Hoshizaki KM-320MAH-E Manuale utente

Hoshizaki

©HOSHIZAKI AMERICA, INC.

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshiza i.com

CUBER DIMENSIONS

xDxH

KM-320/515MAH-E

8/08

Item # 13125

SLIM-LINE MODULAR CRESCENT CUBER

arranty

Contact factory for warranty information.

KM-320/515MAH-E

Item #

Project:

Qty:

Hoshizaki reserves the right to change specifications without notice.

KM-320/515MAH-E

56 x 69.5 x 77cm

*AutoCad availa le on KCL

KM-320MAH-E

•Up to 133 kgs. of ice productio per 24 hours

KM-515MAH-E

•Up to 233 kgs. of ice productio per 24 hours

•Mou t two u its side by side for 466 kgs. per 24 hours

KM-320MAH-E & KM-515MAH-E

•Durable stai less steel exterior

•I dividual cresce t cube

•Protected by HoshiGuard A timicrobial Age t

•CycleSaver®Desig

•EverCheck®alert system

•Stai less steel evaporator

•Removable air filters

•R-404A Refrigera t

KM-320MAH-E

Air-Cooled

Shown

KM-515MAH-E

Air-Cooled

KM-320/B-700

KM-320/B-500

KM-320/B-300

KM-515/B-500

KM-515/B-700

KM-515/B-900

KM-515/B-800

KM-515/B-300

Also available on Lar e Bins:

B-1150SS

B-1300SS

Hoshizaki

DIMENSIONS

xDxH

©HOSHIZAKI AMERICA, INC.

KM-320/515MAH-E

SLIM-LINE MODULAR CRESCENT CUBER

UTILITY CONSUMPTION at 32ºC A/ 21ºC

AIR -C OO LE D - KM -3 20 MA H- E

Model Number

21˚

10˚ 21˚

133

32˚

27˚

32˚

Ice Production

Per Cycle

KWH per

45 Kgs.

Potable

Water

Liters per

45 kgs.

Kgs. Cubes

KM-515MAH-E

Air Temp˚ C.

Water Temp˚ C.

SPECIFICATIONS

Model Number Condenser Amperage Min. Circuit

Ampacity Shipping

Weight

7.14 15 A 79 kgs.

Air-Cooled

KM-515MAH-E

84.0

127

125

114

116

106

3.6 360

105

Condenser

Water

Liters per

45 kgs.

N/A

O P E R AT I N G L I M I T S

• Am ient Temp Range 7 - 38˚C

• Water Temp Range 7 - 32˚C

• Water Pressure 0.7 - 8 kg/cm2

• Voltage Range 198 - 254V

ELECTRICAL&PLUMBING/KM-320/515MAH-E

• 220-240/50/1

• 15 Amp Max Fuse

• 0.95cm OD copper or equivalent independent pota le water supply

• 3/4” FPT independent drain connection

SERVICE

• Panels easily removed and all components

accessi le for service.

• Remova le/cleana le air filters

618 Hwy. 74 S., Peachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshiza i.com Printed in U.S.A.

KM-320/515MAH-E

56 x 69.5 x 77cm

AIR-COOLED - KM-515MAH-E

21˚

10˚ 21˚

233

32˚

27˚

32˚

Air Temp˚ C.

Water Temp˚ C.

222

219

200

182

166

185

KM-320MAH-E

7.1 100.3

4.6 480 N/A

3.5 15 A 79 kgs.

Air-Cooled

KM-320MAH-E

STORAGE BINS

Model Number Application Capacity

B-500 227 kgs.

B-700 318 kgs.

KM-320 FRONT VIEW KM-320 SIDE VIEW

KM-320/515 ICE DROP ONE

KM-515 FRONT VIEW KM-515 SIDE VIEW

• Air-cooled

B-300 136 kgs.

B-900 409 kgs.

B-1150 522 kgs.

B-800 363 kgs.

B-1300 578 kgs.

Power Cord Supply

Dr in

3/4 FPT

(Dew W ter)

Dr in

STAINLESS TUBE

3/8 O.D.

1-3/16"

(30mm)

27-3/8"

(695mm)

1/8"

(3mm)

21-7/8"

(555mm)

22"

(560mm)

30-5/16"

(770mm)

Power Cord Supply

Dr in

3/4 FPT

(Dew W ter)

Dr in

STAINLESS TUBE

3/8 O.D.

1-3/16"

(30mm)

27-3/8"

(695mm)

1/8"

(3mm)

7.3
