CCBBEERR DDIIMMEENNSSIIOONNSS

W x D x H

KM-101BAH

4/08

Item # 13209

SELF-CONTAINED C BER WITH B ILT-IN STORAGE BIN

Warra ty

Valid in United States, Canada, uerto Rico, & U.S. Territories. Contact factory for warranty in

other countries.

Three Year - arts & Labor on entire machine.

Five Year - arts & Labor on: Evaporator.

Five Year - arts on: Compressor, air-cooled condenser coil.

KM-101BAH

Item #

Project:

Qty:

Hoshizaki reserves the right to change specifications without notice.

KM-101BAH

233/4 x 24 x 39*

* with 6" legs

*AutoCad available on KCL

KM-101BAH

Air-Cooled

Shown

•Up to 115 lbs. o ice production per 24 hours

• Up to 53 lbs. o built-in storage capacity

• Individual crescent cube

•Durable stainless steel exterior

• CycleSaver®Design

• EverCheck®alert system

• Front in, ront out air low

• Stainless steel evaporator

• Slide in door

• Removable air ilter

• Power switch accessible without panel removal

• Built-in installation possible

• Optional drain pump HS-0190 with HS-0215*

(*HS-0215 included at no extra charge)

• Complies with Cali ornia Energy Commission (CEC)

• R-134a Re rigerant

* The KM-101BAH is ENERG STAR certified.

Hoshizaki

DIMENSIONS

W x D x H

KM-101BAH

233/4 x 24 x 39*

*with 6" legs

©HOSHIZAKI AMERICA, INC.

KM-101BAH

SELF-CONTAINED CUBER WITH BUILT-IN STORAGE BIN

UTILITY CONSUMPTION

Mod l Numb r Ic Production

Pr Cycl

KWH p r

100 LBS.

Potabl

Wat r

Gal. p r

100 lbs.

Lbs. Cub s

KM-101BAH

SPECIFICATIONS

Mod l Numb r Cond ns r Amp rag Min. Circuit

Ampacity Shipping

W ight

5.2 15A 136 lbs.

KM-101BAH

9.4 23.0

Air-Cooled

2.31 110

Cond ns r

Wat r

Gal. p r

100 lbs.

N/A

O P E R AT I N G L I M I T S

• Ambient Temp Range 45 - 100˚F

• Water Temp Range 45 - 90˚F

• Water ressure 10 - 113psig

• Voltage Range 104 - 127V

ELECTRICAL&PLUMBING/KM-101BAH

• 115V/60/1

• 15 amp Max Fuse/HACR Breaker Size

• 3/8” OD copper or equivalent independent potable water supply

• 3/4” independent drain connection

• 1/2” F T Water Inlet

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com Printed in U.S.A.

FRONT DIMENSIONS

BACK DIMENSIONS

SIDE DIMENSIONS

KM CUBE DIMENSIONS

• Air-cooled

AIR-COOLED

70˚

50˚ 70˚

115

90˚

80˚

90˚

Air T mp˚ F.

Wat r T mp˚ F.

109

107
