HP WL110 - Wireless PC Card Manuale utente

HP WIRELESS PC CARD

WL110

QUICK INSTALL GUIDE

Notice

Microsoft, MS-DOS, Windows, and Windows NT are trademarks

of Microsoft Corporation in the U.S. and other countries. Intel,

Pentium, Intel Inside, and Celeron are trademarks of Intel

Corporation in the U.S. and other countries. Adobe, Acrobat, and

Acrobat Reader are trademarks or registered trademarks of Adobe

Systems Incorporated. All other product names mentioned herein

may be trademarks of their respective companies.

Hewlett-Packard Company shall not be liable for technical or

editorial errors or omissions contained herein or for incidental or

consequential damages in connection with the furnishing,

performance, or use of this material. The information in this

document is provided "as is" without warranty of any kind,

including, but not limited to, the implied warranties of

merchantability and fitness for a particular purpose, and is subject

to change without notice. The warranties for HP products are set

forth in the express limited warranty statements accompanying

such products. Nothing herein should be construed as constituting

an additional warranty.

This document contains proprietary information that is protected by

reproduced, or translated to another language without the prior

written consent of Hewlett-Packard Company.

hp wireless PC card WL110 Quick Install Guide

September 2002.

Table of Contents

Table of Contents ___________________________________________

chapter 1: About 11 Mbps Wireless LAN ______________________ 1-1

Kit Contents________________________________________ 1-1

Network Options ____________________________________ 1-3

 Peer-to-Peer Workgroup __________________________ 1-3

 Home Office Networking__________________________ 1-4

 Enterprise Networking ____________________________ 1-6

hp wireless PC card WL110 Features ____________________ 1-8

 hp wireless PC card WL110 Features _______________ 1-10

About the CD-ROM ________________________________ 1-11

Finding Information ________________________________ 1-12

chapter 2: Installation for Windows ___________________________ 2-1

Introduction________________________________________ 2-1

Insert your hp wireless PC card WL110 __________________ 2-3

Install Drivers ______________________________________ 2-4

 Before You Start the Installation ____________________ 2-4

 What You Need to Know__________________________ 2-4

 Driver Installation for Windows ____________________ 2-5

1-i

Set Windows Network Properties ______________________ 2-7

Wireless LAN Properties _____________________________ 2-8

 Configuration Profile ____________________________ 2-9

 Basic Settings _________________________________ 2-10

Finish the Installation_______________________________ 2-14

 After Restarting Your Computer___________________ 2-15

chapter 3: Working with 11 Mbps Wireless LAN and Windows ____ 3-1

Introduction _______________________________________ 3-1

Use your hp wireless PC card WL110___________________ 3-2

 Radio Antennae_________________________________ 3-2

 Remove the hp wireless PC card WL110 _____________ 3-2

 Maintenance of your hp wireless PC card WL110 ______ 3-4

View Other Computers_______________________________ 3-4

Using the Client Manager ____________________________ 3-6

 View Wireless Link Quality _______________________ 3-7

 View/Modify hp wireless PC card WL110 Settings_____ 3-8

chapter 4: Advanced Settings _______________________________ 4-1

Introduction _______________________________________ 4-1

Advanced Parameters Tab ____________________________ 4-2

Admin Parameters Tab_______________________________ 4-4

1-ii

appendix A: Card Specifications ____________________________

Physical Specifications ______________________________

Electrical Characteristics_____________________________

Networking Characteristics___________________________

Regulatory Information______________________________

Radio Characteristics________________________________

A-1

A-2

A-3

A-4

A-5

appendix B: Troubleshooting ________________________________ B-1

 LED Activity ___________________________________ B-1

 Can Not Connect To The Network __________________ B-6

 LEDs Work But Can’t Connect to Network ___________ B-6

appendix C: Installation for Windows CE ______________________ C-1

Introduction________________________________________ C-1

 Installing the 11 Mbps Wireless LAN Driver __________ C-3

 Using 11 Mbps Wireless LAN with Windows CE ______ C-5

 Modifying Configuration Parameters_________________ C-6

appendix D: Installation for Windows NT _____________________ D-1

Introduction_______________________________________ D-1

1-iii

Installing the 11 Mbps Wireless LAN Driver _____________ D-2

 Overview______________________________________ D-2

 Start Installation ________________________________ D-3

 Enable PCMCIA Services_________________________ D-4

 Enable Network Support__________________________ D-5

1-iv

chapter 1

About 11 Mbps Wireless

LAN

Kit Contents

The hp wireless PC card WL110 kit includes the items as

pictured in Figure 1-1:

a. One hp wireless PC card WL110.

b. A transparent protective casing for storing your hp

wireless PC card WL110 while not in use.

c. The “hp wireless PC card WL110 Quick Install Guide”

d. One 11 Mbps Wireless LAN CD-ROM.

The Quick Install Guide is an abstract from the electronic

User’s Guide that is included on the CD-ROM.

About 11 Mbps Wireless LAN 1-1

Figure 1-1 Kit Contents

Note: In order to extend the life of the hp wireless PC card

WL110 hardware itisadvisedtostore the cardinthe

protective casing whenever carrying the computer on

travel without operating the device.

1-2 About 11 Mbps Wireless LAN

Network Options

The hp wireless PC card WL110 Kit enables you to:

 Connect your computer to a Peer-to-Peer workgroup of

wireless computing devices (see Figure 1-2 on page 1-4).

 Connect your computer to a Small Office/Home Office

(SOHO) network that includes a WL310 Gateway (see

Figure 1-3 on page 1-5).

 Connect your computer to a Local Area Network (LAN)

Infrastructure that includes access points (see Figure 1-4

on page 1-6 and Figure 1-5 on page 1-7).

 Expand the capabilities of your access points, to support

wireless devices that have been equipped with wireless

LAN adapters.

Peer-to-Peer Workgroup

The Peer-to-Peer workgroup configuration enables you to

quickly set up a small wireless workgroup, where the

workgroup participants can exchange files using features like

“File and Printer Sharing” as supported by Microsoft

Networking.

About 11 Mbps Wireless LAN 1-3

Figure 1-2 Peer-to-Peer Wireless Workgroup

You can use this option to setup a temporary or ad-hoc

network in environments where no access points are

available (for example in Small Office/Home Office (SOHO)

environments).

As long as the stations are within range of one another, this is

the easiest and least expensive way to set up a wireless

network.

Home Office Networking

With the WL310 Gateway, wireless access to the Internet or

other computers is at your fingertips.

1-4 About 11 Mbps Wireless LAN
