Specification Created 12/03

410320

®

HTS18ICP – Hotpoint 17.9 Cu. Ft. Top-Freezer Refrigerator with Icemaker

R

R

Total volume and shelf

area are calculated by the

Association of Home

Appliance Manufacturers’

standards.

Listed by

Underwriters

Laboratories

Note: Before installing, consult installation instructions packed with product

for current dimensional data.

Note: All Top-Freezer No-Frost Right-Hand Refrigerator Doors: As you

face the front of the refrigerator, the handle is on your left and the

hinges are on your right.

All Top-Freezer No-Frost Left-Hand Refrigerator Doors: As you

face the front of the refrigerator, the handle is on your right and the

hinges are on your left.

Front View Top View

A

G

E

C

F

BD

H

Height to top of hinge (in.) A66-5/8

Height to top of case (in.) B66-1/8

Height to mid-freezer (in.) 57

Case depth without door (in.) C27-1/2

Case depth less door handle (in.) D30-1/4

Case depth with door handle (in.) E32-1/8

Depth with fresh food door open 90° (in.) F58-1/8

Width (in.) G29-1/2

Width with door open 90° with door handle (in.) H32

Each side (in.) 1/8

Top (in.) 1

Back (in.) 1

Air Overall

Clearances Dimensions

Specification Created 12/03

410320

®

HTS18ICP – Hotpoint 17.9 Cu. Ft. Top-Freezer Refrigerator with Icemaker

Features and Benefits

• Illuminated Upfront Slimline Temperature Controls – Offer maximum style and convenience

• Adjustable Glass Shelves – Lets consumers maximize usable storage space

• Vegetable/Fruit Crispers – Provide easy storage for your fruits and vegetables

• Factory-Installed Icemaker – Makes ice automatically, ensuring a ready supply

• Gallon Door Storage – Makes room for milk and any other gallon size containers

• Contoured Doors – Create a high-fashion look with gently rounded doors and edges

• Deluxe Quiet Design – Significantly reduces operating noise

• NeverClean™Condenser – Condenser coils are encased, so they don’t require cleaning in normal

operating environments

•Model HTS18ICPWW – White on white

•Model HTS18ICPCC – Bisque on bisque
