HP Desktop Mini
Hardware Reference Guide
© Copyright 2017 HP Development Company,
L.P.
Windows is either a registered trademark or
trademark of Microsoft Corporation in the
United States and/or other countries.
The information contained herein is subject to
change without notice. The only warranties for
HP products and services are set forth in the
express warranty statements accompanying
such products and services. Nothing herein
should be construed as constituting an
additional warranty. HP shall not be liable for
technical or editorial errors or omissions
contained herein.
First Edition: January 2017
Document Part Number: 913329-001
Product Notice
This guide describes features that are common
to most models. Some features may not be
available on your computer.
Not all features are available in all editions or
versions of Windows. Systems may require
upgraded and/or separately purchased
hardware, drivers, software or BIOS update to
take full advantage of Windows functionality.
For details on Windows® 8 functionality, go to
http://www.microsoft.com for details.
For details on Windows 7 functionality. Go to
http://windows.microsoft.com/en-us/
windows7/get-know-windows-7 for details.
To access the latest user guides or manuals for
your product, go to http://www.hp.com/
support, and select your country. Select Find
your product, and then follow the on-screen
instructions.
Software terms
By installing, copying, downloading, or
otherwise using any software product
preinstalled on this computer, you agree to be
bound by the terms of the HP End User License
Agreement (EULA). If you do not accept these
license terms, your sole remedy is to return the
entire unused product (hardware and software)
within 14 days for a refund subject to the
refund policy of your seller.
For any further information or to request a full
refund of the price of the computer, please
contact your seller.
About This Book
This guide provides basic information for upgrading the HP Desktop Mini Business PC.
WARNING! Text set o in this manner indicates that failure to follow directions could result in bodily harm or
loss of life.
CAUTION: Text set o in this manner indicates that failure to follow directions could result in damage to
equipment or loss of information.
NOTE: Text set o in this manner provides important supplemental information.
iii
iv About This Book
Table of contents
1 Product features ........................................................................................................................................... 1
Standard conguration features ........................................................................................................................... 1
Front panel components (EliteDesk 800 and ProDesk 600) ................................................................................. 2
Front panel components (ProDesk 400) ............................................................................................................... 3
Rear panel components (EliteDesk 800, and ProDesk 600) ................................................................................. 4
Rear panel components (ProDesk 400) ................................................................................................................. 5
Serial number location .......................................................................................................................................... 6
2 Setup ............................................................................................................................................................ 7
Changing from desktop to tower orientation ........................................................................................................ 7
Attaching the computer to a mounting xture ..................................................................................................... 9
Installing a security cable .................................................................................................................................... 10
Connecting the power cord .................................................................................................................................. 10
3 Hardware upgrades ...................................................................................................................................... 11
Serviceability features ......................................................................................................................................... 11
Warnings and cautions ........................................................................................................................................ 11
Removing the computer access panel ................................................................................................................. 12
Replacing the computer access panel ................................................................................................................. 14
Upgrading system memory ................................................................................................................................. 15
Memory module specications ......................................................................................................... 15
Populating memory module slots .................................................................................................... 16
Installing a memory module ............................................................................................................. 17
Removing a hard drive ......................................................................................................................................... 20
Installing a hard drive .......................................................................................................................................... 21
Replacing an M.2 PCIe solid-state drive .............................................................................................................. 22
Replacing the WLAN module ............................................................................................................................... 27
Installing an external antenna ............................................................................................................................ 32
Replacing the battery .......................................................................................................................................... 37
Synchronizing the optional wireless keyboard and mouse ................................................................................ 42
v
Appendix A Electrostatic discharge .................................................................................................................. 44
Preventing electrostatic damage ........................................................................................................................ 44
Grounding methods ............................................................................................................................................. 44
Appendix B Computer operating guidelines, routine care and shipping preparation ............................................. 45
Computer operating guidelines and routine care ............................................................................................... 45
Shipping preparation ........................................................................................................................................... 46
Appendix C Accessibility ................................................................................................................................. 47
Supported assistive technologies ....................................................................................................................... 47
Contacting support .............................................................................................................................................. 47
Index ............................................................................................................................................................. 48
vi
1 Product features
Standard conguration features
Features may vary depending on the model. For a complete listing of the hardware and software installed in
the computer, run the diagnostic utility (included on some computer models only).
NOTE: This computer model can be used in a tower orientation or a desktop orientation. The tower stand is
sold separately.
Standard conguration features 1
Front panel components (EliteDesk 800 and ProDesk 600)
NOTE: Your computer model may look slightly dierent from the illustration in this section.
Item Icon Component Item Icon Component
1 USB Type-C SuperSpeed port with HP Sleep and
Charge*
5Audio-out (headset)/Audio-in (microphone)
combo jack
2USB 3.x port 6 Drive light
3USB 3.x port with HP Sleep and Charge* 7Dual-state power button
4Headphone jack
*When the computer is on, the USB port connects a USB device, provides high-speed data transfer, and even when the computer is o,
charges products such as a cell phone, camera, activity tracker, or smartwatch.
NOTE: The drive light is normally white when the power is on. If it is ashing red, there is a problem with the computer and the drive
light is displaying a diagnostic code. Refer to the Maintenance and Service Guide to interpret the code.
2 Chapter 1 Product features
Front panel components (ProDesk 400)
NOTE: Your computer model may look slightly dierent from the illustration in this section.
Item Icon Component Item Icon Component
1USB 3.x port 4Audio-out (headset)/Audio-in (microphone)
combo jack
2USB 3.x port with HP Sleep and Charge* 5 Drive light
3Headphone jack 6Dual-state power button
*When the computer is on, the USB port connects a USB device, provides high-speed data transfer, and even when the computer is o,
charges products such as a cellphone, camera, activity tracker, or smartwatch.
NOTE: The drive light is normally white when the power is on. If it is ashing red, there is a problem with the computer and the drive
light is displaying a diagnostic code. Refer to the Maintenance and Service Guide to interpret the code.
Front panel components (ProDesk 400) 3
Rear panel components (EliteDesk 800, and ProDesk 600)
NOTE: Your computer model may look slightly dierent from the illustration in this section.
Item Icon Component Item Icon Component
1 Antenna cover 7DisplayPort (optional)
NOTE: The DisplayPort is optional and may
be replaced with one of the following ports:
HDMI, VGA, USB Type-C alternate mode, or
serial port.
2 Cover lock switch 8USB 3.x ports (2) (black)
3Security cable slot 9USB 3.x ports (2) (black)
4 External antenna connector 10 RJ-45 (network) jack
5 Padlock loop 11 Power connector
6Dual-Mode DisplayPort (D++) (2)
4 Chapter 1 Product features
