HP Compaq nx6115 Manuale utente

Multimedia

Document Part Number: 383369-001

May 2005

This guide explains how to use the audio and video (select models

only) features of the notebook.

Multimedia ii

Contents

Multimedia

Audio Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Using the Internal Microphone or the Audio-In

(Microphone) Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Using the Audio-Out (Headphone) Jack . . . . . . . . . . . . 5

Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Video Features (Select Models Only) . . . . . . . . . . . . . . . . . 7

Using the S-Video-out Jack. . . . . . . . . . . . . . . . . . . . . . 8

Connecting a Monitor, Projector or Television. . . . . . . 9

Multimedia Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Observing the Copyright Warning . . . . . . . . . . . . . . . 10

Installing Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Enabling AutoPlay. . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Using Windows Media Player. . . . . . . . . . . . . . . . . . . 12

Using InterVideo WinDVD. . . . . . . . . . . . . . . . . . . . . 12

Using InterVideo WinDVD Creator Plus

(Select Models Only). . . . . . . . . . . . . . . . . . . . . . . . . . 13

Using Sonic RecordNow! . . . . . . . . . . . . . . . . . . . . . . 13

Changing DVD Region Settings . . . . . . . . . . . . . . . . . 14

Multimedia 1

Multimedia

Audio Features

The following figure and table describe the audio features of the

notebook.

✎Components included with your notebook may vary by

geographical region and by model. The illustrations in this

chapter identify the standard features included in most

notebook models. Refer to the illustration that most closely

matches your notebook.

2 Multimedia

Component Description

1Audio-in (microphone) jack Connects an optional headset

microphone or a monaural

microphone.

2Audio-out (headphone) jack Produces notebook sound when

connected to optional powered stereo

speakers, headphones, headset, or

television audio.

3Speakers (2) Produce notebook sound.

4Volume mute hotkey Turns off notebook sound.

5Volume down hotkey Decreases notebook sound.

6Volume up hotkey Increases notebook sound.

(Continued)

Multimedia 3

7Volume mute button Turns off notebook sound.

8Volume down button Decreases notebook sound.

9Volume up button Increases notebook sound.

-Volume mute light On: Notebook sound is turned off.

;Internal microphone Records sound.

Component Description

4 Multimedia

Component Description

1Audio-in (microphone) jack Connects an optional headset

microphone or a monaural

microphone.

2Audio-out (headphone) jack Produces notebook sound when

connected to optional powered stereo

speakers, headphones, headset, or

television audio.

3Speakers (2) Produce notebook sound.

4Volume mute hotkey Turns off notebook sound.

5Volume down hotkey Decreases notebook sound.

6Volume up hotkey Increases notebook sound.

7Internal microphone Records sound.

Multimedia 5

Using the Internal Microphone or the

Audio-In (Microphone) Jack

Your notebook is equipped with an internal monaural microphone

and a microphone jack that supports an optional headset

microphone or a monaural microphone.

When connecting a microphone to the microphone jack, use a

microphone with a 3.5-mm plug.

✎When a microphone is connected to the microphone jack, the

internal microphone is disabled.

Using the Audio-Out (Headphone) Jack

ÅWARNING: To reduce the risk of personal injury, adjust the volume

before putting on headphones or a headset.

In addition to connecting headphones, the headphone jack is used

to connect the audio function of an audio/video device such as a

television or VCR.

When connecting a device to the headphone jack:

■Use only a 3.5-mm stereo plug.

■For best sound quality, use 24-ohm to 32-ohm headphones.

✎When a device is connected to the headphone jack, the internal

speakers are disabled.

6 Multimedia

Adjusting the Volume

You can adjust the volume using any of the following controls:

■Notebook volume buttons (select models only)

❏To mute or restore volume, press the volume mute button.

❏To decrease the volume, press the volume down button.

❏To increase the volume, press the volume up button.

■Microsoft® Windows® volume control:

1. Click the Volume icon in the notification area (at the far

right of the taskbar).

2. Increase or decrease the volume by moving the slider up

or down. (You can also select the Mute check box to mute

the volume.)

– or –

1. Double-click the Vol um e icon in the notification area.

2. In the Volume Control column, increase or decrease the

volume by moving the Vol ume slider up or down. You can

also adjust the balance or mute the volume.

✎Volume can also be adjusted within some applications.

If the Volume icon is not in the notification area, follow the steps

below to place it in the notification area.

1. Select Start > Control Panel > Sounds, Speech, and Audio

Devices > Sounds and Audio Devices.

2. Click the Volume tab.

3. Select the Place volume icon in the taskbar check box.

4. Click Apply.

Multimedia 7

Video Features (Select Models Only)

The notebook features a 7-pin S-Video-out jack that connects the

notebook to an optional S-Video device such as a television,

VCR, camcorder, overhead projector, or video capture card.

The notebook can support one S-Video device connected to the

S-Video-out jack while simultaneously supporting an image on

the notebook display and on any other supported external display.

The S-Video connection usually provides a higher quality image

than a composite-video connection.

To transmit video signals through the S-Video-out jack, you need

an S-Video cable, available from most electronics retailers. If you

are combining audio and video functions, such as playing a movie

from a DVD in an optional MultiBay drive to a television, you

also need a standard audio cable, available from most electronics

retailers.

8 Multimedia

Using the S-Video-out Jack

To connect a video device to the S-Video-out jack:

1. Plug one end of the S-Video cable into the S-Video-out jack

on the notebook.

2. Connect the other end of the cable to the video device, as

instructed in the documentation included with the device.

✎If the S-Video-out jack on the notebook is not accessible

because the notebook is docked into an optional docking

device, you can connect the device to the S-Video-out jack on

the docking device.
