel

in their correct positions.

14) Turn on the power supply to start the

washing process.

15) Turn off the power supply after 30

minutes.

16) Open the icemaker water supply line

shut-off valve. See Fig. 4.

17) Remove the front panel.

18) Move the control switch to the "ICE"

position.

19) Replace the front panel.

20) Turn on the power supply for 3

minutes. The water tank drains.

21) Turn off the power supply.

22) Repeat steps 20 and 21 three more

times to rinse thoroughly.

SANITIZING:

1) Dilute a 5.25% sodium hypochlorite

solution (chlorine bleach) with water

(add approximately 0.4 fl . oz. (12

ml) to 0.8 gal. (3.0 lit.) of water).

2) Close the icemaker water supply line

shut-off valve.

3) Turn on the power supply for 3

minutes. The water tank drains.

4) Turn off the power supply.

5) Remove the front panel and top

panel.

6) Move the control switch to the

“WASH“ position.

7) Slowly pour the sanitizing solution

over the top of the evaporator and

into the water tank. Do not splash or

spill the solution onto other parts.

8) Replace the front panel and top panel

in their correct positions.

9) Turn on the power supply to start the

sanitizing process.

10) Turn off the power supply after 15

minutes.

11) Open the icemaker water supply line

shut-off valve.

12) Remove the front panel.

13) Move the control switch to the

“ICE“ position.

14) Replace the front panel.

15) Turn on the power supply for 3

minutes. The water tank drains.

16) Turn off the power supply.

17) Repeat steps 15 and 16 three more

times to rinse thoroughly.

18) Repeat steps 1 through 17 one more

time.

19) Remove the front panel.

20) Remove the screw, then move the

water tank drain pipe to the

normal position. See Fig. 5. Use

the screw to secure the water tank

drain pipe in the normal position.

21) Replace the front panel.

22) Clean the storage bin liner using a

neutral cleaner. Rinse thoroughly

after cleaning.

23) Turn on the power supply to start the

automatic ice making process.
