HP SB360 Manuale utente

Initial Settings

When you turn on your camera for the first time, you will be asked to do the initial settings

of your camera.

When you turn the Power button on, the Language Menu is displayed on the LCD screen

for you to setup the display language.

Setting the Language

Press , , or to move through the selection.

Select a language, then press SET to apply.

Setting the Date & Time

Press or to move through the selection.

Press or keys to change the value for the date and time.

Press SET to apply.

If necessary, press to close the menu.

HP SB360

Digital Camera

Quick Start Guide

Initial Settings

When you turn on your camera for the first time, you will be asked to do the initial settings

of your camera.

When you turn the Power button on, the Language Menu is displayed on the LCD screen

for you to setup the display language.

Setting the Language

Press , , or to move through the selection.

Select a language, then press SET to apply.

Setting the Date & Time

Press or to move through the selection.

Press or keys to change the value for the date and time.

Press SET to apply.

If necessary, press to close the menu.

HP SB360

Digital Camera

Quick Start Guide

1. Shutter button

2. Flash

3. Stabilizer

4. LED indicator

5. Power button

6. Self-timer LED / AF Assist Lamp

7. Microphone

8. Zoom Lens

9. Zoom buttons

10. Strapring

11. Function / Delete button

12. Menu Button

13. SET button / 4-way navigation

control

14. Playback button

15. LCD screen

Getting Started

Parts of the Camera

16. Battery / SD card compartment

17. USB / TV Out

18. Tripod screw hole

19. Speaker

Setting the Display Language / Date & Time

When using the camera for the first time after purchasing, be sure to choose a

language and set the date & time before using the camera.

Setting the Display Language

1Turn the power on, and set the

camera to the Setup Menu.

Select [ Language].

Press or to select

[LANGUAGE] then press SET button

to launch the submenu.

Select a language.

Press or to select a language and press SET button to apply

the setting.

Press the MENU button to close the menu.

Setting the Date & Time

1Turn the power on, and set the

camera to the Setup Menu.

Select [ Date & Time].

Press or to select [Date &

Time] then press SET button to

launch the submenu.

Set date and time.

Press or to change the value of the cursor located. Press or

button to move the cursor between settings.

Apply the setting.

After adjusting the settings, press the OK or the MENU button to apply the

setting.

Once the date, time and language have been set, changing the batteries or removing

the SD card will NOT reset these settings. However, if the batteries are removed for

longer than 48 hours, the Date and Time will need to be re-set.

Using the Menus

When the menu is displayed, use the 4-way navigation control and the SET

button to move through menu selections and apply your desired settings.

To close the menu anytime, press the menu button again

Using the Shooting Menu

Turn the power on, and set the

camera to Shooting mode.

Press to launch the Shooting

Menu.

Use the or keys to move

through the menu selections.

To select an item, press .

Change the submenu settings using the 4-way navigation control.

Press the SET button to save and apply settings.

Using the Setup Menu

You can access the Setup menu whether you are in Shooting or Playback mode. The

Setup menu allows you to configure general camera settings.

Press to launch the

Record/ Playback Menu.

Use the or keys to change

the menu tab to Setup

menu.

Use the or keys to move through the menu selections.

To select an item, press .

Change the submenu settings using the 4-way navigation control.

Press the SET button to save and apply settings.

Using the Function Menu

The Function Menu is used to adjust capture settings in Shooting Mode. It contains My Mode,

Resolution, Quality, EV Compensation, White Balance, ISO, Metering, and Color Mode.

Press the FUNC button of your camera to launch the Function Menu.

Press the FUNC button again to close the menu.

The Menu bar displays the current

status of your camera settings. Only

the available functions for the settings

are shown as icon on the menu bar.

The available options for each item

on the menu bar are shown in the

Menu options.

Use the or to move through

the menu selections then press the

SET button to save and apply

changes

My Mode

The My Mode function displays the 6 most recent modes used in order. When you move

through the different modes in the menu options, the items on the menu bar changes

synchronously tothe corresponding available settings.

Initial Settings

When you turn on your camera for the first time, you will be asked to do the initial settings

of your camera.

When you turn the Power button on, the Language Menu is displayed on the LCD screen

for you to setup the display language.

Setting the Language

Press , , or to move through the selection.

Select a language, then press SET to apply.

Setting the Date & Time

Press or to move through the selection.

Press or keys to change the value for the date and time.

Press SET to apply.

If necessary, press to close the menu.

HP SB360

Digital Camera

Quick Start Guide

Initial Settings

When you turn on your camera for the first time, you will be asked to do the initial settings

of your camera.

When you turn the Power button on, the Language Menu is displayed on the LCD screen

for you to setup the display language.

Setting the Language

Press , , or to move through the selection.

Select a language, then press SET to apply.

Setting the Date & Time

Press or to move through the selection.

Press or keys to change the value for the date and time.

Press SET to apply.

If necessary, press to close the menu.

HP SB360

Digital Camera

Quick Start Guide

P/N: 7525C00043A
