HP Compaq Presario Manuale utente

Filename: s3adwmpm.doc Title: HP-Print2k.dot

Template: HP-Print2K.dot Author: kimt Last Saved By: kimt

Revision #: 35 Page: 1 of 32 Printed: 03/07/03 10:36 AM

Installing the Optical Wireless Mouse Set

— Lea Esto Primero —

Instalación del set de ratón óptico inalámbrico

Installation de l’ensemble de souris optique sans fil

Filename: s3adwmpm.doc Title: HP-Print2k.dot

Template: HP-Print2K.dot Author: kimt Last Saved By: kimt

Revision #: 35 Page: 2 of 32 Printed: 03/07/03 10:36 AM

Installing the Optical Wireless Mouse Set 1

Filename: s3adwmpm.doc Title: HP-Print2k.dot

Template: HP-Print2K.dot Author: kimt Last Saved By: kimt

Revision #: 35 Page: 1 of 32 Printed: 03/07/03 10:36 AM

English

Installing the

Optical Wireless Mouse Set

The wireless mouse set includes:

■ Receiver

■ Wireless optical mouse

■ Two alkaline AA batteries

■ Instruction booklet

The receiver (D) plugs into the computer and

works with the wireless optical mouse (M).

Note: This wireless mouse set is compatible with

your model PC and is not intended for

use with other computers.

Important: The mouse goes into a sleep or

suspend mode after 20 minutes of inactivity.

Click a button on the mouse to wake it.

(Moving the mouse does not wake it.)

2Installing the Optical Wireless Mouse Set

Filename: s3adwmpm.doc Title: HP-Print2k.dot

Template: HP-Print2K.dot Author: kimt Last Saved By: kimt

Revision #: 35 Page: 2 of 32 Printed: 03/07/03 10:36 AM

Getting the Mouse Ready

M2 M1

Note: Do not use rechargeable batteries in the

mouse. Alkaline batteries are

recommended.

Install the two alkaline AA batteries (provided)

in the wireless mouse:

1 Push in at M1 and lift the battery cover (M2)

from the bottom of the mouse.

2 Insert the batteries into the compartment. Note

the battery images on the inside of the

compartment, and make sure batteries are

placed in the correct direction.

3 Replace the cover.

Note: The red light (M3) turns on when the

batteries are installed correctly.

Installing the Optical Wireless Mouse Set 3

Filename: s3adwmpm.doc Title: HP-Print2k.dot

Template: HP-Print2K.dot Author: kimt Last Saved By: kimt

Revision #: 35 Page: 3 of 32 Printed: 03/07/03 10:36 AM

English

Getting the Receiver Ready

The receiver (D) must be placed flat on a surface and positioned properly to avoid interference from other

electrical equipment.

1 Turn off your computer.

2 Connect the receiver cable (D1) to a USB connector on the front or the back of the computer.

4Installing the Optical Wireless Mouse Set

Filename: s3adwmpm.doc Title: HP-Print2k.dot

Template: HP-Print2K.dot Author: kimt Last Saved By: kimt

Revision #: 35 Page: 4 of 32 Printed: 03/07/03 10:36 AM

3 Set the receiver flat on a surface and follow these guidelines:

■ A: Minimum 20 cm (8 inches) clearance between the receiver and other electronic devices.

■ B: Maximum 1.5 m (59 inches) working distance between the receiver and wireless mouse.

■ C: Minimum 20 cm (8 inches) clearance between the receiver and the monitor.

■ Place no electronic device between the receiver and wireless mouse.

Installing the Optical Wireless Mouse Set 5

Filename: s3adwmpm.doc Title: HP-Print2k.dot

Template: HP-Print2K.dot Author: kimt Last Saved By: kimt

Revision #: 35 Page: 5 of 32 Printed: 03/07/03 10:36 AM

English

Note: This is one example of the setup. Other

setup positions are also possible. The

wireless keyboard is not included in the

wireless mouse set.

Warning: To avoid causing

interference, keep the receiver at least

20 cm (8 inches) away from the monitor.

Setting Up the Wireless Set

The mouse has 255 IDs that are randomly

selected when you press the ID button. This helps

protect against interference from other wireless

devices in the same area.

Important: The word CONNECT is the label for

the ID button on the bottom of the mouse.

To press the ID button, use a blunt pointed

object, like the tip of a ballpoint pen.

1 Turn on the computer.

Important: If the ID button is pressed more than

one time during the setup, you must start

over with step 2.

2 On the front of the receiver (D), press the

ID button (E) once.

The blue activity light (J) on the receiver starts

flashing and continues flashing until the next

step is completed or until 30 seconds pass.

6Installing the Optical Wireless Mouse Set

Filename: s3adwmpm.doc Title: HP-Print2k.dot

Template: HP-Print2K.dot Author: kimt Last Saved By: kimt

Revision #: 35 Page: 6 of 32 Printed: 03/07/03 10:36 AM

Important: If 30 seconds pass before you

complete step 3, you must repeat step 2

and step 3 to set the mouse ID. If the

ID button is pressed more than one time

during the mouse setup (step 3), you

must start over with step 2 and set the

receiver ID.

3 On the bottom of the mouse, press the

ID button (N) once with a blunt pointed object.

The mouse sends a new ID and flashes the

mouse sensor light (M3) three times. The

receiver flashes its blue activity light (J) three

times and then stops to show it has accepted

the new ID for the mouse.

Note: At this time, when you move the mouse

across a surface, the blue activity light (J)

on the receiver goes on and off indicating

the mouse and the receiver are working

together.

Important: The mouse goes into a sleep or

suspend mode after 20 minutes of inactivity.

Click a button on the mouse to wake it.

(Moving the mouse does not wake it.)

Installing the Optical Wireless Mouse Set 7

Filename: s3adwmpm.doc Title: HP-Print2k.dot

Template: HP-Print2K.dot Author: kimt Last Saved By: kimt

Revision #: 35 Page: 7 of 32 Printed: 03/07/03 10:36 AM

English

Resetting ID Buttons

When Replacing Batteries

When the batteries are replaced in the mouse,

reset the ID buttons on the receiver and the

mouse to allow the mouse to work with the

receiver. You must press the receiver ID button

first and then press the mouse ID button. Refer

to the steps in the section “Setting Up the

Wireless Set.”

Note: You can replace the batteries in the mouse

without turning off the computer. However,

the computer must be on when you change

the ID settings.

Using the Wireless Set

The blue light (J) on the receiver (D) indicates

activity when you move or click any button on the

mouse. The button (E) is the receiver ID button.

Use the receiver on a nonmetallic surface for

better reception.

The optical mouse uses a light to sense

movement. Use the optical mouse on an opaque

surface; the optical mouse cannot work on a

glass, translucent, or reflective surface.

8Installing the Optical Wireless Mouse Set

Filename: s3adwmpm.doc Title: HP-Print2k.dot

Template: HP-Print2K.dot Author: kimt Last Saved By: kimt

Revision #: 35 Page: 8 of 32 Printed: 03/07/03 10:36 AM

Important: The mouse goes into a sleep or

suspend mode after 20 minutes of inactivity.

Click a button on the mouse to wake it.

(Moving the mouse does not wake it.)

You may notice that the mouse moves the cursor

on the screen twice as fast as a standard mouse

does. The mouse moves the cursor at 800 dots

per inch (dpi) while a standard mouse moves the

cursor at 400 dpi. Change the cursor movement

speed by using the mouse properties in the

Control Panel.

Note: If you use a mouse pad, choose a light-

colored one, not a dark one, to conserve

battery power.

Low Battery Icon

The computer displays a mouse icon in the

upper-right corner of the screen to indicate

low batteries.

Note: The Low Battery icon appears 5 times each

hour until the batteries are changed.
